Summary of Contents for Ryobi RPW190BL-G
- Page 1 ORIGINAL INSTRUCTIONS Brushless Pressure Washer RPW190BL-G RBC36X26E RBC36X26E...
- Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. Subject to technical modification.
-
Page 3: Intended Use
Safety, performance, and dependability have ■ To reduce the risk of injury, keep children been given top priority in the design of your and visitors away. All visitors should wear brushless pressure washer. safety glasses and be kept at a safe distance from the work area. -
Page 4: Electrical Safety Warnings
ELECTRICAL SAFETY WARNINGS WARNING ■ The plug must match the outlet. Never Depending on the application, shielded modify the plug in any way. Unmodified nozzles can be used for high-pressure plugs and matching outlets reduces the cleaning, which will reduce the emission risk of electric shock. -
Page 5: Additional Safety Warnings
handle to pump using the high-pressure WARNING hose, disengage the trigger handle lock, Always turn off the mains disconnecting and press the trigger until there is a steady switch when leaving the product unattended. flow. ■ Exercise caution to avoid slipping or falling. ■... -
Page 6: Transportation And Storage
■ Regularly inspect and maintain the high down. Disconnect the product from the pressure washer for safe operation. RYOBI water supply before storing or transporting. Never place the product in any position recommends inspecting the product every 3 months. -
Page 7: Residual Risks
result of a clogged or dirty nozzle. reported that cold weather is a major factor contributing to Raynaud’s Syndrome. ■ Turn off the pressure washer disconnect from power supply, and turn off the water ■ After each period of operation, exercise to supply. -
Page 8: What's In The Box
■ If any parts are damaged or missing, WARNING please call your RYOBI service centre for Do not allow familiarity with the product assistance. to make you careless. Remember that a careless fraction of a second is sufficient to WHAT’S IN THE BOX... - Page 9 following jobs: STARTING AND STOPPING THE HIGH PRESSURE WASHER ■ Clean or remove mold and mildew from weathered decks, driveways, patios, NOTE: Do not run the pressure washer walkways, sidewalks, etc. without water supply connected and turned on, as this may damage the high pressure ■...
- Page 10 USING THE HIGH PRESSURE HOSE pressure in the system. Pull trigger to release water pressure. WARNING RINSING WITH THE HIGH PRESSURE WASHER Injection hazard. Fully unwrap straighten high pressure hose prior to and ■ Turn off the pressure washer and turn off during each use and do not allow it to the water supply.
-
Page 11: Symbols In This Manual
To reduce the risk of injury from Connect to power outlet. kickback, hold the spray wand securely with both hands when the product is on. Disconnect from power outlet. Failure to use in dry conditions and to observe safe practices Note can result in electric shock. -
Page 12: Troubleshooting
TROUBLESHOOTING Problem Possible causes Solution Pressure washer Power cord not connected to Connect the power cord to a live 240V AC, 50 Hz AC does not start when power source. receptacle. trigger is depressed The on/off switch is in the OFF Press the on/off switch to turn on the product. - Page 13 WHAT’S IN THE BOX...
- Page 14 KNOW YOUR PRODUCT 1. 15° nozzle 10. Wheels 2. Soap nozzle 11. Spray wand 3. Turbo nozzle 12. Detergent tank cap 4. Handle 13. Detergent tank 5. Trigger handle holder 14. Water outlet port 6. Trigger handle 15. Hose adaptor 7.
- Page 15 GETTING STARTED GETTING STARTED GETTING STARTED GETTING STARTED Wear full eye and ear protection, protective gloves, Push and hold the push-pin buttons on the rear side of the Completely uncoil and straighten the high pressure hose to Completely uncoil and straighten the garden hose to Connect the threaded end of the spray wand to the Turn on water supply.
- Page 17 OVERVIEW Using the High Pressure Washer Using the Soap Nozzle Using the Turbo Nozzle p.16 p.18 p.17 Cleaning the High Pressure Washer Moving the High Pressure Washer Storing the High Pressure Washer p.20 p.22 p.23...
- Page 18 OPERATION USING THE HIGH PRESSURE WASHER 1. Plug the product into a power outlet. 2. Press the on/off switch to turn on the product. 3. Push the trigger lock out down until it clicks into position. Squeeze and hold the trigger to operate the product. WARNING: Check the work area before each use.
- Page 19 OPERATION USING THE TURBO NOZZLE 1. Engage the lock out on the trigger handle. Push the lock out upwards until it clicks into the slot. 2. Pull back the quick-connect collar. Remove the present nozzle from the spray wand. 3. Pull back the quick-connect collar. Push the turbo nozzle into the quick-connect collar until it clicks into place and is secured properly.
- Page 20 OPERATION USING THE SOAP NOZZLE 1. Engage the lock out on the trigger handle. Push the lock out upwards until it clicks into the slot. 2. Pull back the quick-connect collar. Remove the present nozzle from the spray wand. 3. Pull back the quick-connect collar. Push the soap nozzle into the quick-connect collar until it clicks into place and is secured properly.
- Page 21 OPERATION 5. Push the trigger lock out down until it clicks into position. Squeeze and hold the trigger to operate the product.
-
Page 22: Maintenance
MAINTENANCE MOVING THE HIGH PRESSURE WASHER 1. Press the on/off switch to turn off the product. Turn off the water supply. 2. Disconnect the product from the power outlet. Store the power cord properly. 3. Push the trigger lock out down until it clicks into position. - Page 23 MAINTENANCE 5. Roll the product to the desired location.
- Page 24 MAINTENANCE CLEANING HIGH PRESSURE WASHER 1. Press the on/off switch to turn off the product. Disconnect the product from the power outlet. 2. Clean the product using a dry cloth. WARNING: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents.
- Page 25 STORAGE STORING HIGH PRESSURE WASHER 1. Press the on/off switch to turn off the product. 2. Turn off the water supply. 3. Disconnect the product from the power outlet. Store the power cord properly. 4. Push the trigger lock out down until it clicks into position.
- Page 26 STORAGE 5. Disconnect the garden hose from the water inlet port. Disconnect the other end of the garden hose from the garden tap.Turn the high pressure hose collar counterclockwise and then disconnect the hose from the water outlet port. 6. On the spray wand, pull back the quick- connect collar and remove the present nozzle.
- Page 27 STORAGE 7. Store the product in a cool, dry, and well- ventilated place that is inaccessible to children. Keep it away from corrosive agents such as garden chemicals and de-icing salts. Do not store the product outdoors.
-
Page 28: Product Specifications
PRODUCT SPECIFICATIONS VIBRATION LEVEL Brushless pressure washer WARNING Model RPW190BL-G The declared vibration value has been Rated voltage 220 - 240 V measured with a standard test method and may be used to compare one tool with Frequency 50 Hz another. - Page 32 Imported by: Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149 Melbourne, Australia Techtronic Industries N.Z. Limited 2 Landing Drive, Mangere RYOBI is a trademark of Ryobi Limited, Auckland, 2022, New Zealand and is used under license. 960087341-01...
