Summary of Contents for Smeg MWTK37L
- Page 1 Installation Instructions MWTK37L trim kit ENGLISH www.applico.co.nz...
- Page 2 PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE YOU BEGIN! 1. DIMENSIONS OF THE BUILT-IN CABINET 1) The dimensions of the cupboard should be as follows. Width : 570 mm Height : 430 mm Depth : at least 550 mm 2) There should be no rear panel on the cupboard behind the microwave oven. 3) There must be a gap of at least 40 mm between the wall and both the shelf and the back of the cupboard above.
- Page 3 INSTALLATION GUIDE 2. Identification of the fittings PARTS CODE PARTS NAME DESCRIPTION Q'TY 3510403200 BODY-KIT STS H/L 3511600320 DECORATOR-KIT 7125401211 SCREW TAPPING T2S FLT 4x12 MFZN 3510318700 BASE-KIT SBHG 3512102310 FOOT-BASE-KIT 7125401211 SCREW TAPPING T2S FLT 4x12 MFZN 7112401011 SCREW TAPPING T1 TRS 4x10 MFZN 3515103400 SPRING LOCK...
-
Page 4: Installation Procedure
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE YOU BEGIN! INSTALLATION PROCEDURE 1. Draw screw points of the base-kit4 using template-base0 on the bottom of cupboard. 2. Attach 4 foot-base-kit5 to the base- kit4 using flat screws6. 3. Drive 4 screws7 on the base-kit4 at the drawn points of the cupboard. - Page 5 INSTALLATION GUIDE 4. Draw points of the special screw using template *Lq/*Rw or ruler. And drive the special screw9. 5. Install microwave oven onto the base-kit4. 6. Install body-kit1: Insert 4 special screws9 into the spring-lock8 attached to the body-kit1. 7.
- Page 6 INSTALLATION GUIDE ADDITIONAL INFORMATION FOR FLUSH MOUNTING If the cavity is 600m wide and you wish to mount the trim-kit, you must affix two 15mm battens to the side walls at a distance of 20mm from the front edge of the cabinet, see diagram below. Mounting screws Section A CAVITY...
