Summary of Contents for kincrome K16130
- Page 2 This boom should not be used by people with reduced physical, sensory or mental capabilities or lack of experience and knowledge. Any Questions, Comments or Parts Orders Call Kincrome Tools + Equipment 1300 657 528...
- Page 3 Hazard Signal Word Definitions...
-
Page 4: Table Of Contents
Table of Contents Intended Use ............................4 Summary of Important Safety Information ..................5 Unpacking ............................9 Unpacking the Manual Bag ......................10 Assembly ............................11 Operation – Important Safety Information ................... 17 Operation – Using the Sprayer ....................... 21 Exploded View &... -
Page 5: Intended Use
NOTE: The boom will be damaged and warranty voided if used to apply bleach, chlorine, ice control chemicals, or any petroleum based product (gasoline, diesel, kerosene, oil). Contact Kincrome Product Support for any questions about the on 1300 657 528... -
Page 6: Summary Of Important Safety Information
Summary of Important Safety Information WARNING Read and understand this owner's manual completely before using the boom kit. Read each chemical label's instructions before handling the chemical. Improper use of the boom kit or handling of chemicals could result in serious injury or illness for the operator or nearby persons/animals, or cause damage to the environment. - Page 7 EXERCISE EXTRA CAUTION when spraying near areas accessible to children and pets. CLEAN up spills immediately per instructions on the chemical label. TURN OFF vehicle and set brake or chock wheels, TURN OFF power to sprayer, and RELIEVE system pressure before leaving sprayer unattended. SEE Troubleshooting section of this manual before attempting any repairs.
- Page 8 Summary of Important Safety Information (continued) Poisoning by In case of poisoning from ingestion or inhalation: ingestion or If the victim has collapsed or is not breathing, call 000. Otherwise: inhalation 1. If you are the victim, immediately seek assistance from nearby personnel because you may become incapacitated.
- Page 9 Summary of Important Safety Information (continued) Part# Description K16-798567 Decal, Pinch Point...
-
Page 10: Unpacking
Unpacking Closely inspect all contents in the shipping carton. Note that some parts are shipped inside the tank. call Kincrome Customer Service on 1300 657 528. If you have missing or damaged components, please Hose, 3/8” x 442mm Boom Mount Bracket... -
Page 11: Unpacking The Manual Bag
Unpacking the Manual Bag Note: Items in this section are found in the manual bag. 5/16"-18 x 1/2" Bolt 5/16"-18 x 3/4" Bolt 5/16" Flange Nut K16001-14 K16-82015 K16-82019 (Qty 4) (Qty 4) (Qty 4) 3/8" Hose Clamp K16000-2 (Qty 5) -
Page 12: Assembly
Assembly Tools Needed Step 1 – For removing the existing boom on sprayer. 1/2" Spanner Screwdriver Disconnect boom supply hose. Remove old boom assembly from sprayer. Boom Fig06570... - Page 13 Assembly Tools Needed Step 2 – Bolt boom mount brackets to tank 1/2" Spanner Install boom mount brackets to tank with four 5/16"-18 x Torque Wrench 1/2" Bolts. Tighten bolts to 5 Ft-lbs (6.78nM). Use top four mounting slots. Nozzle tip should be 20” from ground after assembly Fasteners Needed from Owner’s Manual Bag: 5/16"-18 x 1/2"...
- Page 14 Assembly Step 3 – Attach boom assembly to boom mount Tools Needed brackets 1/2” Spanner Install boom assembly to boom mount brackets with four 5/16"- 18 x 3/4" bolts and nuts. Fasteners Needed from Owner’s Manual Bag: Fig06551 5/16" Flange Nut Boom Assembly K16-82019 (Qty 1)
- Page 15 Assembly Step 4 – Attach boom supply hose to fitting in Tools Needed regulator Flat Head Screw Driver Tighten 3/8" hose clamp as shown. Fasteners Needed from Owner’s Manual Bag: 3/8" Hose Clamp K16000-2 (Qty 1) Regulator 3/8" Hose Clamp Boom Supply Hose Fig06549...
- Page 16 Assembly Step 5 – Install boom hoses Tools Needed Install one end of hose to tee and secure it by tightening Flathead hose clamp. Screwdriver Install other end of hose to ball valve hose barb and secure it by tightening hose clamp. Repeat for other arm.
- Page 17 Assembly Step 6: Check and test completed assembly. 1. Test with water Test the system for leaks with water: a) Partially fill the tank with water. b) Connect the remote switch to the pump power cord and turn the remote switch ON.
-
Page 18: Operation - Important Safety Information
Operation – Important Safety Information Now that you have completed and tested your assembly, there is some important safety and health information you need to know with regard to handling and spraying chemicals, as well as vehicle handling with the sprayer attached. - Page 19 Operation – Important Safety Information Chemical Application Safety: WARNING Caution must be used when spraying chemicals to avoid unsafe exposure to humans and the environment Heed the warnings below and follow all instructions carefully. Before Spraying Sprayer prep. ALWAYS inspect and prepare the sprayer before use according to the directions provided in this manual.
- Page 20 Operation – Important Safety Information Towing/hauling Safety: WARNING The filled sprayer is very heavy. It can crush and cause serious injury if it rolls out of control or tips over. Follow the instructions below for safely towing the sprayer. Read vehicle instructions. Review towing safety instructions in your towing/hauling vehicle manual. Driver age.
- Page 21 Operation – Important Safety Information Sprayer leak In the event that the sprayer develops a leak while spraying chemicals, you must immediately stop spraying. Turn off power to the sprayer and follow the directions below, as applicable. Bodily chemical Personal contamination can occur when chemicals splash, spill, or spray contact directly onto a person.
-
Page 22: Operation - Using The Sprayer
Operation – Using the Sprayer Step 1: Operate the boom kit. WARNING ALWAYS wear personal protective equipment as directed on the chemical label when spraying. Long pants and sleeves, chemical-resistant gloves, and eye protection are strongly recommended. Additional protective gear may be required depending on the particular pesticide. - Page 23 Operation – Using the Sprayer 5. Adjust Turn pressure regulator knob to adjust outlet pressure pressure regulator 1. Turn knob clockwise to increase pressure. 2. Turn knob counter-clockwise to decrease pressure Note: If the pressure regulator knob is completely tightened, the pressure setting will be higher than the pressure switch on the pump.
- Page 24 Operation – Using the Sprayer 7. Operate A. Open boom valves broadcast Open the left, right, or all valves as desired boom Open Boom Valves Detail view open valve position B. Remove pin(s) and unfold one or both boom arms as required. Reinsert pin(s) to secure boom arms.
- Page 25 8. Leaving If the sprayer must be left unattended at any time: unattended a) Disconnect power to the sprayer. b) Relieve system pressure by depressing the gun trigger. Turn off the vehicle. Set brake or chock the wheels. 9. Discontinue If the sprayer becomes clogged or inoperative during use, discontinue use use if clogged or immediately.
- Page 26 Operation – Using the Sprayer Step 2: Clean sprayer and decontaminate after use. When done using the sprayer, it is important to clean the sprayer and decontaminate yourself. Do not store the sprayer with chemicals in the tank, as it is unsafe and could also result in damage to the equipment.
-
Page 27: Exploded View & Parts List
Exploded View & Parts List Fig06550... - Page 28 Exploded View & Parts List Ref# Part # Description K16-799249 Boom mount bracket K16-799248 Boom center weldment K16-800759 Boom arm weldment, right K16-797604 Torsion spring K16-797758 Bushing, spring K16-798359 Decal, valve on/off K16-797759 Locking pin K16004-50 Steel wire lanyard K16004-8 5/16"...
-
Page 29: Appendix A -Broadcast Spray Calibration Tables
Appendix A –Broadcast Spray Calibration Tables Below are some guidelines to help you calibrate your tow behind broadcast sprayer. This is a very important step in operating the tow behind broadcast sprayer such that too much or too little chemical may be applied. 1. -
Page 30: Limited Warranty
If this product has materials or workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. Your rights under this warranty are in addition to any other rights you have under the Australian Consumer Law or other applicable laws.
