Yellowtec m!ka Series Briefing Book

Hide thumbs

Advertisement

Quick Links

Download this manual
m!ka
briefing
book
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the m!ka Series and is the answer not in the manual?

Questions and answers

Related Manuals for Yellowtec m!ka Series

Summary of Contents for Yellowtec m!ka Series

  • Page 1 m!ka briefing book...
  • Page 2 Thank you for choosing Yellowtec products. Enjoy m!ka, the most exciting support system for microphones and monitors. m!ka is robust, sleek and flexible. All components are designed to fit with each other and can be combined in multiple ways. Check this Briefing Book to get initial infor­...
  • Page 3 Briefing Book Content m!ka Mic Arm m!ka Mic Arm TV m!ka Studiolight m!ka MMS PDM Kit m!ka Power Sting m!ka MMS Ceiling Mount m!ka Wall Mount m!ka MMS Monitor Mount m!ka EasyLift m!ka MMS Quick Fix m!ka MMS Cable Clamp m!ka MMS Safety Stop m!ka Bushing m!ka MMS Pole Adapter...
  • Page 4 m!ka Mic Arm „On Air“ Audio Shield RED = High BLU = Low N/C N/C Cut Off ! Audio Shield RED = High 5/8“ For RED light connect BLU = Low BLK = 0 V YEL = +12­24VDC For WHITE light connect BLK = LED Indicator BLK = +12­24VDC YEL = 0 V Remarks...
  • Page 5 m!ka Mic Arm Audio Shield RED = High BLU = Low Audio Shield RED = High 5/8“ BLU = Low Remarks...
  • Page 6 m!ka Mic Arm TV „On Air“ Audio Shield RED = High Microphone BLU = Low BLK = LED Indicator YEL = LED Indicator...
  • Page 7 m!ka Mic Arm TV „On Air“ Remarks Audio Shield RED = High Microphone BLU = Low Cut Off ! For RED light connect BLK = 0 V YEL = +12­24VDC For WHITE light connect BLK = +12­24VDC YEL = 0 V or toggle polarity for dual use...
  • Page 8 m!ka Mic Arm TV RED = High Microphone BLU = Low Audio Shield...
  • Page 9 m!ka Mic Arm TV Audio Shield RED = High Microphone BLU = Low Remarks...
  • Page 10 m!ka Mic Arm (all models) Remarks...
  • Page 11 m!ka Mic Arm (all models) Remarks...
  • Page 12 m!ka Studiolight Remarks...
  • Page 13 m!ka Studiolight Remarks...
  • Page 14 m!ka Studiolight Remarks...
  • Page 15 m!ka Studiolight Remarks...
  • Page 16 m!ka MMS PDM­Kit Remarks...
  • Page 17 m!ka Power Sting Remarks...
  • Page 18 m!ka MMS Ceiling Mount Remarks...
  • Page 19 m!ka Wall Mount Remarks...
  • Page 20 m!ka MMS Monitor Mount Remarks...
  • Page 21 m!ka MMS Monitor Mount Remarks...
  • Page 22 m!ka EasyLift Remarks...
  • Page 23 m!ka EasyLift Remarks...
  • Page 24 m!ka MMS QuickFix Remarks...
  • Page 25 m!ka MMS QuickFix Remarks...
  • Page 26 m!ka MMS Cable Clamp Remarks...
  • Page 27 m!ka MMS Safety Stop STOP Remarks...
  • Page 28 m!ka MMS Monitor Arm (Friction) Remarks...
  • Page 29 m!ka Bushing 22 mm Remarks...
  • Page 30 m!ka MMS Pole Adapter Remarks...
  • Page 31 m!ka Table Clamp Remarks...
  • Page 32 m!ka Table Through Mount...
  • Page 33 m!ka Table Top Mount Remarks...
  • Page 34 m!ka Wall Bracket Remarks...
  • Page 35 m!ka System Wall Adapter...
  • Page 36 m!ka Pad­Dock Remarks...
  • Page 37 m!ka Pad­Dock min 160mm max 300mm Remarks...
  • Page 38 m!ka Copy Stand Remarks...
  • Page 39 m!ka Copy Stand Remarks...
  • Page 40 The device complies with the following standards • EN 60589-1 • EN 60589-2-4 • EN 62031 • EN 62471-2-1 • EN 55015 • EN 61547 • EN 61000-3-2 • EN 61000-3-3 • EN 60589-1 according to the requirements of directives • 2006/95/EG • 2004/108/EG For Yellowtec Thum + Mahr GmbH Heinrich­Hertz­Str. 1­3 D­40789 Monheim am Rhein Monheim, 12.06.2015 Hanno Mahr, MD...
  • Page 41 Page 4, 7 ­ We suggest using XLR­5 pin connectors for microphone signal and on air light feed on lower end of cable and XLR­3 type connectors for microphone on upper end of cable. ­ When installing the connector on upper end, cut off the black and yellow wires. They are not connected and do not carry any voltage.
  • Page 42 m!ka Remarks ­ Do not pull the knurled screws too tight. They may break and the joints may squeak. Instead re­adjust the screw inside the bottom as in Step 1. ­ If necessary, use Teflon spray in case of joint squeak. Page 12 ­...
  • Page 43 hole of 12mm diameter for the PDM Kit. ­ Use black or silver washer according to your choice, but always use one on both sides of the table top! ­ If you need to use your own threaded bolt make sure you use M10 metric thread. ­...
  • Page 44 m!ka Remarks Page 22 ­ Use an Allen key to adjust EasyLift‘s pneumatic spring to your monitor‘s weight. ­ Use the screwing devices at the rotating joints to adjust the joints. Page 23 ­ You can deactivate the QuickFix function for security reasons. Turn in the screw next to the release lever in order to disengage its function.
  • Page 45 Page 29 ­ To secure proper upright positioning of the m!ka Bushing drill a hole with a minimum diameter of 22 mm. ­ The thread of the bushing is metric; should you ever need to replace the nut make sure you use the correct M20x1,5 thread. Page 30 ­...
  • Page 46 m!ka Remarks Page 37 ­ An audible „click“ signals that the Pad­Dock is securely locked into position. Page 38 ­ The cover panel for your m!ka Copy Stand holds and aligns by the integrated magnets. ­ Make sure the magnets face each other. ­...
  • Page 48 yellowtec.com...
