Assembling the Allegro
Prior to assembly, check the parts and components received against the following list. If you are missing any parts, contact the
Balanced Body customer service department at 1-800-PILATES (1-800-745-2837) in the U.S. and Canada, or +1-916-388-2838
(international).
PREPARE YOUR ALLEGRO REFORMER
If you have purchased an Allegro 14" leg set, we strongly
recommend installing the legs before installing the Tower.
Remove all ropes and risers from the Allegro. If your Allegro
was purchased before February 1, 2004, remove the labels and
backing on the sides. You can order a new label free of charge by
calling 1-800-PILATES (1-800-745-2837 in the U.S. and Canada,
or +1-916-388-2838 (international).
Tower of Power
®
PARTS LIST
Part Number Description
618-024
Tower
TRP0047
Push-through bar (PTB)
GEN9892
T-pin
950-234
Tower Bracket, Right
950-235
Tower Bracket, Left
950-131
Adjustable pulley and knob assembly
212-001
5/32" Allen key, long
SPR9004
Blue trap spring
SPR9002
Yellow trap spring
SPR9461
Long spring, purple
SPR9006
Long spring, yellow
710-010
Roll down bar
101-005
Single cotton loops
210-023
Safety strap with carabiner
DVD8205
Introductory DVD
950-236
Tower lower spring mounts
™
Qty
1
1
2
1
1
2
1
2
2
2
2
1
1 pair
1
1
1
17
