- Page 1 Hand-operated Knapsack Sprayer Part No K16015 User Manual...
- Page 2 Part Descriptions and Technical Parameters Type: Knapsack Volume of Tank: Operating Pressure: 0.2~0.4Mpa Operating Stroke: 50mm Dia. of Leather Cup: 45mm Net Weight of the Whole Unit: 3.25Kg Overall Size: 355 x 210 x 520mm...
-
Page 3: Operating Instructions
Hazards • You are required to read this Manual and follow WARNING: the instructions on operation and safety for • People affected by fatigue, poor health, injury, purpose of proper operation. pesticide allergy or during pregnancy should • The operator should wear a mask, hat, protective never dispense pesticides. - Page 4 Structural Diagram and Details...
- Page 5 S/N Part Description S/N Part Description Cone Nozzle Tank Lid Nozzle Cap Tank Seal Ring Cone Sprinkle Sheet Big Strainer Split Sheet Spray Tank Seal Gasket ø16 x ø11 x2 O-ring ø50 x 4 Elbow Air Chamber Assembly Spray Boom O-ring ø29 x 3.6 Spray Boom Nut Tap Screw 4 x 8...
-
Page 6: Cleaning And Maintenance
Cleaning and Maintenance • After use, clean and wash the sprayer. Clean the spray gun with high-pressure injection of air till the spray is clear. • Lubricate the spraying parts after cleaning Storage • The sprayer should be stored indoors, in a dry place, out of reach of children Troubleshooting Problems... - Page 7 Packing List Description Unit Qty S/N Remarks Main Unit of Sprayer Operating Instructions Seal Ring Leather Cup Pc(s) Fastening Sleeve Pc(s) Inner Hex Wrench Pc(s)
