- Page 2 Parts Diagram...
- Page 3 FRONT LIFT INSTALLATION *When referring to left and right positions during the installation process, it is from the seated position* 1. Place UTV transmission in park. Place jack under center of UTV front end and lift until front wheels clear the ground.
- Page 4 5. If you have an X4 model, insert the spacer (O) between the shock mount tabs. If you have an X2 model, insert and use spacer (81i) instead. Push the bolt through the spacer then slide the bolt through the lowest hole on the long lift bracket and out through the inner shock mount tab.
- Page 5 8. Next you will reconnect the top of the shock to the lift brackets. Slide a (10mm x 70mm bolt) through the third outer hole of the bracket and then place a small spacer (AA) over the threaded end of the bolt. 9.
- Page 6 REAR LIFT INSTALLATION 1. Place jack under the center of the UTV, just forward of where the rear drive shaft connects to the engine, and lift until the weight is off the suspension. Be careful to secure the UTV properly so it is stable on the jack.
- Page 7 6. Next you will need to insert a spacer (4X) between the shock mount tabs. Slide the bolt through the spacer and through the inner shock mount tab. 7. Place the other rear lift bracket (73O-L) to the outside of the inner shock mount tab and slide the bolt through.
- Page 8 9. Insert a spacer (73Q) in between the frame brackets and slide the bolt all the way through the other lift bracket. Loosely fasten it with a (10 mm lock nut). 10. Next you are going to connect the top end of the shock to the lift brackets. You will first slide a (12mm x 80mm bolt) through the lift bracket.
- Page 9 12. Fasten all the nuts tight and repeat steps for the opposite side. Note: The shock eye and spring may to appear to have tighter clearances now, but they do clear from contacting any other parts. 13. Place wheels back on UTV and torque lugs to factory specifications. LOGO PLATE INSTALLATION 1.
- Page 11 This risk is compounded if the rider does not wear an approved helmet and other safety gear. High Lifter urges that all approved safety gear be worn when riding an ATV and/or RUV as a driver or passenger.
- Page 12 High Lifter Lifetime Warranty From the beginning, High Lifter has engineered and manufactured some of the toughest, most durable products on the market. That’s why this product comes with a Lifetime Warranty. It’s our promise that High Lifter will never let you down.
