Zero 88 Sirius 24 Installation And Operation Instructions

Dmx output kit

Advertisement

Quick Links

Issue 5 - March 2002
Zero 88 Lighting Ltd reserves the right to make
changes to the equipment described in this
manual without prior notice.
This equipment is designed for use with a
Sirius 24 or Sirius 48 lighting control desk only
and is unsuitable for any other purpose. It
should be fitted and used by, or under the
supervision of an appropriately qualified or
trained person only
© Zero 88 Lighting Ltd 1998
E&OE
Manual Stock No 73-560-00
Sirius 24 and 48
DMX Output Kit
Installation and
Operation
Instructions
Zero 88 Lighting Ltd
Usk House
Lanthanam Park
Cwmbran
Gwent, UK
NP44 3HD
Tel
Fax
e-mail
web site
+ 44 (0) 1633 838088
(24 Hr Answer Phone)
+ 44 (0) 1633 867880
sales@zero88.com
www.zero88.com
