Installation Instructions and Wiring Diagram for ESV (24V)
Rev 01222019 © 2020 Melbourne Cricket
1
Advertisement
Table of Contents
Related Manuals for Cricket ESV
Summary of Contents for Cricket ESV
- Page 1 Remote Control Installation Instructions and Wiring Diagram for ESV (24V) Rev 01222019 © 2020 Melbourne Cricket...
- Page 2 Cart. Stop pressing “B” to stop the Cart’s movement. 8. Once you are done loading or unloading the cart press “C” to turn off the Remote Control system. 9. Set the Remote Control Enable Switch to “OFF”. Rev 01222019 © 2020 Melbourne Cricket...
- Page 3 Cricket Remote Control Installation Remote Control Kit Remote Control Radio and Remote Rev 01222019 © 2020 Melbourne Cricket...
- Page 4 Cricket Remote Control Installation Wire Harness #1 (WH1) Wire Harness #2 (WH2) Rev 01222019 © 2020 Melbourne Cricket...
- Page 5 Remote Control Installation Wiring Diagram Purple Green White Freewheel Electronic Switch *See Appendix A for Crickets without the Freewheel Switch. Negative Battery Terminal Pin 13 Pin 2 Controller Legend Existing Wires New Wires Rev 01222019 © 2020 Melbourne Cricket...
- Page 6 5. At the Controller locate the Red and Black cables shown in the diagram and disconnect them from the Controller. 6. Connect the Blue cable from WH1 to the Freewheel Electronic Switch as shown in the diagram. Cricket Carts that do not have this switch see Appendix A 7.
- Page 7 14. Splice the Purple cable on WH2 to the Cart end of the Green cable you cut in Step 11. 15. Splice the Green cable on WH2 to the Controller end of the Green cable you cut in Step 11. Rev 01222019 © 2020 Melbourne Cricket...
- Page 8 Controller Tray. 21. Connect the Remote Control Enable Switch making note of the cable you marked so it’s connected the same way. Rev 01222019 © 2020 Melbourne Cricket...
- Page 9 “On”. 27. Press the “B” button on the Remote Control and your cart should start to slowly move forward. 28. Replace U-Shaped brackets removed in Step 4. 29. Replace the Controller Tray Cover. Rev 01222019 © 2020 Melbourne Cricket...
- Page 10 Cricket Remote Control Installation Appendix A For Older Cricket Carts that DO NOT have the Freewheel Electronic Brake release switch follow these steps. A. Locate the Blue cable going to pin 15 on the sixteen-pin connector going to the controller.
