TWEED Bill of Materials (BOM)

TWEED
BAG
ITEM
250 5 WATT RESISTOR
820 OHM CARBON COMP 1/2 W RESISTOR
1K5 OHM CARBON COMP 1/2 W RESISTOR
1K5 OHM CARBON FILM 1 W RESISTOR
4K7 OHM 2 W METAL RESISTOR
22K OHM METAL OXIDE 2 W RESISTOR
56K OHM CARBON COMP 1/2 W RESISTOR
68K OHM CARBON FILM 1 W RESISTOR
100K OHM CARBON COMP 1/2 W RESISTOR
220K OHM CARBON COMP 1/2 W RESISTOR
470K OHM CARBON FILM 1 W RESISTOR
1M OHM CARBON COMP 1/2 W RESISTOR
1M OHM CARBON FILM 1 W RESISTOR
500 pF SILVER MICA CAPACITOR
.0047uF MALLORY 150 AXIAL CAPACITOR
.022 uF/600 ORANGE DROP STYLE CAP
.1 uF/600 ORANGE DROP STYLE CAP
16uF 450V ELECTROLYTIC CAPACITOR
25 uF 50V AXIAL ELECTROLYTIC CAPACITOR
1M-AUDIO POT (3/8")
CHICKEN HEAD KNOB - BLACK
IEC CHASSIS SOCKET
PANEL MOUNTED BAYONET FUSE HOLDER
FUSE 2A SLO BLO (1A for 220/240V)
PILOT LAMP ASSEMBLY 6.3V WITH RED JEWEL
PILOT LAMP 6.3V
CARLING SPST TOGGLE SWITCH 125V 5A
CHASSIS GROMMETS (1/2"")
9-PIN RETAINER
9-PIN MICALEX TUBE SOCKET
8-PIN MICALEX TUBE SOCKET
8-PIN TUBE RETAINER
SWITCHCRAFT 12A JACK (SWITCHED)
SWITCHCRAFT 11 JACK (UNSWITCHED)
SHOULDER WASHER 3/8" - FIBRE
WASHER 3/8" - FIBRE
*Note - Some hardware may be used to ship transformers in place.
Version 3.2
BOM TWEED
QTY BAG
ITEM
1 SWITCHCRAFT 12A JACK (SWITCHED)
1 SWITCHCRAFT 11 JACK (UNSWITCHED)
2 SHOULDER WASHER 3/8" - FIBRE
2 WASHER 3/8" - FIBRE
1 #4 X 5/16" MACHINE SCREW
1 #4 HEX NUT
2 #4 CHASSIS LUG
4 #6 X 3/4" MACHINE SCREW
3 #6 X 3/8" MACHINE SCREW
2 #6 HEX NUT
1 #6 LOCK WASHER
1 #6 CHASSIS LUG
2 #6 STANDOFFS NYLON 1/4" OD 3/8" LONG
1 #8 X 3/8" MACHINE SCREW, GROUND BOLT, OT.
1 #8 HEX NUT
1 #8 CHASSIS LUGS
4 #10 X 1-1/4" MACHINE SCREW
3 #10 HEX KEPS NUT
3 #10 WASHER
22 GAUGE SOLID WIRE, VARIOUS COLOURS
3
(FEET)
3 SHIELDED CABLE (FEET)
1 18 GA STRANDED WHITE INCHES
1 18 GA STRANDED BLACK INCHES
1 HEAT SHRINK TUBING - 1/16" 4"
1 HEAT SHRINK TUBING - 1/8" 4"
1 HEAT SHRINK TUBING - 1/4" 2"
2 TIE WRAPS
2 DELUXE EYELET BOARD
2 CHROME STEEL CHASSIS
2 POWER CORD 8', 18/3
3 POWER TRANSFORMER - TWEED HI CAPACITY
3 OUTPUT TRANSFORMER - TWEED 3108 4, 8 OHM
4 6V6 POWER TUBES JJ
2 ECC83 / 12AX7 TUBE JJ
4 12AY7 EH
4 5Y3 - RECTIFIER, FULL WAVE, JJ / SOVTEK
TWEED BUILDERS GUIDE
Page: 73
QT
BOM
Y
4
2
4
4
13
1
2
4
1
1
4
3
4
3
7
1
2
2
2
10
1
18
18
1
1
1
6
1
1
1
1
1
2
1
1
1
1
