SERVICE
COLOR TELEVISION
Refer to the service manual in the GSPN (see the rear cover) for the more information.
COLOR TELEVISION
Chassis : KSDA(P)_Uranus
Model : CS29Z45Z39XNWT
Manual
CS-29Z45Z3Q

CONTENTS

1. Precaution
3. Disassembly & Reassembly
5. Exploded View & Part List

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-29Z45Z3Q and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung CS-29Z45Z3Q

Summary of Contents for Samsung CS-29Z45Z3Q

  • Page 1 1. Precaution 2. Product Specification 3. Disassembly & Reassembly 4. Troubleshooting 5. Exploded View & Part List 6. Wiring Diagram 7. Schematic Diagram CS-29Z45Z3Q Refer to the service manual in the GSPN (see the rear cover) for the more information.
  • Page 2 Table of Contents 1. Precaution 1-1 Safety Precautions ..............................1-1 1-2 Servicing Precautions ..............................1-3 1-3 Static Electricity Precautions ............................1-4 1-4 Installation Precautions ...............................1-5 2. Product Specification 2-1 Product Specification ..............................2-1 2-2 Specifications Analysis ..............................2-2 2-3 Accessories .................................2-3 3. Disassembly & Reassembly 3-1 Overall Disassembly &...
  • Page 3 These two grounding systems are separated in the circuit using an unbreakable/unchangeable insulation material. 8. When any parts, material or wiring appear overheated or damaged, replace them with new regular ones immediately. When any damage or overheating is detected, correct this immediately and make a regular check of possible errors. Samsung Electronics...
  • Page 4 Critical safety parts should be bracketed with ( , ). Use only regular parts for replacements (in particular, flame resistance and dielectric strength specifications). Irregular parts or materials may cause electric shock or fire. Samsung Electronics...
  • Page 5 The ground lead of the tester should be removed last. 9. Beware of risks of any current leakage coming into contact with the high-capacity capacitor. 10. The sharp edges of the metal material may cause physical damage, so protect yourself by wearing gloves during the repair. Samsung Electronics...
  • Page 6 These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Samsung Electronics...
  • Page 7 6. Keep the antenna far away from any high-voltage cables and install it firmly. Contact with the high-voltage cable or the antenna falling over may cause fire or electric shock. 7. Check the basics of the screen test. - Image position/size, Tilt adjustment, Actuator activation . Samsung Electronics...
  • Page 8 MEMO Samsung Electronics...
  • Page 9 Output : 10W x 2 TDA7297SA Cabinet 29Z50 Cabinet Z50 Cabinet Specification Model CS-29Z50M19XXSV Screen Size 29” Dimensions (WxHxD) 773 x 423.5 x 604 mm Weight 40.4 kg CIS: AC 160~300V Voltage S.E.Asia: 100~240V Speaker Output 10W + 10W Samsung Electronics...
  • Page 10 Rear:1, Side 1 Rear:1, Side 1 S-Video Y/Pb/Pr Rear:1 Rear:1 Ports HDMI Digital Audio Out Video Out Rear:1 Rear:1 TM86 Remote Controller TM85 ※ For the power supply and power consumption, refer to the label attached to the product. Samsung Electronics...
  • Page 11 2-3-1 Supplied Accessories Accessories Item Item code Remark Remote Control AA59-00421A Batteries 4301-000121 Power Cord AA39-10006X Samsung Service center Owner’s Instructions AA68-03967C Warranty Card AA68-03724B Registration Card Safety Guide Manual AA68-03242K 2-3-2 Accessories that can be purchased additionally Accessories Item...
  • Page 12 MEMO Samsung Electronics...
  • Page 13 Since there is a danger of injury from the remaining current and of damaging the product due to static electricity, make sure to remove the power cord and wait for a moment so that the remaining current is discharged completely before disassembling the product. Samsung Electronics...
  • Page 14 Pull the chassis while pushing the clip fixing the Front Cabinet and the Holder Chassis. ① Separate the CRT Ass’y from the CRT. ② Separate the TBC wire, GND cables from the CRT Ass’y sequentially. Samsung Electronics...
  • Page 15 Take care when separating the wires because pulling the wires by force may damage the socket. In addition, separate the wires on a flat and clean surface so as to prevent scratching of the material and the PCB. Samsung Electronics...
  • Page 16 MEMO Samsung Electronics...
  • Page 17 ② Check that the Master Switch has been pressed. ③ Ch eck that the transmitter is turned on. ④ Check that transmitter device selection is set to TV. ⑤ Check that the signal cable is properly connected. ⑥ Check that channel setting has been set. Samsung Electronics...
  • Page 18 AV item is grayed out, you cannot select an A/V channel. Check if the connector is properly connected. Check if the menu is grayed out. If a menu is grayed out, it cannot be Cannot select a menu. selected. Samsung Electronics...
  • Page 19 The sound is very low. ■ Set the auto volume control to ON. There is a lot of noise. Keep the antenna away from the power cord or connectors if possible. The selected language does not appear. Press the Multiplex button to select the TV. Samsung Electronics...
  • Page 20 This noise may occur when the plastic material inside the TV expands or The TV makes a noise as if something is dropping contracts according to the seasonal temperature or humidity. This is like the inside. noise from a furniture/cabinet/sink unit, and there is no need for concern. Samsung Electronics...
  • Page 21 Therefore, you can determine whether the software has been properly downloaded, if you know the correct checksum for that version of the software. You can check the checksum according in the following order. Factory Mode → Checksum → Enter → Output Checksum (e.g. 0xab2b) ■ Checksum Examples T-MA1PEAN-1001.1 checksum=9E1F Samsung Electronics...
  • Page 22 Board. the cable from the Connect the cable Main Board th the CRT Ass’y properly innected? SOUND IC TUNER MICOM 1 CHIP IC SCART JACK VERTICAL IC OUTPUT TR Q401 BRIDGE DIODE SMPS-IC DY-JACK MAIN TRANS EW DRIVER Samsung Electronics...
  • Page 23 Is the power cord or the master switch out of order? Check the others part Check the “D801S” #1 Check the FUSE “LP801S” Check the IC801S #1 5Q0765R Change “LP801S” Change “D801S” Change “IC801S” Complete FD801S FP801S D801S SOUND IC D809A SMPS POWER IC Samsung Electronics...
  • Page 24 2. No Sound - when the power is normal No sound (1st power OK) Check the +14V line Check IC802S Check D809A Check FD801A Change IC602 Change FD801A Change D809A Complete FD801S SOUND IC MICOM CHIP IC D809A Samsung Electronics...
  • Page 25 Check the others B+ line T444 B+ Pin #3 “D811”(D811A) Check D407 CHECK CRT ASS`Y open and check Open and check Change the “D811” (D811A) Check the “Q401” Change D407 Change the “Q401” Complete MAIN TRANS D811 D407 OUTPUT TR Q401 Samsung Electronics...
  • Page 26 If there is no signal measured even though the RF signal received by the external antenna is input to the Main Board Tuner. - Supplied Power: 5V, 8V, 33V - RF Trouble Check: Check CVBS output - AUDIO Trouble Check: Check SiF Signal output B+33V B+5V TP06 TP05 4-10 Samsung Electronics...
  • Page 27 - Input Problem Check: Check the connecting jacks. - Output Problem Check: Check the UOC TOP IC EXT2/Monitor Out AUDIO 1 IN VIDEO 1 IN AUDIO 1 OUT AUDIO 2 IN TV OUT VIDEO 2 IN AUDIO 2 OUT EXT1 MONITOR OUT TP05 Samsung Electronics 4-11...
  • Page 28 Troubleshooting 3. TDA12156 Diagnosis IF+MICOM+VIDEO 4-12 Samsung Electronics...
  • Page 29 Troubleshooting 4. LA42032 Diagnosis - Supplied Power: 14V - Input Problem Check: L/R - Output Problem Check: L+, L-, R+, R TP06 TP05 Samsung Electronics 4-13...
  • Page 30 If there are some ‘spotted’ points on the screen when displaying a black and white picture, degauss the screen using the degauss coil. If the spotted points remain, re-adjust the purity and the convergence. This completes the basic performance examination. 4-14 Samsung Electronics...
  • Page 31 280 ± 5 y: 290 ± 5 Y: 30 ± 3 White Balance White Balance (Standard Data) x :280 ± 5 y: 290 ± 5 Y: 1.5± 02 Toshiba Pattern Screen Voltage Same As S17A Chassis G2 Adjust Samsung Electronics 4-15...
  • Page 32 Turbo Effect LOW/High High Sound Mode India/Europe Europe 3. Hotel Option Item Selection Initial Data Hotel Mode On/Off Power On Channel 0~99 Power on volume 0~100 Max Volume 0~100 Pannel Button Lock On/Off Power On Source Off/TV/EXT1/EXT2 4-16 Samsung Electronics...
  • Page 33 Troubleshooting Samsung Electronics 4-17...
  • Page 34 Adjust R Drive Adjust G Drive B Drive Adjust Sub Bright Adjust Sub Contrast Adjust Bluescreen Contrast Adjust G2 Adjust Bright G2 Adjust AKB Option Cathode Drive Level G2 Adjust,W/B TTX Bright TTX RGB Bright TTX Position 4-18 Samsung Electronics...
  • Page 35 IF AGC Speed IF Demodulator Fast Filter IF PLL RF FOA/FOB VCR RF output AV FOA/FOB RF PAL Ident Sensitivit RF NTSC Ident Sensitivit AV PA/NT Ident Sensitivit DCXO Caps/NICAM Center DCXO Scaling Control Gain Threshold Sound 1 Carrier Samsung Electronics 4-19...
  • Page 36 RGB Blanking Mode Secam Blanking Wide Blanking Front Wide Blanking Rear ADCLEV Cut Offf Control Range 9. YC Delay Item Data Initial Data Remarks PAL Delay SECAM Delay NTSC Delay PAL AV Delay SECAM AV Delay NTSC AV Delay 4-20 Samsung Electronics...
  • Page 37 Ratio posi & Nega Peaks 0: 123 degree Dynamic Skin 1: 117 degree Gamma & White Stretch 0: No black level shift DC Transfer Ratio 1: black level shift 0: Japanese matrix NTSC Matrix 1: USA matrix Samsung Electronics 4-21...
  • Page 38 2. Press “Power Off → Info → Menu → Mute → Power On” using the remote control and enter Factory Mode. 3. Enter Deflection Mode. 4. Adjust the V-AMP, V-SHIFT, H-EW and H-SHIFT items so that the width becomes 92 and the height becomes 92. 4-22 Samsung Electronics...
  • Page 39 7. When the adjustments are complete, display the Lion pattern and check that the picture size has not been changed. If there is no change, finish the adjustments. Samsung Electronics 4-23...
  • Page 40 ■ Adjusting the Screen Voltage 1. Select: Power OFF Info Menu Mute POWER ON 2. Initialize all settings to the values appropriate to the corresponding model make sure the video adjust 1 is the factory date,just as the following picture. 4-24 Samsung Electronics...
  • Page 41 4. Beacause using the TR type, the power time longer,the H-light and L-light will be higher,so pls adjust the offset data by the different models so that they will become the final date we give out in the W/B table in the next page. Samsung Electronics 4-25...
  • Page 42 4. When the adjustment is finished, check the following checklist. - f there is a spot on the screen when turning the TV set off/on, adjust the Screen Voltage again. - f there is a ghost line on the screen, adjust the Screen Voltage again. 4-26 Samsung Electronics...
  • Page 43 MEMO Samsung Electronics 4-27...
  • Page 44 Exploded View & Part List 5. Exploded View & Part List 5-1 CS29Z45Z39XNWT Exploded View Samsung Electronics...
  • Page 45 ASSY POWER CORD -,CP2/NO,N(H/C500MM),KKP T0091 AA94-15869A ASSY PCB MISC-A/V CS29Z30ZQTXBWT,KS7C T0098 AA94-16470A ASSY PCB MISC-CONTROL URANUS,KSDA T0175 AA96-04765A ASSY SPEAKER P 8ohm,10W,900mm,600mm,200m T0175 AA96-02375A ASSY SPEAKER P 8ohm,3001-001535,15W,250m T0299 AA64-04408A WINDOW-RMC LED 29Z45,PC,CLEAR S.N.A T0607 AA61-40113A STOPPER-PCB 501H,HIPS,-,-,HB,NTR,- S.N.A Samsung Electronics...
  • Page 46 C-AL 2.2uF,10%,50V,GP,TP,5x11,5 2401-000649 C-AL 2.2uF,20%,50V,BP,TP,5x11,5 2401-000649 C-AL 2.2uF,20%,50V,BP,TP,5x11,5 2401-000649 C-AL 2.2uF,20%,50V,BP,TP,5x11,5 2401-000660 C-AL 2.2uF,20%,50V,GP,TP,5x11,5 2401-000703 C-AL 2200uF,20%,25V,GP,-,12.5x25mm, 2401-000703 C-AL 2200uF,20%,25V,GP,-,12.5x25mm, 2401-000832 C-AL 220uF,20%,25V,GP,TP,8x11.5,5 2401-000913 C-AL 22uF,20%,16V,GP,TP,5x11,5 2401-000962 C-AL 22uF,20%,50V,GP,TP,5x11,5 2401-001101 C-AL 330uF,20%,16V,GP,TP,8x11.5,5 2401-001101 C-AL 330uF,20%,16V,GP,TP,8x11.5,5 2401-001271 C-AL 4.7uF,20%,50V,GP,TP,5x11mm,5 Samsung Electronics...
  • Page 47 C-CER,CHIP 470nF,+80-20%,16V,Y5V,1608 C120 2203-002398 C-CER,CHIP 22nF,10%,50V,X7R,1608 C120 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 C120 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 C120 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 C120 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 C120 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 C120 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 C120 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C120 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 Samsung Electronics...
  • Page 48 TDQ-6L/125S,CTV,PAL HYPER,181CH,38 CN330 3711-002643 HEADER-BOARD TO CABLE BOX,4P,1R,2.5mm,ST CN330 3711-002646 HEADER-BOARD TO CABLE BOX,7P,1R,2.5mm,ST CN330 3711-002647 HEADER-BOARD TO CABLE BOX,8P,1R,2.5mm,ST CN330 3711-003043 HEADER-BOARD TO CABLE BOX,4P,1R,2.5MM,ST CN330 3711-003043 HEADER-BOARD TO CABLE BOX,4P,1R,2.5MM,ST CN330 3711-000577 HEADER-BOARD TO CABLE BOX,10P,1R,2.5MM,S Samsung Electronics...
  • Page 49 DIODE-ZENER MTZJ24B,22.75-23.73V,500mW,D DZ306 0403-000700 DIODE-ZENER TZP33A,5%,1000mW,DO-41,TP DZ401 0403-001319 DIODE-ZENER MTZJ4.7C,4.68-4.93V,500mW,DO DZ403 0403-000509 DIODE-ZENER MTZJ5.6B,5.4-5.7V,500mW,DO-3 DZ501 0403-001211 DIODE-ZENER MTZJ12B,11.8-12.3V,500mW,DO- DZ502 0403-001211 DIODE-ZENER MTZJ12B,11.8-12.3V,500mW,DO- DZ503 0403-001211 DIODE-ZENER MTZJ12B,11.8-12.3V,500mW,DO- DZ701 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500mW,DO DZ702 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500mW,DO DZ703 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500mW,DO Samsung Electronics...
  • Page 50 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY890 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY891 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY893 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H F101 2901-000297 FILTER-EMI ON BOARD -,3A,-,3.5x5mm,TP,- F101 2901-000297 FILTER-EMI ON BOARD -,3A,-,3.5x5mm,TP,- F101 2901-000297 FILTER-EMI ON BOARD -,3A,-,3.5x5mm,TP,- F101 2901-000299 FILTER-EMI ON BOARD -,6A,UL/CSA,-,9x7.5, Samsung Electronics...
  • Page 51 WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J247 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J248 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J253 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J254 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J255 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J278 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* J279 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* Samsung Electronics...
  • Page 52 WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD137 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD138 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD139 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD141 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD142 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD143 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD144 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* Samsung Electronics...
  • Page 53 WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD222 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD223 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD224 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD225 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD226 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD227 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* JD228 BH39-40305U WIRE HARNESS-JUMPER 52MM,330UF,+-20%,25* Samsung Electronics 5-10...
  • Page 54 4.7UH,10%,2534 L808 2701-001030 INDUCTOR-AXIAL 43UH,10%,4514 LD201 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 LD202 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 LD203 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 LD204 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 LD206 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 LD207 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 LD209 2701-000106 INDUCTOR-AXIAL 1.5UH,10%,3070 LD210 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 5-11 Samsung Electronics...
  • Page 55 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R110 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 Samsung Electronics 5-12...
  • Page 56 82Kohm,5%,1/10W,TP,1608 R110 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 R110 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 R110 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 R110 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 R110 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 R110 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 R110 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 R110 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 R110 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 5-13 Samsung Electronics...
  • Page 57 390ohm,5%,2W,AF,TP,3.9x R401 2001-001072 R-CARBON(S) 12OHM,5%,1/2W,AA,TP,2.4X6.4M R402 2001-001070 R-CARBON(S) 120OHM,5%,1/2W,AA,TP,2.4X6.4 R404 2001-001114 R-CARBON(S) 270OHM,5%,1/2W,AA,TP,2.4X6.4 R405 2001-000020 R-CARBON(S) 22OHM,5%,1/2W,AA,TP,2.4X6.4M R408 2004-001390 R-METAL(S) 1Kohm,2%,1/2W,AA,TP,2.4x6.4mm R409 2001-001168 R-CARBON(S) 6.8KOHM,5%,1/2W,AA,TP,2.4X6. R410 2001-000009 R-CARBON 20KOHM,5%,1/8W,AA,TP,1.8X3.2MM R413 2008-000206 R-FUSIBLE(S) 1ohm,5%,1/2W,AF,TP,2.5x6.5m R414 2008-000206 R-FUSIBLE(S) 1ohm,5%,1/2W,AF,TP,2.5x6.5m Samsung Electronics 5-14...
  • Page 58 R927 2001-000793 R-CARBON 47OHM,5%,1/8W,AA,TP,1.8X3.2MM RA815 2001-000003 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm RA816 2001-001178 R-CARBON(S) 680OHM,5%,1/2W,AA,TP,2.4X6.4 RB426 2003-000540 R-METAL OXIDE(S) 1Kohm,5%,2W,AF,TP,4x12m RD207A 2001-000083 R-CARBON 82Kohm,5%,1/8W,AA,TP,1.8x3.2mm RD208A 2001-000273 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM RD210 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM RD217 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM RD222 2001-000702 R-CARBON 39KOHM,5%,1/8W,AA,TP,1.8X3.2MM 5-15 Samsung Electronics...
  • Page 59 29 CIS S.N.A T0900 1404-001045 THERMISTOR-NTC 4.7ohm,4.565A,2900K,-,-,- T401 AA26-50001M TRANS-H.DRIVE -,-,-,80mH,-,-,520uH,-,-,- T444 AA26-00289A TRANS FBT FQH29A003,SHREK2,3.48mH,U4277, T801S AA26-00217B TRANS SWITCHING EER4950,CS25M20EQ KS7A,A V999S 3704-001197 SOCKET-CRT 8P+SEN,29PI,22.5PI,NI+SN,- VX801S 1405-000187 VARISTOR 615Vdc,1250A,12.5x7mm,TP XD201 2801-003316 CRYSTAL-UNIT 24.576MHz,30ppm,28-AAM,20pF 0502-001007 TR-POWER KSC2073-H2,NPN,25W,TO-220,ST,6 Samsung Electronics 5-16...
  • Page 60 8ohm,10W,900mm,600mm,200m T0382 BP61-00509C HOLDER-CARE PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A T0057 AA64-04422A LOGO-BADGE Z50,AL,1.2,2.0g,65mm,LEAD 3,S S.N.A T0175 AA96-02375A ASSY SPEAKER P 8ohm,3001-001535,15W,250m T0382 BP61-00495C HOLDER-CARE PJT,ACRYL-FOAM,T0.25,W30.0mm 0.32 S.N.A ASSY FIXING T0892 AA91-11191A ASSY FIXING CS29Z45Z39XNWT,KSDA S.N.A T0121 3301-001201 CORE-FERRITE AE,21x11x32mm,1500,280G 5-17 Samsung Electronics...
  • Page 61 MANUAL FLYER-02,SAFETY GUIDE comm,Samsun S.N.A T0238 AA68-03724B MANUAL FLYER-WARRANTY CARD comm,Samsung, S.N.A AA68-03777A MANUAL USERS-CARD,06 comm,Samsung,Englis S.N.A T0511 AA68-03967A MANUAL USERS COMM,SAMSUNG,RUS,CIS,W/P 80 S.N.A T0511 AA68-03967C MANUAL USERS COMM,SAMSUNG,ENG,CIS,W/P 80 S.N.A T0511 AA68-03967B MANUAL USERS COMM,SAMSUNG,UKR,CIS,W/P 80 S.N.A Samsung Electronics 5-18...
  • Page 62 MEMO 5-19 Samsung Electronics...
  • Page 63 Wiring Diagram 6. Wiring Diagram 6-1 Overall Wiring Signal Signal Samsung Electronics...
  • Page 64 Wiring Diagram ※ The code number of cable(Lead-connector) can be changed, see “5. Exploded View & Part List.” ① CRT Board ↔ Main Board ② Power Code ③ Speaker Wire Code AA39-00422A AA96-20109D AA96-04765A Photo ④ AV Wire Code AA39-20068J/ AA39-20070B Photo Samsung Electronics...
  • Page 65 Wiring Diagram 6-2 Pin Connection MAIN CNA501 CN902 KEY1 S-Y-OUT TO CRT TO CONTROL KEY2 CN702A TO S-VIDEO S-C-OUT S-Y-IN CNA502 S-C-IN TO CRT CN601 CN701 200V TO SPK TO AV SCART CNA503 TO MAIN 200V Samsung Electronics...
  • Page 66 CRT Board connect AV connect Pin No. Pin Name Pin No. Pin Name CNA502 CRT Board connect Pin No. Pin Name CN702A Side-AV connect Pin No. Pin Name S-Y-OUT 200V S-C-OUT CN601 Speaker connect S-Y-IN Pin No. Pin Name S-C-IN Samsung Electronics...
  • Page 67 6-2-2 Connector role Loc. No. Description CNA501 Main Board and CRT Board connect CNA502 Main Board and CRT Board connect CN601 Main Board and Speaker connect CN701 Main Board and Side-AV connect CN702A Main Board and Side-AV connect Samsung Electronics...
  • Page 68 MEMO Samsung Electronics...
  • Page 69 Schematic Diagram 7. Schematic Diagram 7-1 Circuit Description 7-1-1 Overall Block Description Samsung Electronics...
  • Page 70 Schematic Diagram 7-1-2 Power Signal Samsung Electronics...
  • Page 71 Schematic Diagram 7-1-3 Partial Block Diagram 1. Main Block Description Samsung Electronics...
  • Page 72 MEMO Samsung Electronics...
  • Page 73 Schematic Diagram 7-2 Schematic Diagram 7-2-1 Main Board This Document can not be used without Samsung’s authorization. Power Video Audio Samsung Electronics...
  • Page 74 Schematic Diagram 7-2-2 Sound This Document can not be used without Samsung’s authorization. Power Video TP05 Audio TP06 TP06 TP05 Samsung Electronics...
  • Page 75 Schematic Diagram 7-2-3 Power This Document can not be used without Samsung’s authorization. Power Video TP02 Audio TP02 Samsung Electronics...
  • Page 76 Schematic Diagram 7-2-4 CRT, PIP Module This Document can not be used without Samsung’s authorization. Power Video Audio Samsung Electronics...
