- Page 1 ® STORELIO 2000/3000 Series Solar Off-Grid System with integrated Lithium battery EN – Installation manual Figures included in this manual are not contractual Version v1.0 – February 15, 2015 www.easylibatteries.com Printed on 100% recycled paper...
-
Page 2: Table Of Contents
Table of contents GENERAL INFORMATION..............................3 1.1. Description of Storelio off-grid ..........................3 1.2. Use of the manual ............................... 3 1.3. Validity of this manual ............................3 1.4. Long storage precautions ............................ 3 1.5. Precautions in case of PV disconnection further to installation ................3 1.6. -
Page 3: General Information
2000 Series 1.4. Long storage precautions Storelio off-grid battery is precharged before shipment from easyLi factory. In case of storage exceeded six months between easyLi factory shipment and operation it is mandatory to recharge the battery in compliance with the specific Figure 1 procedure defined by easyLi. -
Page 4: Intended Use Of Storelio Off-Grid
Any use other than the one for which Storelio off-grid is designed releases easyLi from any liability in case of damage or injury. easyLi is by no means liable of Storelio off-grid installation. Therefore, easyLi liability cannot be involved in any default and/or dispute regarding Storelio off-grid installation. -
Page 5: Battery Box
It and do not attempt to repair Storelio off-grid. can cause irreversible damages not covered by Contact your easyLi authorized dealer. the warranty. - Storelio off-grid must be installed with 20 cm vertical and When electrical devices of the dedicated grid horizontal clearance. -
Page 6: Electrical Box Mounting
DANGER! Switch OFF the external PV disconnect switch before starting any installation work. DANGER! Read carefully chapters 2 and 3 before starting any installation work. Make sure to tighten the power wires onto the terminals and cable gland to avoid overheating, any risk of disconnection or any risk of fire. -
Page 7: Dc Connection
Put the battery cover and fix it with the provided screws as shown. Open the DC compartment 4.3. DC Connection PV - Connector General remarks The input PV voltage range is 60V – 150V. Refer to the chapter “Technical data”. PV + Connector Figure 10 –... -
Page 8: Ac In Connection
4.5. AC IN Connection Phase (P), Neutral (N), and earth (PE) must be connected to AC breaker, through cable glands. AC breaker connections and earth bare are located in AC compartment General remarks (Mark 4, Figure 2). Maximum diameter of cable gland is Storelio off-grid is a class 1 box. - Page 9 LANGUAGE xxxxxx INVERTER COMMUNICATION OK In case of no selection, English language will be applied. The following messages will appear: SELF-USE SENSOR easyLi COMMUNICATION . . . OG3 V 1.0 SELF-USE SENSOR BATTERY COMMUNICATION OK COMMUNICATION . . . BATTERY...
-
Page 10: Operation - Settings
If the following message appears: POWER INJ DEFAULT xxxx W SELF-USE SENSOR - Check if the AC Breaker is on ON position and the AC ENERGY INJ input is powered. xxxx kWh - Turn ON some devices of the local cunsummer grid GRID POWER: in «... -
Page 11: Language Setting
These menus are available by scrolling with the UP/DOWN 7. BATTERY OVERDISCHARGE Button. PROTECTION Push SELECT Button to enter the selected menu. To prevent the battery from over-discharging, Storelio off- 6.3.1. LANGUAGE setting grid will automatically shut down. Screen will not be powered. -
Page 12: Error Messages
Use a dry cloth to clean the casing of the device. Do not use abrasive or solvent-based products. 11. AFTER SALES In case of troubles, do not attempt to open Storelio off-grid. Contact your local easyLi authorized dealer or in France: hotline@easylibatteries.com + 33 5 86 16 10 09 (France) Version v1.0 –... -
Page 13: Technical Data
