D50K PLANETARY AUGER DRIVE
SERVICE AND REPAIR MANUAL

Example Part Number

50
05
2
1
F
54
Motor
Motor
Model
Ratio
Shaft
Bail Boss
Supplier
Number
THIS SERVICE MANUAL IS EFFECTIVE
FROM: ..... S/N 58670, SEPT. 2003
TO:........... CURRENT
REF: ........ SMD50K-BA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D50K and is the answer not in the manual?

Questions and answers

Related Manuals for Eskridge D50K

Summary of Contents for Eskridge D50K

  • Page 1: Example Part Number

    D50K PLANETARY AUGER DRIVE SERVICE AND REPAIR MANUAL Example Part Number Motor Motor Model Ratio Shaft Bail Boss Supplier Number THIS SERVICE MANUAL IS EFFECTIVE FROM: ..S/N 58670, SEPT. 2003 TO:... CURRENT REF: ..SMD50K-BA...

  • Page 2: Table Of Contents

    Secondary Planet Carrier Subassembly ..............4 Base Subassembly....................... 4 Unit Reassembly ......................5 Single Stage Exploded View Drawing ................ 6 Double Stage Exploded View Drawing ............... 7 Eskridge Product Warranty ..................8 Warranty Return Policy..................8 Other Eskridge Products ..................... 9...

  • Page 3: Unit Disassembly Procedure

    Unit Disassembly Procedure *Primary Planet Carrier Subassembly There are two types of model D50 units: single planetaries without a primary carrier and double planetaries with a primary planet car- rier. Steps with an asterisk (*) apply only to the double planetary model.

  • Page 4: Secondary Planet Carrier Subassembly

    Inspect inner and outer bearing cups (20 & 21). If cups are damaged, the cups and base (1) may need replacement. Contact Eskridge if you have questions. CAUTION: Care should be taken not to injure feet or damage output shaft during this procedure.

  • Page 5: Unit Reassembly

    Install secondary carrier assembly into unit. Carrier assembly Unit Reassembly should be installed with hub side down (24 tooth spline). Rotate carrier assembly back and forth to mesh secondary Start with base (1). Turn base upside down and position on planet gear teeth (7) with ring gear (2) teeth.

  • Page 6: Single Stage Exploded View Drawing

    Single Stage Exploded View Drawing MODEL D50 WITH INTEGRAL BAIL SINGLE PLANETARY EFFECTIVE 5.05:1 FROM: S/N 58670 09-01-03 5.05:1 TO: (CURRENT) RATIO DESCRIPTION PART NUMBER ITEM QTY. BASE 50-004-3303 RING GEAR 50-004-1033 COVER / BAIL ASSEMBLY 1" BAIL BOSSES 50-005-2142 COVER / BAIL ASSEMBLY 1-1/4"...

  • Page 7: Double Stage Exploded View Drawing

    Double Stage Exploded View Drawing...

  • Page 8: Eskridge Product Warranty

    Units. The foregoing warranty is the sole warranty made by Eskridge with respect to any Units and is in lieu of any and all other warranties, expressed or implied. There are no warranties which extend beyond the description on the face hereof without limiting the generality of the foregoing, Eskridge expressly disclaims any implied warranty of merchantability or fitness for any particular purpose, regardless of any knowledge Eskridge may have of any particular use or application intended by the purchaser.

  • Page 9: Other Eskridge Products

    OTHER ESKRIDGE PRODUCTS Planetary Gear Drives TORQUE RATING (IN-LB) SERIES MODELS MAX. INTERMITTENT 20B, 20P, 20LB, 20LP 20,000 28B, 28P, 28M, 28LB, 28LP 50,000 50K/L, 50LG, 50N 50,000 60B, 60E, 60L 60,000 100E 100,000 105E 100,000 130,000 150,000 250K/L, 251K/L, 252K/L, 253K/L...

This manual is also suitable for:

D50

Table of Contents
