- Page 1 Remote Control Installation Instructions and Wiring Diagram for RX5 and SX3 (36V) Rev 01222019 © 2020 Melbourne Cricket...
-
Page 2: Remote Control Operation
Cart. Stop pressing “B” to stop the Cart’s movement. 8. Once you are done loading or unloading the cart press “C” to turn off the Remote Control system. 9. Set the Remote Control Enable Switch to “OFF”. Rev 01222019 © 2020 Melbourne Cricket... - Page 3 Cricket Remote Control Installation Remote Control Kit Remote Control Radio and Remote Rev 01222019 © 2020 Melbourne Cricket...
- Page 4 Cricket Remote Control Installation Wire Harness #1 (WH1) Wire Harness #2 (WH2) Rev 01222019 © 2020 Melbourne Cricket...
- Page 5 Remote Control Installation Wiring Diagram Legend Existing Wires New Wires Purple Green White Freewheel Electronic (Right) (Left) Switch* *See Appendix A for Crickets without the Freewheel Switch. Negative Battery Terminal Pin 13 Pin 2 36v Controller Yellow Solenoid Rev 01222019 © 2020 Melbourne Cricket...
- Page 6 3. At the Controller locate the Black cable shown in the diagram and disconnect it from the Controller. 4. Connect the Blue cable from WH1 to the Freewheel Electronic Switch as shown in the diagram. Cricket Carts that do not have this switch see Appendix A 5.
- Page 7 10. Splice the Purple cable on WH2 to the Cart end of the Green cable you cut in Step 11. 11. Splice the Green cable on WH2 to the Controller end of the Green cable you cut in Step 11. Rev 01222019 © 2020 Melbourne Cricket...
- Page 8 15. Connect the Remote Control Enable Switch making note of the cable you marked so it’s connected the same way. 16. Connect the Black wire from WH2 and the Black wire removed from the Controller back to the negative terminal per the wiring diagram. Rev 01222019 © 2020 Melbourne Cricket...
- Page 9 “On”. 20. Press the “B” button on the Remote Control and your cart should start to slowly move forward. 21. Replace U-Shaped brackets removed in Step 4. 22. Replace the Controller Tray Cover. Rev 01222019 © 2020 Melbourne Cricket...
- Page 10 Cricket Remote Control Installation Appendix A For Older Cricket Carts that DO NOT have the Freewheel Electronic Brake release switch follow these steps. A. Locate the Blue cable going to pin 15 on the sixteen-pin connector going to the controller.
