- Page 1 CLK570L-00 CLK570L-00...
- Page 2 This risk is compounded if the rider does not wear an approved helmet and other safety gear. High Lifter urges that all approved safety gear be worn when riding an ATV and/or RUV as a driver or passenger.
-
Page 3: Parts Diagram
Parts Diagram CLK570L-00... - Page 4 ATV) 6) You will need to relocate the vent tube that is connected the front differential. It will interfere with the bracket and how it mounts. The vent tube is located on the left side of the ATV. CLK570L-00...
- Page 5 9) Once you have relocated the vent tube, connect the long bracket to the frame. 10) Using a 10x65mm hex bolt and the front medium spacer connect the bracket to the frame. 11) Place the front SS spacer on the outside of the shock mount on the end of the bolt. CLK570L-00...
- Page 6 14) Insert a 10x65mm hex bolt into the lift bracket, then place the front 4X spacer on the bolt then place the small front lift bracket on both bolts to the outside of the shock mount tabs. 15) Loosely connect the brackets with the 10mm lock nut. CLK570L-00...
- Page 7 18) Tighten all bolts, and then you can replace the inner fender. 19) Repeat these steps for opposite side. 20) Be sure that all lugs are torqued to factory specifications. 21) Place wheels back onto ATV and lower jack. CLK570L-00...
- Page 8 4) Insert the rear long lift bracket into the frame of the ATV. It needs to run on the backside of the shock mount tabs, to the rear of the ATV. 5) Insert a Rear 4Y spacer between the shock mount tabs. CLK570L-00...
- Page 9 7) Next insert a second 10mm x 65mm bolt through the bracket. Insert two 10mm washers onto the bolt then insert the bolt through the shock eye. 8) Place two 10mm washers on the other side of the shock eye onto the 10mm x 65mm bolt. CLK570L-00...
- Page 10 11) Place a rear 37J spacer between the two rear lift brackets and secure them with a 10mm x 65mm bolt and 10mm lock nut. 12) Repeat steps for the opposite side 13) Place wheels back on ATV and torque all lugs to factory specifications. CLK570L-00...
- Page 11 High Lifter Lifetime Warranty From the beginning, High Lifter has engineered and manufactured some of the toughest, most durable products on the market. That’s why this product comes with a Lifetime Warranty. It’s our promise that High Lifter will never let you down.
