Dension Gateway Five General Installation Manual

Gateway Five
iPod, USB, Bluetooth
General
Installation Guide
v1.0
GWF-9001-1
1 Introduction
Warning!
Always make sure that the the ignition key is
removed from the car, the radio is switched off
and that you have the security code of the
head unit (radio) available (if applicable).
The Dension Gateway Five connects your iPod or
USB storage (stick, hard drive or mass storage
capable mp3 player) to your original car radio,
providing music playback, menu based control
and charging.
The Gateway Five also
connectivity for music streaming (via A2DP) and
handsfree mobile call handling via the original
buttons and screens of your vehicle.
Please make sure that the vehicle compatibility
is correct.
The Dension Gateway Five is available in specific
versions for different vehicle types, therefore the
exact operation and installation may be different in
each case.
Remove the head unit
First, carefully remove your vehicle's existing
factory fit head unit as per the factory instructions
and using the correct tools.
In some cases, removing the head unit will require
panel removal. Contact your vehicle's dealer or
installation supplier/installer for more information.
2
Once the head unit has been removed, disconnect
the antenna cable (1), then unclip the main wiring
connector from the head unit (2). This will differ in
all makes and manufacturers.
offers Bluetooth
With the main radio cable removed, connect the
Dension supplied cable between the original
factory cable harness and the head unit.
Fitting the Gateway Harness
