- Page 1 INSTALLATION MANUAL...
- Page 2 Congratulations on your purchase of a Power-Pole shallow water anchor featuring ® C-Monster Control System. It has been designed, engineered, and manufactured to provide the best possible performance and dependability. Please read all installation instructions carefully. The information contained here describes the proper procedures for safely installing your Power-Pole shallow water anchor.
- Page 3 2. While holding the Power-Pole anchor in place, turn and tilt the motor as far as possible toward the unit. With the motor turned toward the unit, manually move the anchor through its entire range of motion to verify clearance.
- Page 4 STEP Hydraulic Pump Unit (HPU) Step 3: Hydraulic Pump Unit (HP Choose a mounting location 1. Locate a dry compartment in the vessel with ample space to accommodate the HPU. The footprint of the HPU is approximately 6.5”x 7”. NOTE: Be sure to allow enough clearance surrounding the HPU such that the hydraulic tubing will not make a severe bend when exiting the compartment.
- Page 5 FIG. 13 Figure 11 Figure 12 WARNING: The nuts must be tightened down far enough so that none of the compression fitting’s threads are visible, failure to tighten completely may cause hydraulic failure. ( FIG. 14 Figure 13 Figure 14 www.power-pole.com...
- Page 6 Each anchor is preprogrammed as a single unit. When using only one anchor do not program as a port or starboard. LED Light 1. Determine which HPU controls the starboard side Power-Pole anchor using the UP & DOWN buttons on both HPUs. ( FIG. 16 2.
- Page 7 STEP Pairing Dual Units To A Single Wireless Controller NOTE: The Power-Pole anchor comes paired to the included Dash Switch and Key Fob remotes. When Program Button installing dual anchors, you can program a single Dash Switch and/or Key Fob remote to control both...
- Page 8 CAUTION: Do not use the Power-Pole shallow water anchor as your primary anchorage. Never leave your boat unattended while anchored solely with the Power-Pole shallow water anchor. US Pat No. 6,041,730 Need help? Contact our Technical Support Team at 1 + 813.689.9932 option 2...
