Eskridge 600 Service Manual

Double planetary spindle drive
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
MODEL 600 DOUBLE PLANETARY
SPINDLE DRIVE SERVICE MANUAL
WARNING: While working on this equipment, use safe lifting procedures,
!
wear adequate clothing and wear hearing, eye and respiratory protection.
THIS SERVICE MANUAL IS EFFECTIVE:
S/N:25000 TO CURRENT
DATE:02/01/1996 TO CURRENT
VERSION: SM600LS2-AG
NOTE: Individual customer specifications (mounting
case, output shaft, brake assembly, etc.) may vary from
exploded drawing and standard part numbers shown.
If applicable, refer to customer drawing for details.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 600 and is the answer not in the manual?

Questions and answers

Related Manuals for Eskridge 600

Summary of Contents for Eskridge 600

  • Page 1 MODEL 600 DOUBLE PLANETARY SPINDLE DRIVE SERVICE MANUAL WARNING: While working on this equipment, use safe lifting procedures, wear adequate clothing and wear hearing, eye and respiratory protection. THIS SERVICE MANUAL IS EFFECTIVE: NOTE: Individual customer specifications (mounting case, output shaft, brake assembly, etc.) may vary from S/N:25000 TO CURRENT exploded drawing and standard part numbers shown.
  • Page 2 CURRENT UNIT (SHOWN ON THIS DRAWING) EQUIPPED WITH PATENTED "LOAD-N-LOCK" SHAFT RETENTION SYSTEM (U.S. PATENT NO.5746517). X600LS2-AD, Page 1 of 2 Effective date 07/01/2007 Effective serial # 74362 Model 600 Spindle Drive service manual, SM600LS2-AG Page 1 Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com...
  • Page 3 CODE S - SPINDLE STUDS PIPE PLUG (1/4 NPT) 01-207-0020 01-207-0020 01-207-0020 01-207-0020 01-207-0020 01-207-0020 01-207-0020 X600LS2-AD Page 2 of 2 Effective date 07/01/2007 Effective serial # 74362 Model 600 Spindle Drive service manual, SM600LS2-AG Page 2 Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com...
  • Page 4 Note: All standard Eskridge Geardrives are issued a descriptive part number which includes information regarding the Model, means of shaft retention, base style, shaft style, input mounting, input shaft size, overall ratio and vari- ous available options. For a detailed breakdown of this information, please refer to Eskridge product specification sheets found at: http://www.eskridgeinc.com/geardrives/gearprodspecs.html Model 600 Spindle Drive service manual, SM600LS2-AG Page 3 Eskridge, Inc.
  • Page 5 (25). Remove the split ring segments (35) and shims (15). All subassembly service or repairs should be com- plete at this time. Continue to Unit Assembly to com- Model 600 Spindle Drive service manual, SM600LS2-AG Page 4 Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com...

  • Page 6: Unit Reassembly

    (31, 2ea; 30, 1ea) Refer to exploded view for details. Noting the scribed line made during disassembly, (with lubri- cated o-ring in place) align and install the cover (2). Model 600 Spindle Drive service manual, SM600LS2-AG Page 5 Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com...
  • Page 7 3 - Housing Retainer Lip 8 - Seal Ring Retaining Lip 4 - Housing Ramp 9 - Installation Tool (Optional) 5 - Seal Ring Housing (Base/Shaft) Model 600 Spindle Drive service manual, SM600LS2-AG Page 6 Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com...
  • Page 8 When assembling metal face seals, please carefully observe assembly instructions. Model 600 Spindle Drive service manual, SM600LS2-AG Page 7 Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com...

  • Page 9: Installation Process
