Product Description
The //code.Node Holder is an accessory for the //code.Node (PS-3231). The Holder is
used to mount the //code.Node to a variety of surfaces.
1
What's Included
//code.Node Holder with Strap
1
Use the strap on the Holder to mount a
//code.Node to a variety of objects.
Hook and Loop Strap
2
For attaching to the strap on the Holder
to create a longer strap.
What's Required
• //code.Node (PS-3231)
//code.Node Holder
PS-3233
3
Instruction Manual | 012-16830A
Hook Fastener Strip
3
Attaches to the loop fastener strip on
the back of the Holder. Use the sticky
back on the strip to attach it to a
smooth surface.
2
1
Advertisement
Table of Contents
Related Manuals for PASCO //code.Node Holder
Summary of Contents for PASCO //code.Node Holder
- Page 1 Instruction Manual | 012-16830A //code.Node Holder PS-3233 Product Description The //code.Node Holder is an accessory for the //code.Node (PS-3231). The Holder is used to mount the //code.Node to a variety of surfaces. What's Included //code.Node Holder with Strap Hook Fastener Strip Use the strap on the Holder to mount a Attaches to the loop fastener strip on //code.Node to a variety of objects.
- Page 2 //code.Node Holder | PS-3233 //code.Node Holder Features Strap Slots Release Tab For inserting the included hook and For securing the //code.Node to the loop strap. Holder. Pull gently to release the //code.Node from the Holder. Fastener Hole Loop Fastener Strip (not shown) Use to insert a fastener (such as a screw) for a permanent mounting The strip is located on the back of the...
- Page 3 Instruction Manual | 012-16830A Install the //code.Node into the Holder 1. Insert the top side of the //code.Node into the Holder face up. 2. Press down the bottom side of the //code.Node until it snaps in place. To release the //code.Node from the holder, gently pull back the release tab then pull the //code.Node out of the Holder.
- Page 4 Warranty, Copyright, and Trademarks Limited Warranty For a description of the product warranty, see the Warranty and Returns page at www.pasco.com/legal. Copyright This document is copyrighted with all rights reserved. Permission is granted to non-profit educational institutions for reproduction of any part of this manual, providing the reproductions are used only in their laboratories and classrooms, and are not sold for profit.
