- Page 1 Practical Multipurpose Utility Pump (PMUP) User Guide...
-
Page 2: Table Of Contents
Table of Contents PMUP – INTRODUCTION ....................3 PLUMBING YOUR PMUP ....................3 PHYSICAL INSTALLATION ....................4 POWER CONNECTION ..................... 5 CONTROLLING THE PMUP ....................6 NEPTUNE SYSTEMS LIMITED WARRANTY ............... 8... -
Page 3: Pmup - Introduction
Energy Bar 832 or a 1LINK module. An Apex and an EB832 -or- an Apex and 1LINK module are required. An optional 10’ / 3m extension cable is available; the Neptune Systems part number is CBL-DC24-EXT. PLUMBING YOUR PMUP The output tube of the PMUP is 3/8”... -
Page 4: Physical Installation
PMUP with 3/8–3/8” quick-disconnect & 3/8” tubing PMUP with 3/8–1/4” quick-disconnect & 1/4” tubing If 3/8” ID tubing is used, it is recommended that silicone tubing be used versus vinyl or polyethylene tubing. Silicone tubing will grip the PMUP’s output tube securely without the need for a clamp. -
Page 5: Power Connection
CAUTION: The PMUP is intended for use in relatively clean water. It must not be used in an area where sand or other debris could be drawn into the PMUP. If sand or other hard debris enters the pump, it may fail; this will not be covered under warranty. -
Page 6: Controlling The Pmup
The plug is keyed and will only fit in the DC24 port one way. The plug has a locking tab; this tab must point in the same direction as the face of the EB832 or 1LINK module. Insert the plug as shown: To remove the plug from the DC24 port, press down on the back of the locking tab, then pull it out. - Page 7 DC24 Output “A” on an EB832 DC24 Output “B” on an EB832 DC24 Output “A” on a 1LINK DC24 Output “B” on a 1LINK The above images show the default names of the DC24 “A” and “B” outputs. The middle number indicates the AquaBus address of the EB832 or 1LINK, and will vary from system to system.
-
Page 8: Neptune Systems Limited Warranty
1 year from the date of purchase. If repair or adjustment is necessary and has not been the result of abuse, Neptune Systems warrants this product to be free from defects in material and workmanship for a period of 1 year from the date of purchase. - Page 9 The symbols to the right mean that according to local laws and regulations your product should be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities. Some collection points accept products for free.
