Operation Manual
Compact Amplifiers with DSP
The amplifi ers of the PA S-DSC series are compact, remote controllable 2-channel digital amplifi ers
with integrated DSP. With minimal dimensions the amplifi ers of the PA S-DSC series comprise
2 symmetrical inputs and 2 outputs with 50 or 100 watts power and deliver outstanding sound quality
at low levels of heat generation. Single or multiple amplifi ers of the PA S-DSC series can be connected
via Ethernet, programmed using the DSC Control software and a PC, and operated using a media control
system.
In addition to the 2×2 mixer matrix, the DSP also off ers ten fully parametric fi lters, a delay of up to 10 ms,
compressors and limiters for each input and output. Up to 100 presets can be stored permanently.
We can also preconfi gure project-specifi c settings on request.
The integrated limiters guarantee stable, distortion-free operation even with low load impedances.
The amplifi ers are equipped with an automatic switch-on function, an ON/Stand-by contact and VCA
inputs for external volume control.
The amplifi ers can be controlled individually or in groups using the WP-V and RP-V volume controllers
or the DV module and UP/DOWN contacts. Up to 4 compact amplifi ers can be mounted in 19" racks in a
single height unit (in PA-T 1U).
