BEBEHUT®
Voyager User Manual
i-Size universal child restraint system
40 – 105 cm
approx. age 0 - 4 years

Advertisement

loading
Need help?

Need help?

Do you have a question about the Voyager and is the answer not in the manual?

Questions and answers

Related Manuals for Bebehut Voyager

Summary of Contents for Bebehut Voyager

  • Page 1 BEBEHUT® Voyager User Manual i-Size universal child restraint system 40 – 105 cm approx. age 0 - 4 years...
  • Page 2 i-Size universal ISOFIX (40-105cm, ≤18kg): ISOFIX + support leg + 5-point harness NOTICE  This is an i-Size Enhanced Child Restraint System. It is approved according to UN Regulation No. 129, for use in, i-Size compatible vehicle seating positions as indicated by vehicle manufacturers in the vehicle users' manual.
  • Page 3 1 APPLICABLE USAGE IN VEHICLE This child car seat is designed for child within 40 – 105 cm. It should be installed in the following way: Child height Installation direction Installation Category 40-105 cm Rearward facing ISOFIX + support leg + 5- i-Size universal point harness ISOFIX...
  • Page 4 2 WARNING Please carefully read through the manual, operate accordingly and keep the manual in the pocket of child seat back for future use. Treatment for the protection of child and other passengers.  This product is designed solely for the use in vehicle. DO NOT use it in other places (like home). ...

  • Page 5: Product Specification

    3 PRODUCT SPECIFICATION Seat Body Seat base...

  • Page 6: Installation And Adjustment

    4 Installation and adjustment 4.1 Seat base installation 1. Check the ISOFIX anchorage on the vehicle. Mount 2 ISOFIX guides to the anchorage. Please refer to the vehicle handbook provided by the car manufacture for the configuration of ISOFIX. 2. Open support maximum angle with a CLICK sound.
  • Page 7 4.2 Seat body installation/release 1. To release seat body, push forward the release button on the base. Hold the harness belt to lift up seat body. 2. To lock the seat body, aim at the hook and push down seat body. The seat body is completely locked when the indicator next to button turns green.

  • Page 8: Seat Adjustment

    4.3 Seat adjustment Notice: When incline is used, the child car seat may not fit in some types of vehicles due to dimension change. 1. To adjust support leg, hold the support leg adjuster and pull down the lower half part of the support leg.
  • Page 9 5. For forward facing (76-105cm, <18kg) installation, there are 5 incline positions, i.e., position 1, 2, 3, 4, 5. rearward facing (40- 105cm, <18kg) installation, there are only one incline position (position A). Please refer to the incline mark on both side of the child car seat when choosing incline position.
  • Page 10 2. There are 3 kinds of removable accessories: baby head support, baby pad and wedge cushion. Child under 76 cm must use all 3 accessories together. Child between 76 and 87 cm must use baby pad and wedge cushion together. Child between 87 and 105 cm should not use 3 accessories mentioned above.

  • Page 11: Care And Cleaning

    5 CARE AND CLEANING  Regularly check important parts for malfunction. Make sure mechanical components are always working properly.  DO NOT let any parts of the child car seat be stuck by vehicle door, vehicle seat frame or other object.
