- Page 1 ASPEN SOAP DISPENSER MODELS 427-L-GRY 427-F-GRY OPERATION & INSTALLATION MANUAL W W W . A L P I N E I N D U S T R I E S . C O M...
- Page 2 Alpine will not be liable for any damages because of failure to comply with the installation and operating instructions outlined in this manual or because of improper use.
-
Page 3: Components List
COMPONENTS LIST 1. Cover 2. Power adaptor plug * 3. Key button 4. Sight glass 5. Dispenser 6. Reservoir 7. Screw cap 8. Pump 9. Case tab 10. Pump tab 11. Single dose button * 12. Double dose button * 13. -
Page 4: Preparing The Dispenser
PREPARING THE DISPENSER 1. Carefully remove dispenser from shipping carton, remove packing material (recycling is recom- mended), and inspect unit for damage. 2. Check for missing of damaged parts. If parts are missing or damaged contact the retailer. 3. Open the dispenser by inserting key, pressing down on key button 3 and swinging cover 1 down. 4. -
Page 5: Tools Needed
TOOLS NEEDED Phillips head screw driver Drill Drill bit Stud finder Pencil 1. Mount over a counter top no less than 16 inches (40cm) above counter. Do not install dispenser over electrical outlets. 2. Hold the holster 16 against bare wall and mark location of screws on the wall. 3. -
Page 6: Limited Warranty
The replacement of any part is warranted for the remainder of the original warranty period. What is Covered — The parts are warranted for a 1 year period from the date of purchase. Alpine Industries will provide part replacement for original defects, when in accordance to the owner's manual and installation guide.
