MEDIAGATEWAY
USER MANUAL
July 2020
Manual-Version: 5.1
FW-Version: v4.4.0
HW-Version: v2.1a to v2.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MediaGateway and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Technica MediaGateway

  • Page 1 MEDIAGATEWAY USER MANUAL July 2020 Manual-Version: 5.1 FW-Version: v4.4.0 HW-Version: v2.1a to v2.6...
  • Page 2: Table Of Contents

    LINKS ......................7 1.1.4 General operating and safety strategy of Technica Engineering’s Products 1.1.5 General design rules for the power supply of Technica Engineering’s products ........................8 Warranty and Safety Information ............... 9 RoHS Certificate of Compliance ..............11 Scope of Delivery ....................12 HARDWARE INTERFACES ..................
  • Page 3 Communication mode: Speed RAW ............68 3.7.4 Communication mode: Extreme RAW ............71 3.7.5 Difference between all RAW modes ............74 3.7.6 Structure of a CANEthernet packet ............74 3.7.6.1 Structure of UDP-Packet ..............74 3.7.6.2 Structure of RAW-Packet ..............74 MediaGateway User Manual...
  • Page 4 Configuration Examples ..................76 Logging communication between two DUTs ..........76 Get access by third communication partner ........... 79 PTP AND 802.1AS in the MediaGateway ............... 81 Protocol ......................81 Transport of time-synchronization information ..........81 Propagation delay measurement ..............83 802.1AS in the MediaGateway .................
  • Page 5 No access to webserver anymore ..............101 Host LED is blinking fast................. 101 Problems with website interface ..............102 Delay Time for Ethernet packets through the MediaGateway ...... 102 AVB Support ....................102 Maximum Frame Size ..................102 10 LIST OF FIGURES ....................103 11 CHANGELOG ......................
  • Page 6: General Information

    1.1 Functionality and Features of the MediaGateway Figure 1-1: MediaGateway The Technica Engineering MediaGateway allows users to connect and loop through up to 12 100BASE-T1-based devices on the physical layer and to establish virtual point- to-point connections, thus enabling filter and control of data streams (routing, mirroring, forwarding).
  • Page 7: General Information

    Operating temperature: -40°Celsius to +80°Celsius StartUp Time The StartUp time is valid for HW-Variants 2.1a and higher, and Software 3.7 and higher. If there is information needed about older variants of the MediaGateway, please contact support@technica-engineering.de. PowerUp and Processor Boot Time:...
  • Page 8: General Operating And Safety Strategy Of Technica Engineering's Products

    Should Technica Engineering’s products be operated in voltage ranges beyond those specified in the norms, which represents a breach of the conditions of operation, then this will void the product warranty and Technica Engineering will assume no liability whatsoever of the results and/or consequences thereof.
  • Page 9: Warranty And Safety Information

    When integrating the modules in a vehicle or test set-up, the user must ensure appropriate ventilation or air convection. Technica Engineering products must not be considered as a safety element out of context when using safety-critical systems and must be included in the safety assessment when used. The development class in a safety system must be taken into account with standard QM referred to ISO26262.
  • Page 10 This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. Technica Engineering GmbH is registered as manufacturer of the brand "Technica Engineering" and...
  • Page 11: Rohs Certificate Of Compliance

    1.3 RoHS Certificate of Compliance Figure 1-2: Copy of RoHS Certificate of Compliance MediaGateway User Manual...
  • Page 12: Scope Of Delivery

    1x 1m Ethernet Cable o 1x Black MQS Connector o 3x Blue MQS Connectors o 100BASE-T1 cabling o MQS Crimps o Power cabling o 4mm Banana-plugs Additional cable-sets can be ordered. Please write us at order@technica- engineering.de. MediaGateway User Manual...
  • Page 13: Hardware Interfaces

    2 HARDWARE INTERFACES 2.1 Connectors On the label on top of the device you can see an overview about all HW interfaces of the MediaGateway: Figure 2-1: Label of MediaGateway with pinning information MediaGateway User Manual...
  • Page 14: Power Connector - Black Mqs Connector

    Wake up line 1 FlexRay plus LIN Bus FlexRay minus Table 2-2: Pinning of black MQS connector Note: CAN interfaces can only be used with CAN Gateway option and FlexRay Logging only with FlexRay option. further Information please contact technicalsales@technica-engineering.de MediaGateway User Manual...
  • Page 15: Switch Connectors - Blue Mqs Connectors

    The power supply for the device is supplied by Pin 1 (12Volt) and Pin 2 (Ground). Requirements for the MediaGateway itself: 12 Volts DC up to 1 Ampere (typical 600mA) Please note, that the power supply for the 12 Volts camera power output is also supplied form Pins 1 and 2.
  • Page 16: Ethernet Connectors

    Edimax Mini GBIC (SFP) LC, 1 Gigabit/s, 1000 Base-SX Module SFPEX S1GT-A Mini GBIC (SFP) 10/100/100 Mbps RJ-45 Module BEL SFP-1GBT-05 SFP 10/100/100 Mpbs RJ-45 Module Note: Technica Engineering´s 100/1000BASE-T1 SFP Modules are compatible with the MediaGateway! For further information please follow these links: https://technica-engineering.de/produkt/100base-t1-sfp-module/...
  • Page 17: Other Interfaces

    2.2 Other Interfaces 2.2.1 Status LEDs The MediaGateway has several status LEDs at the front side of the case. Figure 2-2: LEDs The “Host” LED can toggle at three different speeds: Slow toggle (approx. 0.5 sec) during normal operation to show that the microcontroller is running in normal mode.
  • Page 18 Complete configurations are lost and set to default Note: If the device is blocked and all LEDs are lit, device must be sent to Technica Engineering. In order to avoid controversies here please make sure that the HOST LED is blinking its normal operation mode and the power supply is stable before the reset.
  • Page 19: Configuration Of Device

    PC. 1. Please go to the network adapter settings of your PC and adjust the IP in the same range of your MediaGateway. Default-IP address of the MediaGateway is 192.168.0.49, the subnet mask is 255.255.255.0. 2. Enter the IP address of the MediaGateway in your browser.
  • Page 20: Save Changes

    You can check the version number of the application firmware and the bootloader or the unique MAC address of the device. The version number registers of the switch and PHY chips are displayed for information only. MediaGateway User Manual...
  • Page 21: Control Panel Tab

    Software reset. Configuration will NOT be lost. Configuration: It shows the current configuration name. Export: Save the stored configuration from MediaGateway into user’s PC. Import: User can import or export the configuration settings of the device to a file (*.cfg) on a computer connected to the RJ45 Port.
  • Page 22: Mediagateway Feature Activation

    (Please see the configuration of each port in HAPTER 3.6) Diagnose service: If you enable this functionality, the MediaGateway will send periodically status information about its state. For example, transmitted and dropped frame counters, link quality, etc. For more details please see HAPTER 3.4.2...
  • Page 23 Figure 3-5: UUID of MediaGateway Technica Engineering will provide an activation code for the feature. The received activation code must be entered in the Control Panel. The next picture shows how to unlock CAN Gateway feature after receiving the activation code:...
  • Page 24 Now there is an extra tabulator for the extra feature available: Figure 3-7: CAN Gateway tabulator Remove extra features: With this function all extra features will be removed from this MediaGateway. If this is done, reactivation is possible with the Activation key again. MediaGateway User Manual...
  • Page 25: Switch Status Tab

    3.5 Switch Status tab Figure 3-8: Switch Status tab The main configuration of the MediaGateway is done in the “Switch Status“tab. Here you can configure details about each port and get some status information about the ports and switch states.
  • Page 26: Arl Table Status

    Dynamic: the switch is learning the ARL table by itself Static: the ARL table can be set and all entries must be defined by the user. Even the micro of the MediaGateway itself and the PC for configuration. Address Resolution Table...
  • Page 27: Dynamic Arl Table

    1 = Entry has been learned or accessed since last aging process Age bit 0 = Entry has not been accessed since last aging process Static bit Entry has not been learned and cannot expire Table 3-1: Description of ARL Tabel Entry MediaGateway User Manual...
  • Page 28: Static Arl Table

    That means, if you want to add an entry to current entries, don’t Figure 3-11: How to add current entries forget to add even the current entries by pressing “+”. Please see 3-11 IGURE MediaGateway User Manual...
  • Page 29 Export: the current configuration of the ARL table is exported to a *.json-file. Choose File: the user can import a ARL-table-configuration file of type *.json. After the import the changes must be applied by the button “Apply” and then must be saved by the button “Save configuration”. MediaGateway User Manual...
  • Page 30 After pressing the save button, the shown tabulator jumps to System Information tab and there is no restart of the MediaGateway. Please go to the Control Panel-tab and do here the saving again. This way the MediaGateway should restart and all changes will be saved.
  • Page 31 After pressing the save button, the shown tabulator jumps to System Information tab and there is no restart of the MediaGateway. Please go to the Control Panel-tab and do here the saving again. This way the MediaGateway should restart and all changes will be saved.
  • Page 32: Ports Overview

    IEEE 802.1q (VLAN) mode is not hooked (see 3.5.1) HAPTER In this mode, basic configuration details can be adjusted, but the MediaGateway works as standard switch. Grey fields are not configurable and have standard values or no values. MediaGateway User Manual...
  • Page 33: Ethernet Port Rj-45

    This port is monitored: If on this port is incoming traffic, the MediaGateway doesn’t go asleep. This port is not monitored: The MediaGateway can go asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports to be mirrored.
  • Page 34 Capable” autonegotiation is done. By the other settings, the speed is set, but master/slave is still autonegotiated. Detected Speed: Here the detected speed is displayed, which is autonegotiated between MediaGateway and connected device on this port. Drop ingress packets with…: Source IP: one IP address can be configured here.
  • Page 35: Sfp Module Port

    This port is monitored: If on this port is incoming traffic, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports to be mirrored.
  • Page 36 Base-T1 / BroadR-Reach® module: please select this option for a BASE-T1 modules from Technica-Engineering GmbH Speed: If autonegotiation is not available, please select the speed of the SFP module 100BASE-T1 for 100Mbps and 1000BASE-T1 for 1000Mbps BASE-T1 / BroadR-Reach®...
  • Page 37: S1-P4 (Cpu) And Internal Ports (P4 And P8)

    This port is monitored: If on this port is incoming traffic, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: Here you can choose the incoming traffic from the ports, which you want to be mirrored to this port.
  • Page 38 MAC addresses can be configured. It is a filter outgoing traffic. Data with configured MAC address as destination MAC address will be dropped and forwarded Note: This drop feature is only available if mirroring on this port is activated MediaGateway User Manual...
  • Page 39: 100Base-T1 Ports

    This port is monitored: If on this port is incoming traffic, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Enable port: port is active.
  • Page 40 BroadR-Reach® mode: For the MediaGateway there is no autonegotiation on 100BASE-T1 Ports available. Slave: the connected device is a master and MediaGateway-port itself is a slave Master: the connected device is a slave and MediaGateway’s port itself is a master Output level: The “Output Level”...
  • Page 41: Port Information While Single Vlan Tagging Is Active

    3.5.1) but not double tagging, HAPTER port based single VLAN is activated. In this mode, the routing through the MediaGateway is defined by the configuration of each port. Grey fields are not configurable and have standard values or no values.
  • Page 42: Ethernet Port Rj-45

    0x1 and 0xFFF can be defined separated by “,” [E.g.: 100, 101, EDF, …]. Outgoing (allowed) traffic is sent with no VLAN- tag anymore. octets: decimal value of sent octets on this port. octets: decimal value of received octets on this port. MediaGateway User Manual...
  • Page 43 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports to be mirrored.
  • Page 44: Sfp Module Port

    0x1 and 0xFFF can be defined separated by “,” [E.g.: 100, 101, EDF, …]. Outgoing (allowed) traffic is sent with no VLAN- tag anymore. octets: decimal value of sent octets on this port. MediaGateway User Manual...
  • Page 45 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can go asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports...
  • Page 46: S1-P4 (Cpu) And Internal Ports (P4 And P8)

    S1-P4 (CPU) and internal ports (P4 and P8) Figure 3-22: CPU port and internal ports Port name: Here you can change the Port Name Default VLAN ID (hex): please define one hexadecimal value between 0x1 and 0xFFF. MediaGateway User Manual...
  • Page 47 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports...
  • Page 48: 100Base-T1 Ports

    Here you can change the Port Name Default VLAN ID (hex): please define one hexadecimal value between 0x1 and 0xFFF. Incoming traffic is single tagged with this value, if not already tagged. It is not overwriting VLAN-IDs. MediaGateway User Manual...
  • Page 49 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Enable port: port is active.
  • Page 50: Port Information While Double Vlan Tagging Is Active

    IEEE 802.1q (VLAN) mode is hooked (see 3.5.1) and double tagging is HAPTER hooked, too. In this mode, the routing through the MediaGateway is defined by the configuration of each port. Grey fields are not configurable and have standard values or no values.
  • Page 51: Ethernet Port Rj-45

    Note: This is the recommended use case of the MediaGateway. Networks in vehicles are often already single-tagged. In this use case you can prove the flexibility of the MediaGateway, being independent from single-tagged networks. 3.6.3.1 Ethernet Port RJ-45 Figure 3-24: Details of the Ethernet Port RJ-45...
  • Page 52 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports...
  • Page 53: Sfp Module Port

    Data with configured MAC address as destination MAC address will be dropped and forwarded Note: This feature is only available if mirroring on this port is activated 3.6.3.2 SFP module port Figure 3-25: SFP Module Port MediaGateway User Manual...
  • Page 54 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports...
  • Page 55 Base-T1 / BroadR-Reach® module: please select this option for a BASE-T1 modules from Technica-Engineering GmbH Base-T1 / BroadR-Reach® module: please select this option for a BASE-T1 modules Speed: If autonegotiation is not available, please select the speed of the SFP module 100BASE-T1 for 100Mbit/s and 1000BASE-T1 for 1000Mbit/s BASE-T1 / BroadR-Reach®...
  • Page 56: S1-P4 (Cpu) And Internal Ports (P4 And P8)

    This adjustment is valid only for (allowed) outgoing traffic. Three different options are available: received: a frame came in to the (current) switch on another port. This frame must leave on this port “as received” => o leave with VLAN if received with VLAN on another port MediaGateway User Manual...
  • Page 57 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Mirroring: On each switch only on port can be a mirroring port. Please select the ports to be mirrored.
  • Page 58: 100Base-T1 Ports

    “,” [E.g.: 100, 101, EDF, …]. Outgoing traffic can leave the switch on this port, if the data is tagged with one of the defined VLAN-IDs. Only outerVLANs are checked! Egress VID remarking: this must be defined for innerVLAN and outerVLAN separately. MediaGateway User Manual...
  • Page 59 This port is monitored: If there is incoming traffic on this port, the MediaGateway doesn’t fall asleep. This port is not monitored: The MediaGateway can fall asleep, even if there is incoming traffic on this port. Enable port: port is active.
  • Page 60 DISABLED: Port will not take part of any 802.1AS traffic BRIDGEX_MASTER: Port will take part of 802.1AS network as PTP-Bridge- Master. BRIDGEX_SLAVE: Only one Slave per BridgeX is allowed. MediaGateway will take part of 802.1AS network as PTP-BridgeX-Slave MASTER_802.1AS: Port will work as 802.1AS Master Clock. Only one MasterClock per switch is possible.
  • Page 61: Important Vlan Tagging Rules

    VLAN ID on this specific port. The MediaGateway does never overwrite any VLAN tags. It means a frame already tagged before entering a switch of the MediaGateway’s switch doesn’t change its VLAN tag. Both rules are valid for both VLAN tags and in both VLAN tagging modes (single/double).
  • Page 62: Can Gateway

    Note: The CAN Gateway is in the Microcontroller (CPU). The Switch 1 has to be configured in a way that the microcontroller has still a connection to your PC. Note: The CAN Gateway is not able to work with CAN-FD. MediaGateway User Manual...
  • Page 63 Communication mode in basic settings is not selectable. Please change into advanced settings for changing the communication mode. After choosing the communication mode please change back to the Basic settings. MediaGateway User Manual...
  • Page 64: Communication Mode: Udp

    Figure 3-29: Overview CAN Gateway settings in UDP-mode CAN Parameters: (only in advanced mode available) Speed: For each CAN channel the correct speed must be selected (CAN- FD is not available.) Following kilo baud per second are available: 125Kbps 500Kbps MediaGateway User Manual...
  • Page 65 CAN channel. This is necessary if there is no other communication partner for the CAN messages. Ethernet to CAN: Incoming configurable parameters: rxPort: The MediaGateway will wait for UDP-CAN packets on selected UPD port. Please select a non-reserved port number. CAN to Ethernet: Outgoing configurable parameters:...
  • Page 66: Communication Mode: Raw

    If the target MAC address or the EtherType has the default value set, the Ethernet CAN Gateway will be disabled. Here you can see an overview about the configuration board for the RAW mode. Figure 3-32: Overview CAN Gateway settings in RAW mode MediaGateway User Manual...
  • Page 67 CAN channel. Listen-Only means no acknowledge is done for CAN messages on this bus by the MediaGateway. In deactivated Listen-Only Mode, the MediaGateway acknowledges every message on the CAN channel. This is necessary if there is no other communication partner for the CAN messages.
  • Page 68: Communication Mode: Speed Raw

    Figure 3-34: CAN-Eth-Gateway configurable parameters 3.7.3 Communication mode: Speed RAW Using this mode, the CAN Gateway can be configured by setting target MAC Address and the EtherType of the RAW packets. Non-valid entries will not be accepted and will MediaGateway User Manual...
  • Page 69 Figure 3-35: Overview CAN Gateway settings in Speed RAW mode CAN Parameters: (only in advanced mode available) Speed: For each CAN channel the correct speed must be selected (CAN- FD is not available.) Following kilo baud per second are available: 125Kbps 500Kbps 1000Kbps MediaGateway User Manual...
  • Page 70 CAN channel. Listen-Only means no acknowledge is done for CAN messages on this bus by the MediaGateway. In deactivated Listen-Only Mode, the MediaGateway acknowledges every message on the CAN channel. This is necessary if there is no other communication partner for the CAN messages.
  • Page 71: Communication Mode: Extreme Raw

    If the target MAC address or the EtherType has the default value set, the Ethernet CAN Gateway will be disabled. Here you can see an overview about the configuration board for the Extreme RAW mode. MediaGateway User Manual...
  • Page 72 Filtering: Please select the CAN channels by checking the box. Then you can adjust CAN ID Filtering. For each selected CAN channel there appears a line where the CAN IDs must be put in. Values are in hexadecimal and are separated by a comma. MediaGateway User Manual...
  • Page 73 CAN channel. Listen-Only means no acknowledge is done for CAN messages on this bus by the MediaGateway. In deactivated Listen-Only Mode, the MediaGateway acknowledges every message on the CAN channel. This is necessary if there is no other communication partner for the CAN messages.
  • Page 74: Difference Between All Raw Modes

    The CAN packet is the payload of the UDP frame or RAW ethernet frame. The following tables show the structure of this payload: 8 Byte Frame Version ID type Channel type Table 3-4: Payload of CAN/Ethernet Packet MediaGateway User Manual...
  • Page 75 Frame type UINT8 0 for CAN data frame 1 for CAN remote transmission request UINT8 Payload length of the CAN packet D0 to D7 up to UINT64 Payload Table 3-5: Detailed Information about Payload of CAN/Ethernet Packet MediaGateway User Manual...
  • Page 76: Configuration Examples

    Note: It makes sense to configure the configuration port first. The connection between a PC and the MediaGateway for access to the webserver on the microcontroller is the same as any other connection through the MediaGateway. => S1-P4 to PC-port must be configured.
  • Page 77 S1-P4 can leave on this port the Switch_1 do the same for the other direction with e.g. 0xDD as VLAN-ID: do a save if you have still access the S1-P5 is as configuration-port defined MediaGateway User Manual...
  • Page 78 A VLAN membership is not necessary because of the mirroring. InnerVLAN IDs are not touched by this configuration. It doesn’t matter if the original data has singleVLAN tags or not (egress VID remarking is “As received”) MediaGateway User Manual...
  • Page 79: Get Access By Third Communication Partner

    “Inject”-Port (S3-P8) to the DUT_2. Figure 4-2: Example for inject Steps to configure your MediaGateway: Take your MediaGateway and configure it like the example before (4.1). Go to port S3-P8 default VLAN ID e.g. 0x38 and set the VLAN membership...
  • Page 80 P2 to S3-P8 without touching the outerVLAN tag => set VLAN membership 0x12 and set Egress VID remarking for outerVLAN tags to Normalized. Do a save Now you have access on the “Inject”-Port by any other device to the DUT_2 in our example. MediaGateway User Manual...
  • Page 81: Ptp And 802.1As In The Mediagateway

    5 PTP AND 802.1AS in the MediaGateway This chapter explains the current support of the MediaGateway for 802.1AS protocol. 802.1AS is a protocol used between two or more devices to synchronize all of them through an Ethernet communication. This synchronization allows two or more devices...
  • Page 82 “correction field” will be changed and this parameter will be used on reception side to adjust the reference time of the system considering the delay of the switch and the delay in the path „Time-aware system i-1“ to „Time-aware system i“. MediaGateway User Manual...
  • Page 83: Propagation Delay Measurement

    For the correction adjust of the time reference transmitted by the Sync and Follow Up Packets, the delay between the initiator of the protocol „Time-aware system i-1“ and the first slave port of the MediaGateway „Time-aware system i“, should be measured. ( ����...
  • Page 84: As In The Mediagateway

    The implementation allows only the use of the 802.1AS in the 12 x OABR Ports of the MediaGateway. Due to technical reasons, the use of the 802.1AS protocol is not possible in Ethernet ports.
  • Page 85: Diagnostic Frames

    6 Diagnostic Frames There are two diagnostic frames implemented in the MediaGateway. To see them, please activate Diagnose-Service (C 3.4.1) and mirror the Port S1-P4 (CPU). HAPTER Both frames are based on SOME/IP. For specific information about SOME/IP please SOME/IP P...
  • Page 86 Figure 6-1: Board Configuration Frame MediaGateway User Manual...
  • Page 87 0 to 1 HW Version 2 to 21 UUID 22 to 24 Firmware version 25 to 27 Enabled function (gateways) MS Restart Status (Nr_port x 21) + 29 Port Number (Nr_port x 21) + 30 Port Name MediaGateway User Manual...
  • Page 88 Drop Source IP (Nr_port x 21) + 47 to (Nr_port x 21) + 50 Drop Destination IP VLAN Table Size and configured VLAN- 470 and following memberships and VLANs to untag Table 6-2: Specific information of bytes MediaGateway User Manual...
  • Page 89: Port Information Frame (0X8002)

    BitrateTx [Mbit/s] (Nr_port x 42) + 9 to (Nr_port x 42) + 12 RxErrorPkts (Nr_port x 42) + 13 to (Nr_port x 42) + 16 RxGoodPkts (Nr_port x 42) + 17 to (Nr_port x 42) + 20 TxErrorPkts MediaGateway User Manual...
  • Page 90 (Nr_port x 22) + 37 to (Nr_port x 22) + 38 Nr_disconnections (Nr_port x 22) + 39 to (Nr_port x 22) + 40 Last disconnection time in [ms] (Nr_port x 42) + 41 Separator Byte Table 6-3: Specific information of bytes MediaGateway User Manual...
  • Page 91: Mediagateway Remote Control

    MediaGateway through SOME/IP messages. For specific information about SOME/IP please see SOME/IP P AUTOSAR ROTOCOL PECIFICATION These messages have to be sent to the MediaGateway with the destination IP of MediaGateway and UDP port 30491 Currently, the following methods are implemented: restart device import configuration export configuration...
  • Page 92: Reset Device

    This method has the same behaviour as the Import button from webpage of the MediaGateway. This method stores a configuration into the flash. The new configuration is the payload. Note: New settings will be applied when next device restart is performed.
  • Page 93: Export Configuration

    7.3 Export Configuration This method has the same behaviour as the Export button from webpage of the MediaGateway. The response message from MediaGateway contains the *.cfg file in its payload as HEX stream. Request with: Method ID: 0x0003 Length: 0x8...
  • Page 94: Check Status

    0x02: for Dynamic Operation 7.6 Set WakeUp Line Status This method provides the user the possibility of driving the wakeup line to high or low level. Two wake up lines are available in the MediaGateway. Request with: Method ID: 0x0006...
  • Page 95: Get Wakeup Line Status

    Via this method the user can enable or disable 100BASE-T1 ports, similarly to the Enable port function on the webserver for the 100BASE-T1 ports. Request with: Method ID: 0x0008 Length: 0xA Payload: 2 bytes contain the information, which port is enabled/disabled 2 Byte MediaGateway User Manual...
  • Page 96: Set Port To Master/Slave (Only 100Base-T1-Ports)

    Via this method the user can set 100BASE-T1 ports to master or slave,similarly to the BroadR-Reach® mode function on the webserver for the 100BASE-T1 ports. Request with: Method ID: 0x0009 Length: 0xA Payload: 2 bytes contain the information, which port is set to master/slave. 2 Byte 100BASE-T1 Port selection BroadR-Reach® mode MediaGateway User Manual...
  • Page 97: Reset To Default

    This method returns a SOME/IP message with return code 0x00 (OK) before restart. 7.11 Get System Information This method returns information about MediaGateway and its active licenses. It is the same information, that is shown on System Information tab on the Webserver of the MediaGateway. MediaGateway User Manual...
  • Page 98 HW version low UINT8 e.g. 0x06 for HW v2.6 SW version UINT24 e.g. 0x040400 for SW v4.4.0 BMW extra function UINT8 0x00 disabled 0x01 enabled/unlocked CAN Gateway UINT8 0x00 disabled 0x01 enabled/unlocked FlexRay UINT8 0x00 disabled 0x01 enabled/unlocked MediaGateway User Manual...
  • Page 99: Application And Firmware Update

    8 APPLICATION AND FIRMWARE UPDATE You can download the latest firmware and documentation for the MediaGateway here: https://technica-engineering.de/produkt/media-gateway/ 8.1 Preconditions and important information Warnings: Please do not downgrade the bootloader or application to a former version. Please follow this update instruction to avoid erroneous states of the device.
  • Page 100: Update

    8.2 Update 1. Power up the device 2. Reset the MediaGateway to default settings: IP must be 192.168.0.49 3. Make sure the network adapter from your PC is configured in the same IP range (e.g. 192.168.0.60) 4. Connect the network-adapter with a RJ-45 cable directly to the Port S1-P5 and make sure there is a link by checking the LEDs blinking.
  • Page 101: Troubleshooting And Faq

    => Switch 3 is damaged, switch 2 and 1 are still working. If the first switch (Switch 1) is damaged, the MediaGateway is not working anymore. If there is still warranty, please send it back to Technica Engineering GmbH and we will provide you with a new one.
  • Page 102: Problems With Website Interface

    Note: Please do not reset by pressing the reset button while the MediaGateway is in bootloader mode! This may cause the problem of 9.1! HAPTER 9.5 Problems with website interface Please try another browser. Firefox and Chrome are recommended. 9.6 Delay Time for Ethernet packets through the MediaGateway The propagation delay of the switch depends on the load.
  • Page 103: List Of Figures

    10 LIST OF FIGURES Figure 1-1: MediaGateway ....................6 Figure 1-2: Copy of RoHS Certificate of Compliance ............ 11 Figure 2-1: Label of MediaGateway with pinning information ........13 Figure 2-2: LEDs ......................17 Figure 3-1: Home Screen MediaGateway ..............19 Figure 3-2: Save Configuration ..................
  • Page 104 Figure 4-2: Example for inject ..................79 Figure 5-1: Sync and Follow_Up messages ..............82 Figure 5-2: p_delay messages and formula ..............83 Figure 6-1: Board Configuration Frame ................. 86 Figure 6-2: Board Information Frame ................89 MediaGateway User Manual...
  • Page 105: Changelog

    11 CHANGELOG Version Chapter Description Date Added ARL status 03.2018 MediaGateway Remote control revised Added SFP port information and new SFP Modules 4.98 compatibility CANGateway Chapter updated Removed bootloader update chapter Complete rework of all Chapters 03.2020 Added information on General Operating and Safety Strategy July 2020 1.1.4...
  • Page 106: Contact

    12 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/ MediaGateway User Manual...
  • Page 107: Declaration Of Conformity

    Български English С настоящото Technica Engineering GmbH Hereby, Technica Engineering GmbH declares декларира, че продуктът Модул за улавяне that the product MediaGateway (TE-1100), is MediaGateway (TE-1100), е в съответств ие in compliance with Directive 2014/30/EU. The с Директива 2014/30/ЕС. Цялостният...
  • Page 108 Pełny tekst deklaracji zgodnośc I UE jest dostępny następującym adre Latviešu internetowym: https://technica- Ar šo Technica Engineering GmbH deklarē, ka engineering.de/produkt/mediagateway/ produkts MediaGateway (TE-1100), atbilst Direktīvai 2014/30/ES. Pilns ES atbilstības Português deklarācijas teksts ir pieejams šādā interneta v ietnē: O(a) abaixo assinado(a) Technica Engineering...
