L&S Emotion Quick Start Manual page 2

7
The transmitter can control multi route color temperature adjustable LED Lamps
with receiver within the remote range
If you need this function , please go with step8 and step9.
Slave
Receiver
8 The indicator light turns on(The controller
.c
will exit matching setting mode after 1
minute of inactivity, and indicator light will
turn off)
9
Match the master receiver to transmitter
9
Connect color temperature
.a
adjustable LED lamps
9 If the indicator light flashes
.d
after 5 seconds, the transmitter
works well with the receiver
Slave
Receiver
LED
Driver
Distributor
Master
Receiver
Slave
Receiver
Press the On/Off button
8
.d
for more than 5 seconds
9
.b
LED Driver
Remote range ≤ 15m
Slave
Receiver
Connect to power and press
the test button for 5 seconds
Memory function
!
Notice: Memory function will take effect under the receiver working well at
least 60s while rotating the color wheel.
Sleeping function
The remote will go dormant after 60 seconds of inactivity.
Press any button to reactivate the remote.
Master receiver setting function
Notice: Only one master receiver allowed in the wireless network.
If the salve receiver need to be setted as master, it can be setted
according to the "Match the master receiver to transmitter"step, and
the original master receiver should be power on.
8
Match the slave receiver to transmitter
Connect color temperature
8
.a
adjustable LED lamps
8
Connect to power and
.b
press the test button
LED Driver
If the indicator light flashes and
8
.e
turns off, the transmitter works
well with the receiver.
9
.c
The indicator light turn on
