- Page 1 Ring Automation for rolling shutters MADE IN ITALY MANUAL OF INSTRUCTION...
-
Page 2: General Description
1 - GENERAL DESCRIPTION 1A - ADVERTENCIAS This manual has been especially written for use by qualified installation technicians. No information given in this manual can be considered as being of interest to end users. Read these instructions carefully before proceeding with the installation, as they provide important information regarding safety, installation, use and maintenance. -
Page 3: Installation
2 - INSTALLATION 2A - PRELIMINARY CHECKS Please keep in mind that automatic rolling gate systems may only be installed by qualified personnel in compliance with the legislation in force. Make sure that: - The packing is undamaged and contains all the parts shown in Fig. 1. - The rolling gate opens and closes without presenting points of greater friction. -
Page 4: Maintenance
3 - Manual manoeuvre (only on versions with brake) Release only when the rolling gate is stopped. � To release the gearmotor proceed as follows: 1 Turn the bottom of the knob clockwise to loosen it until you feel a certain resistance; 2 Open or close the rolling gate manually;... - Page 5 RING 150 - RING 180 - RING 150 / 110 RING 150 PLUS - RING 180 PLUS - RING 150 / 110 PLUS...
- Page 6 RING 150 RING 180 RING 150 / 110 RING 150 PLUS RING 150 / 110 PLUS RING 180 PLUS...
- Page 8 King Gates S.r.l. Via A. Malignani, 42 - 33077 Sacile (PN) ITALY Tel. +39 0434 737082 - Fax +39 0434 785351 e-mail: info@king-gates.com web: www.king-gates.com...
