- Page 1 floor heating Power supply unit AP 100 E-NERGY CARBON system systems modern floor heating Installation instructions...
-
Page 2: Table Of Contents
Contents General information and safety instructions 1.1 Scope of delivery 1.2 Overview 1.3 Safety Instructions Installation instructions 2.1 Introduction Assembly 2.2 Assembly 2.3 Mains voltage connection 2.4 Connection of the heating circuits 2.5 Temperature sensor 2.6 Commissioning 2.7 Adjusting the temperature sensor Technical data... -
Page 3: General Information And Safety Instructions
1. General information and safety instructions The E-NERGY CARBON AP 100 power supply unit is referred to as a device in the instructions. The unit is intended for independent temperature control of wall sections. The unit uses an external temperature sensor to regulate the surface temperature to 16 °C to prevent the formation of mould. -
Page 4: Overview
1.2. Overview E-NERGY CARBON power supply AP 100 (see Figure 1) Power supply cable 1 m Temperature sensor 2.5 m Secondary connection 1 m (heating track connection) Housing Power supply unit LED operation display Green = Standby Yellow = heating operation... -
Page 5: Safety Instructions
1.3. Safety Instructions • Please read this manual carefully and completely before starting the installation. • Transport: To protect all parts from damage, they should be transported to the installation site in the remain in their original packaging. Internal parts can be damaged by shock and fall. •... -
Page 6: Installation Instructions
2. Installation instructions for the E-NERGY CARBON Power Supply AP 100 2.1. Introduction Installation When planning your system, remember that you operate the device with the pre-assembled mains connection cable (Fig.: 1, A) at a normal shockproof socket. The heating control unit is prepared for this operating mode when delivered. -
Page 7: Mains Voltage Connection
2.3 Mains voltage connection The following specifications must be observed for connection to the power supply system. Supply voltage 230-240 VAC, 50/60 Hz 2.4 Connection heating circuits Please note the following: After the heating tracks have been laid, the connecting cables can be connected to the secondary line of the unit. To do this, connect the connection lines of the heating tracks to the secondary line (see Fig.: 1 / C) of the unit in a junction box / flush-mounted box or in the cable duct. -
Page 8: Technical Data
186 x 123 x 41 mm Weight 1.6 kg LEAD FREE Im Einklang mit RoHS systems mfh systems GmbH Hager Feld 8 49191 Belm-Vehrte modern floor heating Germany Fon +49 (0) 54 06 | 699 95-10 Fax +49 (0) 54 06 | 699 95-90 mail@mfh-systems.com...
