DQ-CUBE
Installation Manual
DUALi Inc.
Document Version: 1.00
Last Revised Date: 22
Copyright ⓒ 2018 DUALi Inc. All rights reserved. You are strictly prohibited to
copy, disclose, distribute, or use this document in part or as a whole for any
purposes other than those for which this document is disclosed. This document is
copyrighted and contains confidential information and other intellectual property
rights of DUALi Inc. Any unauthorized use, copy, disclosure or distribution
constitutes infringement of DUALi's intellectual property rights.
Release Date: 25 November 2009
th
. May 2019
Advertisement
Table of Contents
Related Manuals for Duali DQ-CUBE
Summary of Contents for Duali DQ-CUBE
- Page 1 Last Revised Date: 22 . May 2019 Copyright ⓒ 2018 DUALi Inc. All rights reserved. You are strictly prohibited to copy, disclose, distribute, or use this document in part or as a whole for any purposes other than those for which this document is disclosed. This document is copyrighted and contains confidential information and other intellectual property rights of DUALi Inc.
- Page 2 DQ-CUBE Installation Manual Version: 1.00 Revision History 2019.05.22 (Ver. 1.00): First Release www.duali.com...
- Page 3 DQ-CUBE Installation Manual Version: 1.00 DUALi Inc. reserves the right to make changes to its applications or services or to discontinue any application or service at any time without notice. DUALi provides customer assistance in various technical areas, but does not have full access to data concerning the use and applications of customer's products.
-
Page 4: Table Of Contents
DQ-CUBE Installation Manual Version: 1.00 CONTENTS 1. Introduction ................................. 5 Specification ............................5 2. Contents confirmation........................... 6 Contents confirmation ........................6 3. Appearance ................................. 7 Product Exterior ..........................7 Dimension ............................... 8 Installation Guide ..........................8 How to add SAM ..........................10 4. -
Page 5: Introduction
DQ-CUBE Installation Manual Version: 1.00 1. Introduction DQ Cube is designed for unattended machine, Kiosk & speed gate to accept mobile ID or E-wallet application. It provides seamless scanning of digital 1D, 2D and PDF codes in a single, convenient device. -
Page 6: Contents Confirmation
DQ-CUBE Installation Manual Version: 1.00 2. Contents confirmation 2.1 Contents confirmation - DQ-CUBE hardware - Cable option ( by request ) -> refer to page 10 12P cable (Wiegand/RS232/RS485) OR USB cable (USB HID or Virtual Comport) www.duali.com... -
Page 7: Appearance
DQ-CUBE Installation Manual Version: 1.00 3. Appearance 3.1 Product Exterior www.duali.com... -
Page 8: Dimension
- You’ll need following item DQ-CUBE * 1EA M3 Tapping screws * 4EA Fixing panel for DQ-CUBE (recommendable depth 1.5mm min.) Boss for tapping screw 4 point Recommended depth 1) Prepare tapping screws fits for DQ Cube. ... - Page 9 DQ-CUBE Installation Manual Version: 1.00 After fix Cube on panel www.duali.com...
-
Page 10: How To Add Sam
DQ-CUBE Installation Manual Version: 1.00 3.4 How to insert SAM - You will need SAM card Screw driver (+) (-) flat head screw driver. Note: SAM requires only for the secure transaction, it’s not necessary in case of QR only version. - Page 11 DQ-CUBE Installation Manual Version: 1.00 4) SAM slot is located inside. Insert the SAM to use and put the metal bar into left to fix it. . 5) Put QR module back in to the position, and screw them as process 3) ->...
-
Page 12: Connection Diagram
DQ-CUBE Installation Manual Version: 1.00 4. Connection Diagram 4.1 12P cable (DC 12V ~ 24V INPUT) PIN No. DESCRIPTION COLOR PWR_IN PWR_GND BLACK RS232_RX GRAY RS232_TX PINK or JADE WGD_D0 GREEN WGD_D1 WHITE PWR_GND BLUE BROWN BEEP YELLOW TAMPER VIOLET... -
Page 13: Environmental Feature
DQ-CUBE Installation Manual Version: 1.00 5. Environmental Feature 5.1 Operation Environment - Operation temperature : 0 ~ 60 ℃ - Operation humidity : 30 ~ 90 % (relative humidity) 5.2 Storage Environment - Storage temperature : -20 ~ 70 ℃... - Page 14 6. Warranty & Service Warranty and Repair service DUALi Inc. warrants to the original consumer or other end user that this product, DQ-Cube, is free from defects in materials and workmanship for a period of 1 year from the date of purchase.
