Automation PC 810 with
GM45 CPU board
User's Manual
Version: 1.14
(July 2011)
Model no.: MAAPC800A-ENG
All information contained in this manual is current as of its creation/publication. We reserve the
right to change the contents of this manual without warning. The information contained herein is
believed to be accurate as of the date of publication; however, Bernecker + Rainer Industrie-
Elektronik Ges.m.b.H. makes no warranty, expressed or implied, with regard to the products or
documentation contained within this manual. In addition, Bernecker + Rainer Industrie-Elektronik
Ges.m.b.H. shall not be liable in the event of incidental or consequential damages in connection
with or resulting from the furnishing, performance or use of these products. The software names,
hardware names and trademarks used in this document are registered by the respective
companies.
Automation PC 810 with GM45 CPU board User's Manual V 1.14
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Automation PC 810 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for B&R Automation PC 810

Summary of Contents for B&R Automation PC 810

  • Page 1 The software names, hardware names and trademarks used in this document are registered by the respective companies. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 2 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 3 Chapter 1: General information Chapter 2: Technical data Chapter 3: Commissioning Chapter 4: Software Chapter 5: Standards and certifications Chapter 6: Accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 4 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 5 Chapter 7: Maintenance / Servicing Appendix A Figure index Table index Model number index Index Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 6 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 7: Table Of Contents

    1.4 Configuration - Drives, software, accessories ............... 40 2. Entire device ........................41 2.1 Overview of APC810 1 card slot variations ..............41 2.1.1 Interfaces ........................ 41 2.1.2 Technical data ......................43 2.1.3 Dimensions ......................45 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 8 2.10.7 USB interfaces (USB1, 2, 3, 4, 5) ................. 88 2.10.8 MIC, Line IN, Line OUT ..................90 2.10.9 Add-on interface slot ..................... 91 2.10.10 Add-on UPS slot ....................92 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 9 3.8.1 AP Link SDL transmitter 5AC801.SDL0-00 ............152 3.8.2 Ready relay 5AC801.RDYR-00 ................155 3.9 Add-on interfaces (IF option) ..................156 3.9.1 Add-on CAN interface - 5AC600.CANI-00 ............157 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 10 4.7.3 Cables ........................189 4.7.4 BIOS settings ......................190 4.8 Four Automation Panel 900 units via SDL (AP Link) ........... 191 4.8.1 Basic system requirements ................... 191 4.8.2 Link modules ......................192 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 11 1.4.2 PCI Configuration ....................224 1.4.3 PCI express configuration ..................229 1.4.4 Graphics configuration ..................231 1.4.5 CPU configuration ....................235 1.4.6 Chipset configuration .................... 236 1.4.7 I/O interface configuration ..................238 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 12 3.1 Known problems ......................298 4. Automation PC 810 with Windows XP Professional ............300 4.1 Installation ........................300 4.1.1 Installation on PCI SATA RAID controller - 5ACPCI.RAIC-03, 5ACPCI.RAIC-05 301 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 13 5.1.2 Special considerations for the 5PCI slot model ............ 304 5.2 Drivers ......................... 305 5.3 Special considerations, limitations: ................305 6. Automation PC 810 with Windows Embedded Standard 2009 ......... 306 6.1 General Information ..................... 306 6.2 Features with WES2009 (Windows Embedded Standard 2009) ......... 307 6.3 Installation ........................
  • Page 14 3. Replacement CMOS batteries ..................353 3.1 Order data ........................353 3.2 Technical data ......................353 4. Replacement fan ....................... 354 5. DVI - monitor adapter 5AC900.1000-00 ................355 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 15 11.1 Order data ......................... 380 11.2 Features ........................380 11.3 Requirements ......................380 11.4 Individual components ....................381 11.4.1 Add-on UPS module 5AC600.UPSI-00 ............... 381 11.4.2 Battery unit 5AC600.UPSB-00 ................383 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 16 14.4.3 Flex radius specification ..................410 14.4.4 Dimensions ......................410 14.4.5 Contents of delivery .................... 411 14.4.6 Construction ......................411 14.4.7 Cable specifications .................... 412 14.5 SDL flex cable with extender 5CASDL.0x00-13 ............413 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 17 6.2 Installation with installed add-on interface module ............447 6.2.1 APC810 1 card slot ....................447 6.2.2 APC810 2 and 5 card slot ..................449 6.2.3 APC810 5 card slot ....................451 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 18 4. B&R Key Editor information ....................465 5. B&R Automation Device Interface (ADI) development kit ..........467 6. B&R Automation Device Interface (ADI) .NET SDK ............469 7. Glossary ..........................471 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 19: Chapter 1: General Information

    - B&R USB flash drive added to the chapter 6 "Accessories" on page 376. - Section 5 "Automation PC 810 with Windows 7", on page 303 in chapter 4 "Software" added. - GM45 BIOS Version updated from V1.10 to V1.11, see page 217.
  • Page 20 Automation Device Interface (ADI) development kit", on page 467 and "B&R Automation Device Interface (ADI) .NET SDK", on page 469 updated. - Informations about „special considerations for the 5PCI slot model“ added at "Automation PC 810 with Windows XP Professional", on page 300 and "Automation PC 810 with Windows 7", on page 303.

  • Page 21: Safety Notices

    Components can only be touched on the small sides or on the front plate. • Components should always be stored in a suitable medium (ESD packaging, conductive foam, etc.). Metallic surfaces are not suitable storage surfaces! Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 22: Policy And Procedures

    2.4 Transport and storage During transport and storage, devices must be protected against impermissible stress (mechanical loads, temperature, humidity, aggressive atmospheres, etc.). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 23: Installation

    Automation Panel or Power Panel are protected on the front side. The rear side of all devices must be protected from dust and humidity and must be cleaned at suitable intervals. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 24: Programs, Viruses, And Dangerous Programs

    Uninterruptible power supply Cables Cardboard box / paper packaging Paper / cardboard recycling Plastic packaging Plastic recycling Table 2: Environmentally-friendly separation of materials Disposal must comply with the respective legal regulations. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 25: Organization Of Safety Notices

    Disregarding safety guidelines and notices can result in injury or damage to equipment. Information: Important information for preventing errors. Table 3: Organization of safety notices 4. Directives European dimension standards apply to all dimensions (e.g. dimension diagrams, etc.). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 26: Model Numbers

    APC810 bus unit with 4 PCI slots and one PCIe slot. 5PC810.BX05-01 APC810 bus 2PCI 3PCIe.x1 See page 106 APC810 bus unit with 2 PCI slots and 3 PCIe slots. Table 5: Model numbers - Bus units Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 27: Gm45 Cpu Board

    250 GB SATA hard disk (slide-in compact); 24/7 hard disk with extended temperature range. 5AC801.HDDS-00 APC810 slide-in HDD 40GB See page 125 40 GB SATA hard disk (slide-in), 24/7 hard disk with extended temperature range. Table 9: Model numbers - Drives Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 28: Fan Kits

    Short description Note 5AC600.CANI-00 Add-on CAN interface See page 157 CAN interface for installation in an APC620, APC800 or PPC700. Table 12: Model numbers - Add-on interfaces (IF option) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 29: Uninterruptible Power Supply

    See page 355 DVI-I interface. 5CFCRD.0512-04 CompactFlash 512 MB B&R See page 356 CompactFlash card with 512 MB SLC NAND flash and IDE/ATA interface Table 14: Model numbers - Accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 30 Power supply, 1-phase, 5 A See page 388 24 VDC power supply, 1 phase, 5 A, input 115/230 VAC, manual select, DIN rail mounting Table 14: Model numbers - Accessories (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 31: Software

    Only delivered with a new PC. 9S0000.01-020 OEM MS-DOS 6.22 English (disk) OEM MS-DOS 6.22 English disks See page 298 Only delivered with a new PC. Table 15: Model numbers - Software Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 32 Microsoft OEM Windows Embedded Standard 7 Premium 32-bit, multilanguage; for APC810 See page 309 with GM45 chipset; order CompactFlash separately (at least 8 GB) Table 15: Model numbers - Software Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 33 GM45 chipset; order CompactFlash separately (at least 16 GB) 5SWWI7.0900-MUL WES7P 32bit Language Pack DVD See page 309 5SWWI7.1000-MUL WES7P 64bit Language Pack DVD See page 309 Table 15: Model numbers - Software Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 34: Typical Topology

    Power Panel 300 Remote I/O systems Remote I/O systems CAN bus X20 System Remote I/O systems X20 System ACOPOS ACOPOS ACOPOS Figure 1: APC810 for central control and visualization Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 35: Apc810 As A Visualization Device

    Control system Control system X20 System X20 System Drive technology Drive technology Remote I/O systems Remote I/O systems ACOPOS ACOPOS ACOPOS ACOPOS Figure 2: APC810 as a visualization device Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 36 General information • Typical topology Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 37: Chapter 2: Technical Data

    (for PCI/PCI Express cards) provide the optimum design for every type of installation - a perfect fit without wasting valuable space in the control cabinet. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 38: Features

    • CPU board • Heat sink • Main memory • Fan kits • Drive (mass memory such as CompactFlash card or hard disk) for the operating system • Software Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 39: Configuration - Basic System

    5AC801.HS00-01 Main memory 1 or 2 can be selected (max. 3 GB can be used) 5MMDDR.2048-01 - 2 GB 5MMDDR.1024-01 - 1 GB Figure 3: Configuration - Basic system Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 40: Configuration - Drives, Software, Accessories

    5SWWI7.0100-ENG (Win7 32 Bit English) 9S0000.01-010 (MS-DOS 6.22 German) 5SWWI7.0200-GER (Win7 64 Bit German) 9S0000.01-020 (MS-DOS 6.22 English 5SWWI7.0200-ENG (Win7 64 Bit English) Figure 4: Configuration - Drives, software, accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 41: Entire Device

    APC810 must be sent for repair. Removal of the mounting screws, which can be determined by a broken seal, voids all warranty. During operation, surface temperatures of the heat sink may reach 70°C (warning "hot surface"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 42 The orange front doors contain two permanent magnets. Contact between a data carrier that saves data magnetically (hard disk, diskette, the magnetic strip of a credit card, etc.) and a magnet can cause loss of data. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 43: Technical Data

    Yes, accessible behind the orange front doors LEDs 4 directed outwards via fiber optic lines, also see section "Status LEDs", on page 94 Buzzer Table 16: Technical data - APC810, 1 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 44 4) Maximum values, as long as no other individual component specifies any other. 5) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 45: Dimensions

    30 to 120 mm ± 0.3 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm Figure 7: Dimensions - APC810 1 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 46: Overview Of Apc810 2 Card Slot Variations

    APC810 must be sent for repair. Removal of the mounting screws, which can be determined by a broken seal, voids all warranty. During operation, surface temperatures of the heat sink may reach 70°C (warning "hot surface"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 47 The orange front doors contain two permanent magnets. Contact between a data carrier that saves data magnetically (hard disk, diskette, the magnetic strip of a credit card, etc.) and a magnet can cause loss of data. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 48: Technical Data

    Yes, accessible behind the orange front doors LEDs 4 directed outwards via fiber optic lines, also see section "Status LEDs", on page 94 Buzzer Table 17: Technical data - APC810, 2 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 49 4) Maximum values, as long as no other individual component specifies any other. 5) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 50: Dimensions

    30 to 120 mm ± 0.3 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm 110.5 Figure 10: Dimensions - APC810 2 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 51: Overview Of Apc810 3 Card Slot Variations

    APC810 must be sent for repair. Removal of the mounting screws, which can be determined by a broken seal, voids all warranty. During operation, surface temperatures of the heat sink may reach 70°C (warning "hot surface"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 52 The orange front doors contain two permanent magnets. Contact between a data carrier that saves data magnetically (hard disk, diskette, the magnetic strip of a credit card, etc.) and a magnet can cause loss of data. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 53: Technical Data

    Yes, accessible behind the orange front doors LEDs 4 directed outwards via fiber optic lines, also see section "Status LEDs", on page 94 Buzzer Table 18: Technical data - APC810, 3 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 54 4) Maximum values, as long as no other individual component specifies any other. 5) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 55: Dimensions

    30 to 120 mm ± 0.3 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm Figure 13: Dimensions - APC810 3 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 56: Overview Of Apc810 5 Card Slot Variations

    APC810 must be sent for repair. Removal of the mounting screws, which can be determined by a broken seal, voids all warranty. During operation, surface temperatures of the heat sink may reach 70°C (warning "hot surface"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 57 The orange front doors contain two permanent magnets. Contact between a data carrier that saves data magnetically (hard disk, diskette, the magnetic strip of a credit card, etc.) and a magnet can cause loss of data. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 58: Technical Data

    Yes, accessible behind the orange front doors LEDs 4 directed outwards via fiber optic lines, also see section "Status LEDs", on page 94 Buzzer Table 19: Technical data - APC810, 5 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 59 4) Maximum values, as long as no other individual component specifies any other. 5) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 60: Dimensions

    30 to 120 mm ± 0.3 mm ± 0.5 mm over 120 to 400 ± 0.8 mm over 400 to 1000 191.4 Figure 16: Dimensions - APC810 5 card slot variant Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 61: Ambient Temperatures

    What must be considered when determining the maximum ambient temperature? • Operation of the Ethernet interfaces (ETH1/ETH2) in 10/100Mbit or 1 Gbit mode • Revision of heat sink being used Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 62: Maximum Ambient Temperature With A Fan Kit

    1) With horizontal mounting, the maximum ambient temperature, must be reduced by 5°C! 2) Only possible with a CompactFlash card from B&R ( 5CFCRD.xxxx-04 or 5CFCRD.xxxx-03) Figure 17: Ambient temperatures with a fan kit Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 63: Minimum Ambient Temperature

    (e.g. HDD thermometer - freeware) in Microsoft Windows XP/embedded. 1) The measured temperature is a guideline for the immediate ambient temperature, but can be influenced by neighboring components. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 64: Humidity Specifications

    The listed specifications correspond to the relative humidity at an ambient temperature of 30°C. More detailed information about the specific temperature-dependent humidity values can be found in the technical data for the individual components. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 65: Power Management

    An additional DC/DC converter generates +12 V. The optional Add-on UPS (with battery unit) is supplied with 15 V and provides an uninterrupted power supply from the 15 V bus during power failures. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 66: Power Calculation With 5Pc810.Sx01-00 Revision >= D0

    1) The total performance of one PCI / PCIe card per PCI slot (= sum of power consumptions for each voltage area) may not exceed the limits stated for operation with fan kit. Figure 19: Power calculation with 5PC810.SX01-00 revision >= D0 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 67: Power Calculation With 5Pc810.Sx01-00 Revision < D0

    1) The total performance of one PCI / PCIe card per PCI slot (= sum of power consumptions for each voltage area) may not exceed the limits stated for operation with fan kit. Figure 20: Power calculation with 5PC810.SX01-00 revision < D0 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 68: Power Calculation With 5Pc810.Sx02-00 Revision>= D0

    1) The total performance of one PCI / PCIe card per PCI slot (= sum of power consumptions for each voltage area) may not exceed the limits stated for operation with fan kit. Figure 21: Power calculation with 5PC810.SX02-00 revision >= D0 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 69: Power Calculation With 5Pc810.Sx02-00 Revision < D0

    1) The total performance of one PCI / PCIe card per PCI slot (= sum of power consumptions for each voltage area) may not exceed the limits stated for operation with fan kit. Figure 22: Power calculation with 5PC810.SX02-00 revision < D0 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 70: Power Calculation With 5Pc810.Sx03-00

    1) The total performance of one PCI / PCIe card per PCI slot (= sum of power consumptions for each voltage area) may not exceed the limits stated for operation with fan kit. Figure 23: Power calculation with 5PC810.SX03-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 71: Power Calculation With 5Pc810.Sx05-00

    1) The total performance of one PCI / PCIe card per PCI slot (= sum of power consumptions for each voltage area) may not exceed the limits stated for operation with fan kit. Figure 24: Power calculation with 5PC810.SX05-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 72: Serial Number Sticker

    Figure 25: Serial number sticker (front) A sticker with detailed information about the individual components can also be found on the back side of the mounting plate. Figure 26: Serial number sticker (back) Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 73 The search provides you with a detailed list of the individual components. Serial number entry e.g. A3C70168444 List of installed components after the serial number searc Figure 27: Example of serial number search - A3C70168444 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 74: Block Diagram

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 28: Block diagram 5PC810.SX01-00 + 5PC810.BX01-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 75: System Unit 5Pc810.Sx01-00 + Bus Unit 5Pc810.Bx01-01

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 29: Block diagram 5PC810.SX01-00 + 5PC810.BX01-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 76: System Unit 5Pc810.Sx02-00 + Bus Unit 5Pc810.Bx02-00

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 30: Block diagram 5PC810.SX02-00 + 5PC810.BX02-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 77: System Unit 5Pc810.Sx02-00 + Bus Unit 5Pc810.Bx02-01

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 31: Block diagram 5PC810.SX02-00 + 5PC810.BX02-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 78: System Unit 5Pc810.Sx03-00 + Bus Unit 5Pc810.Bx03-00

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 32: Block diagram 5PC810.SX03-00 + 5PC810.BX03-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 79: System Unit 5Pc810.Sx05-00 + Bus Unit 5Pc810.Bx05-00

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 33: Block diagram 5PC810.SX05-00 + 5PC810.BX05-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 80: System Unit 5Pc810.Sx05-00 + Bus Unit 5Pc810.Bx05-01

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 34: Block diagram 5PC810.SX05-00 + 5PC810.BX05-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 81: System Unit 5Pc810.Sx05-00 + Bus Unit 5Pc810.Bx05-02

    Isolated 3-pin DC/DC + 3.3 Volt Switching Piezzo Buzzer DC/DC + 12 Volt Switching Interface fed toward outside Interface optional or internal Figure 35: Block diagram 5PC810.SX05-00 + 5PC810.BX05-02 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 82: Device Interfaces

    3-pin, male Description Functional ground Accessories 0TB103.9 Plug 24 V 5.08 3p screw clamps 0TB103.91 Plug 24 V 5.08 3p cage clamps Table 21: Supply voltage connection + 24VDC Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 83 The M4 self-locking nut can be used, for example, to fasten a copper strip that is built into the APC810 at a central grounding point in the control cabinet or system. The largest possible conductor cross section should be used (at least 2.5 mm²). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 84: Serial Interface Com1

    1) The interfaces, etc. available on the device or module were numbered accordingly for easy identification. This numbering can differ from the numbering used by the particular operating system. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 85: Serial Interface Com2

    For details, see technical data for the CPU board being used. CPU board Video signals with all system unit variations 5PC800.BM45-00 RGB, DVI, SDL 5PC800.BM45-01 RGB, DVI, SDL Table 24: Monitor / Panel connection - RGB, DVI, SDL Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 86: Ethernet 1 (Eth1)

    B&R homepage (www.br- automation.com). Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 87: Ethernet 2 (Eth2)

    B&R homepage (www.br- automation.com). Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 88: Usb Interfaces (Usb1, 2, 3, 4, 5)

    2) For safety, every USB port is equipped with a maintenance free "USB current-limiting circuit breaker" (max. 500 mA or 1 A). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 89 1) The interfaces, etc. available on the device or module were numbered accordingly for easy identification. This numbering can differ from the numbering used by the particular operating system. 2) For safety, the USB port is equipped with a maintenance free "USB current-limiting circuit breaker" (max. 1 A) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 90: Mic, Line In, Line Out

    Since the Intel GM45 chipset used in the 5PC800.BM45-0x doesn't support AC97 sound, the MIC, Line In and Line OUT connections are not supported. MIC, Line IN, Line OUT 3.5 mm jack, female Table 29: MIC, Line IN, Line OUT Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 91: Add-On Interface Slot

    An optional add-on interface (e.g. CAN, RS485) can be installed here. See also 3.9 "Add-on interfaces (IF option)", on page 156. Add-on interface slot Available add-on interfaces 5AC600.CANI-00 Add-on CAN interface 5AC600.458I-00 Add-on RS232/422/458 interface IF Option Table 30: Add-on interface slot Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 92: Add-On Ups Slot

    DVI and SDL, but without RGB signals. Furthermore, the APC810 ready relay 5AC801.RDYR-00 can also be mounted. Information: Installation of AP Link cards is only possible in connection with the system units 5PC810.SX02-00, 5PC810.SX03-00 and 5PC810.SX05-00. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 93: Card Slot (Pci / Pcie)

    All values in mm 17.4 25.8 Figure 37: Dimensions - Standard half-size PCI card 167.65 11.65 3.65 All values in mm 49.65 57.15 59.05 Figure 38: Dimensions - Standard half-size PCIe card Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 94: Status Leds

    1) Only lit when add-on UPS module is installed. The light for the Status LEDs is fed to the front cover via fiber optic lines. Figure 39: Front-side status LEDs Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 95: Cmos Profile Switch

    The position of the CMOS profile switch is is displayed in the BIOS setup pages and in the B&R ADI Control Center, among other places. 2.10.15 Power button The power button has a variety of functions due to full ATX power supply support. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 96: Reset Button

    The APC810 is restarted (cold restart). The MTCX processor is not reset when the reset button is pressed. Table 35: Reset button Warning! A system reset can result in data loss! Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 97: Battery

    Data buffering is guaranteed for approx. another 500 hours from the point in time that the battery capacity is determined to be BAD (insufficient). Table 37: Meaning of battery status Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 98: Hardware Security Key

    A hardware security key (dongle) can be inserted behind the black cover. Table 38: Hardware security key Warning! Turn off power before removing or adding the hardware security key. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 99: Compactflash Slot 1

    CompactFlash 2048 MB SSI 5CFCRD.4096-03 CompactFlash 4096 MB SSI 5CFCRD.8192-03 CompactFlash 8192 MB SSI Table 39: CompactFlash slot (CF1) Warning! Turn off power before inserting or removing the CompactFlash card! Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 100: Compactflash Slot 2

    2.10.20 CompactFlash slot 2 Since the Intel GM45 chipset used on 5PC800.BM45-0x doesn't support an IDE (PATA) channel, the CF2 slot is not supported. CompactFlash slot (CF2) Table 40: CompactFlash slot (CF2) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 101: Slide-In Slot 1

    Table 41: Slide-in slot 1 Information: The SATA I interface allows data carriers to be exchanged during operation (hot- plug). To utilize this capability, it must be supported by the operating system. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 102: Slide-In Slot 2

    1 for mechanical reasons (closing the front door). Information: The SATA I interface allows data carriers to be exchanged during operation (hot- plug). To utilize this capability, it must be supported by the operating system. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 103: Slide-In Compact Slot

    To utilize this capability, it must be supported by the operating system. For information about installing / exchanging a slide-in compact drive, see the section "Installing / exchanging a slide-in compact drive", on page 434. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 104: Individual Components

    Slot for slide-in compact drive Slot for add-on UPS module Reset button Power button CMOS profile switch Battery compartment Hardware security compartment Fan kit insert Table 44: Technical data - System units Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 105 2) For more information about Maintenance Controller Extended, see the section "Maintenance Controller Extended (MTCX)", on page 462. 3) Depending on the process or batch, there may be visible deviations in the color and surface structure. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 106: Bus Units

    2 PCI slots 1 PCIe slot 1 PCI slot 5PC810.BX02-01 5PC810.BX02-00 Figure 41: 2 slot bus units 1 PCIe slot 2 PCI slots 5PC810.BX03-00 Figure 42: 3 slot bus units Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 107: Technical Data

    1.0a 1.0a 1.0a 1.0a 1.0a Bus speed x4 (10 GB/s) x4 (10 GB/s) x4 (10 GB/s) x1 (2.5 x1 (2.5 GB/s) GB/s) Table 45: Technical data - Bus units Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 108: Cpu Boards Gm45

    1) At max. specified ambient temperature: typically 58 ppm (5 seconds) - worst-case 220 ppm (19 seconds). 2) The SATA 2 port is not used internally on the APC810, and the SATA 3 port is used internally for the SATA to PATA bridge. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 109: Heat Sink

    Material Aluminum, black-coated with copper heat pipes Outer dimensions Width 228.7 mm Height 218 mm Depth 28 mm Weight Approx. 2 kg Table 47: Technical data - Heat sink Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 110: Main Memory

    204 Pin SO-DIMM Organization 256M x 64-bit 512M x 64-bit Table 48: Technical data - Main memory Information: A main memory module can only be replaced at the B&R plant. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 111: Drives

    Number of heads Number of sectors (user) 78,140,160 Bytes per sector Revolution speed 5400 rpm Access time (average) 12.5 ms Table 49: Technical data - Add-on hard disk - 5AC801.HDDI-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 112 2) Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. 3) Humidity gradient: Maximum 15% per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 113 Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 114: Slide-In Compact Hdd 160 Gb 24X7 Et - 5Ac801.Hddi-02

    Positioning time (seek, typical values) Minimum (track to track) 1.5 ms Average (read access) 12 ms Maximum (read access) 22 ms Table 50: Technical data - Slide-in compact HDD - 5AC801.HDDI-02 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 115 2) Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. 3) Humidity gradient: Maximum 15% per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 116 Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 117: Slide-In Compact Hdd 250Gb - 5Ac801.Hddi-03

    Average (read access) 14 ms Maximum (read access) 30 ms Starting time (0 rpm to read access) 3.6 seconds (typically) Table 51: Technical data - Slide-in compact HDD - 5AC801.HDDI-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 118 20°C per hour. 3) 24-hour operation means 732 POH (power-on hours) per month. 4) Humidity gradient: Maximum 30% per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 119 Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 120: Slide-In Compact Ssd - 5Ac801.Ssdi-00

    For the entire device in which this individual component is used, refer to the data given specifically for the entire device. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 121 2.17 g at 7 - 800 Hz Storage 3.13 g at 10 - 500 Hz Transport 3.13 g at 10 - 500 Hz Table 52: Technical data - Slide-in compact SSD - 5AC801.SSDI-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 122 Figure 54: Temperature humidity diagram - 5AC801.SSDI-00 Benchmark The following two benchmarks show a comparison of the Intel Solid State Drive (5AC801.SSDI- 00) and the Seagate Hard Disk (5AC801.HDDI-00) for cyclic reading and writing. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 123 5AC810.SSDI-00 5AC810.HDDI-00 Figure 55: ATTO disk benchmark v2.34 - cyclic read 1024 2048 4096 8192 Transfer size [kb] 5AC810.SSDI-00 5AC810.HDDI-00 Figure 56: ATTO disk benchmark v2.34 - cyclic write Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 124: Hard Disk Adapter (Slide-In Compact) - 5Ac801.Adas-00

    1 for mechanical reasons (closing the front door). Mechanical characteristics 5AC801.ADAS-00 Outer dimensions Height 172.5 mm Width 22 mm Depth 150 mm Weight 328 g Table 53: Technical data - Slide-in HDD adapter - 5AC801.ADAS-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 125: Slide-In Hdd Ee25 - 5Ac801.Hdds-00

    Average (read access) 12.5 ms Maximum (read access) 23 ms Starting time (0 rpm to read access) 3 seconds (typically) Table 54: Technical data - Slide-in HDD EE25 - 5AC801.HDDS-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 126 2) Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. 3) Humidity gradient: Maximum 15% per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 127 Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 128: Slide-In Dvd-Rom - 5Ac801.Dvds-00

    130 ms 140 ms Revolution speed Max. 5090 rpm ±1% Starting time (0 rpm to read access) 19 seconds (maximum) Host interface SATA Table 55: Technical data - 5AC801.DVDS-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 129 1) Temperature data is for operation at 500 meters. Derating the max. ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2) Drive surface temperature Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 130 1°C per 1000 meters (from 500 meters above sea level). Hot plug capable Hardware revision B0 of the slide-in DVD-ROM - 5AC801.DVDS-00 does not offer SATA hot plug capability. Other hardware revisions are hot plug capable. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 131: Slide-In Dvd-R/Rw - 5Ac801.Dvrs-00

    6x, 4x and 2, 4x DVD+RW 4x and 2x Reading rate max. 24x max. 8x Data transfer rate Max. 33.3 MB/s Table 56: Technical data - Slide-in DVD-R/RW, DVD+R/RW - 5AC801.DVRS-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 132 At max. 5 - 500 Hz and 2 g Transport At max. 5 - 500 Hz and 2 g Table 56: Technical data - Slide-in DVD-R/RW, DVD+R/RW - 5AC801.DVRS-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 133 Figure 63: Temperature humidity diagram - Slide-in DVD-R/RW, DVD+R/RW - 5AC801.DVRS-00 Temperature data is for operation at 500 meters. Derating the max. ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 134: Pci Sata Raid 2 X 160 Gb 24X7 Et - 5Acpci.raic-03

    (UPS). If the operating system is shut down improperly, the next time it is started it is detected as an error by the RAID 1, and a complete rebuild is executed. This generally takes at least 120 minutes (configurable) to complete. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 135 0.3 A at 3.3 V (PCI bus) 1 A at 5 V (PCI bus) Mechanical characteristics Mounted on PCI insert Fixed Weight 350 g Table 57: Technical data - RAID hard disk - 5ACPCI.RAIC-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 136 4) Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate). Temperature humidity diagram - Operation and storage Operation Temperature [°C] Figure 65: Temperature humidity diagram - SATA RAID hard disk 5ACPCI.RAIC-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 137 5ACPCI.RAIC-02 is available as a replacement part for a HDD. For instructions on exchanging the drive, see Chapter 7 "Maintenance / Servicing", section "Mounting the side cover", on page 453. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 138: Replacement Pci Sata Raid Hdd 160 Gb - 5Acpci.raic-04

    SATA 1.0, PIO mode 0-4, multiword DMA mode 0-2, UDMA 0-5 Data transfer rate On the medium Max. 84.6 Mbit/s To/from host Max. 150 MB/s Table 58: Technical data - RAID hard disk - 5ACPCI.RAIC-04 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 139 3) Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate). 4) Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 140 Technical data • Individual components Temperature humidity diagram - Operation and storage Operation Temperature [°C] Figure 67: Temperature humidity diagram - SATA RAID hard disk 5ACPCI.RAIC-04 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 141: Pci Sata Raid 2 X 250 Gb - 5Acpci.raic-05

    (UPS). If the operating system is shut down improperly, the next time it is started it is detected as an error by the RAID 1, and a complete rebuild is executed. This generally takes at least 120 minutes (configurable) to complete. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 142 0.3 A at 3.3 V (PCI bus) 1 A at 5 V (PCI bus) Mechanical characteristics Mounted on PCI insert Fixed Weight 350 g Table 59: Technical data - RAID Hard Disk - 5ACPCI.RAIC-05 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 143 4) Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate). Temperature humidity diagram Storage Operation Transport Temperature [°C] Figure 69: Temperature humidity diagram - SATA RAID Hard Disk - 5ACPCI.RAIC-05 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 144 5MMHDD.0250-00 is available as a replacement part for a HDD. For instructions on exchanging the drive, see Chapter 7 "Maintenance / Servicing", section "Mounting the side cover", on page 453. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 145: Replacement Sata Hdd 250 Gb - 5Mmhdd.0250-00

    Supported transfer modes SATA 1.0, Serial ATA Revision 2.6 PIO mode 0-4, multiword DMA mode 0-2, UDMA mode 0-6 Interface SATA Table 60: Technical data - RAID hard disk - 5MMHDD.0250-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 146 20°C per hour. 3) 24-hour operation means 732 POH (power-on hours) per month. 4) Humidity gradient: Maximum 30% per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 147 Temperature values for 305 meter altitude. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature increase and decrease can be a maximum of 20°C per hour. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 148: Fan Kit

    An exchange or cleaning of the filter kit is appropriate at that time. Table 61: Technical data - 5PC810.FA01-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 149: Fan Kit 2 Card Slot - 5Pc810.Fa02-01

    This fan kit is an optional addition for system units with 3 card slots. For available replacement dust filters for this fan kit, see section "Replacement fan", on page 354. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 150 Table 63: Technical data - 5PC810.FA03-00 For information about installing or exchanging the fan kits, see the section "Installing / exchanging the fan kit", on page 438. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 151: Fan Kit 5 Card Slot - 5Pc810.Fa05-00

    Table 64: Technical data - 5PC810.FA05-00 For information about installing or exchanging the fan kits, see the section "Installing / exchanging the fan kit", on page 438. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 152: Ap Link Cards

    5PC810.SX02-00, 5PC810.SX03-00 and 5PC810.SX05-00. You can find information on installing the AP link SDL transmitters under "AP Link installation", on page 455. Figure 77: Mounting example with the system unit 5PC810.SX02-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 153 5CASDL.0100-01 5CASDL.0100-01 5CASDL.0100-01 5CASDL.0100-01 5CASDL.0100-03 5CASDL.0100-03 5CASDL.0100-03 5CASDL.0100-03 5CASDL.0100-03 5CASDL.0150-00 5CASDL.0150-00 5CASDL.0150-00 5CASDL.0150-00 5CASDL.0150-01 5CASDL.0150-01 5CASDL.0150-01 5CASDL.0150-01 5CASDL.0150-03 5CASDL.0150-03 5CASDL.0150-03 5CASDL.0150-03 Table 66: Segment lengths, resolutions and SDL cables Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 154 5CASDL.0250-00 5CASDL.0250-00 5CASDL.0250-30 5CASDL.0250-30 5CASDL.0250-30 5CASDL.0300-00 5CASDL.0300-00 5CASDL.0300-10 5CASDL.0300-10 5CASDL.0300-03 5CASDL.0300-03 5CASDL.0300-13 5CASDL.0300-13 5CASDL.0400-10 5CASDL.0400-10 5CASDL.0400-10 5CASDL.0400-10 5CASDL.0400-13 5CASDL.0400-13 5CASDL.0400-13 5CASDL.0400-13 Table 66: Segment lengths, resolutions and SDL cables Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 155: Ready Relay 5Ac801.Rdyr-00

    Normally closed contact n.c. Accessories 0TB704.90 Terminal block, 4-pin, Screw clamp, 1.5 mm² TB704.91 Terminal block, 4-pin, Cage clamps, 2.5 mm² Table 67: Pin assignments - Ready relay 5AC801.RDYR-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 156: Add-On Interfaces (If Option)

    Figure 80: Add-on interfaces (IF option) Information: It is possible to add or remove an add-on interface at any time. Caution! Turn off power before adding or removing an add-on interface. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 157: Add-On Can Interface - 5Ac600.Cani-00

    Amount Connection 9-pin DSUB, male Terminating resistor Can be activated and deactivated using a sliding switch Default setting Disabled Table 69: Technical data - Add-on CAN interface - 5AC600.CANI-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 158 I/O address Register Function 384h Address register Defines the register number to access. 385h Data register Access to the register defined in the address register. Table 72: CAN address register Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 159 1 x 0.34 mm² (22AWG/19), tinned Cu wire Wire insulation ≤ 59 Ω / km Conductor resistance Outer sheathing Material PUR mixture Characteristics Halogen free Total shielding From tinned cu wires Table 74: CAN cable requirements Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 160 Because of the Dual Core processors, the INACAN.SYS driver version 2.36, contained in the PVI setup 2.6.0.3105, is required for the operation. Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 161: Add-On Rs232/422/485 Interface - 5Ac600.485I-00

    Max. 15 meters Max. 1200 meters Assignments Assignments 9-pin DSUB connector (RS232) (RS422) n.c. TXD\ n.c. n.c. n.c. n.c. RXD\ n.c. n.c. n.c. Table 76: Pin assignments - RS232/RS422 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 162 Wire insulation ≤ 59 Ω / km Conductor resistance Outer sheathing Material PUR mixture Characteristics Halogen free Total shielding From tinned cu wires Table 79: RS232 - Cable requirements Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 163 Figure 83: Add-on RS232/422/485 interface - operated in RS485 mode The RTS line must be switched each time the driver is sent and received; there is no automatic switch back. This cannot be configured in Windows. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 164 Wire insulation ≤ 59 Ω / km Conductor resistance Outer sheathing Material PUR mixture Characteristics Halogen free Total shielding From tinned cu wires Table 83: RS485 - Cable requirements Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 165 Technical data • Individual components Contents of delivery The screws included in the mounting kit are to be used for installation. Figure 84: Contents of the delivery / mounting material - 5AC600.485I-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 166 Technical data • Individual components Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 167: Chapter 3: Commissioning

    Be sure the wall or control cabinet can withstand four times the total weight of the the APC810. • When connecting certain cable types (DVI, SDL, USB, etc.), keep the flex radius of the cable in mind (see section 2 "Cable connections", on page 172). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 168: Drilling Templates

    APC810 1 card slot APC810 2 card slot Mounting plate outline (APC810) Mounting plate outline (APC810) 20.3 90.3 110.5 Table 84: Drilling templates - 1 and 2 card slot system units Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 169 APC810 5 card slot Mounting plate outline (APC810) Mounting plate outline (APC810) 25.7 95.7 165.7 191.4 30.5 100.5 Table 85: Drilling templates - 3 and 5 card slot system units Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 170: Mounting Orientation

    Operation in the optional horizontal mounting position (heat sink on top) requires the use of a fan kit. The maximum ambient temperature specification must be lowered to 5°C. 0° 0° Heat sink Figure 87: Optional mounting - horizontal Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 171: Spacing For Air Circulation

    50 mm at least air in 100 mm Figure 88: Standard mounting - Mounting distances These defined distances are valid for both vertical and horizontal mounting of the APC810. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 172: Cable Connections

    The specified flex radius can be found in the Automation Panel 800 or Automation Panel 900 user's manual, which can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 173: Grounding Concept

    Note the line shielding concept, all connected data cables are used as shielded lines. Ground connection min. 2.5mm² Switching cabinet Supply voltage Grounding strip min. 2.5mm² Figure 90: Grounding concept Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 174: Connection Examples

    AP800 device. Automation Panel 800 Automation Panel 900 5AP820.1505-00 5AP920.1505-01 5AP951.1505-01 5AP980.1505-01 5AP981.1505-01 5AP880.1505-00 5AP920.1505-01 5AP951.1505-01 5AP980.1505-01 5AP981.1505-01 Table 86: Selecting the display units Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 175: One Automation Panel 900 Via Dvi (Onboard)

    DVI-D, RS232 and USB 2.0 (Type B); 24VDC (screw clamp 0TB103.9 or cage clamp 0TB103.91 sold separately). Table 88: Link module for the configuration - One Automation Panel 900 via DVI Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 176: Cables

    1) USB support is not possible on the Automation Panel 900 because USB is limited to 5 m. Information: The DVI transfer mode does not allow reading statistical values on Automation Panel 900 units. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 177: Bios Settings

    Commissioning • Connection examples 4.2.5 BIOS settings No special BIOS settings are necessary for operation. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 178: An Automation Panel 900 Via Sdl (Onboard)

    Connection for SDL in, transfer of display data, touch screen, USB 1.1, matrix keys, and service data, 24 VDC (screw clamp 0TB103.9 or cage clamp 0TB103.91 sold separately). Table 92: Link module for the configuration - One Automation Panel 900 via SDL Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 179: Cables

    Detailed technical data about the cables can be found in the Automation Panel 900 User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 180: Bios Settings

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 181: An Automation Panel 800 Via Sdl (Onboard)

    SDL cable for fixed and flexible type of layout 25 m 5CASDL.0300-30 SDL cable with extender for fixed and flexible type of layout 30 m Table 96: Cables for SDL configurations Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 182: Bios Settings

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 183: An Ap900 And An Ap800 Via Sdl (Onboard)

    24 VDC (screw clamp 0TB103.9 or cage clamp 0TB103.91 sold separately). 1 pieces required Table 99: Link modules for configuration - One AP900 and one AP800 via SDL (onboard) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 184: Cables

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 185: Four Automation Panel 900 Units Via Sdl (Onboard)

    Resolution 5PC810.SX01-00 5PC810.SX02-00 5PC810.SX03-00 5PC810.SX05-00 ✓ ✓ ✓ ✓ 5PC800.BM45-00 Max. UXGA ✓ ✓ ✓ ✓ 5PC800.BM45-01 Max. UXGA Table 100: Possible combinations of system unit and CPU board Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 186: Link Modules

    Detailed technical data about the cables can be found in the Automation Panel 900 User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 187: Bios Settings

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 188: One Automation Panel 900 Unit Via Sdl (Ap Link)

    APC810 AP Link SDL transmitter For Automation PC 810 Automation Panel SDL link transmitter Table 105: Link modules for the configuration: 4 Automation Panel 900 via SDL on 1 line Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 189: Cables

    User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Cable lengths and resolutions for SDL transfer The following table shows the relationship between segment lengths and the maximum resolution according to the SDL cable used: Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 190: Bios Settings

    The COM D must be enabled in BIOS in order to operate the connected panel touch screen on the AP Link connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 191: Four Automation Panel 900 Units Via Sdl (Ap Link)

    5PC810.SX05-00 ✓ ✓ ✓ 5PC800.BM45-00 Max. UXGA ✓ ✓ ✓ 5PC800.BM45-01 Max. UXGA Table 108: Possible combinations of system unit and CPU board 1) AP Link cannot be installed. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 192: Link Modules

    SDL cable with extender for fixed and flexible type of layout 30 m 5CASDL.0400-13 SDL cable with extender for fixed and flexible type of layout 40 m Table 110: Cables for SDL configurations Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 193: Bios Settings

    The COM D must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 194: Two Automation Panel 900 Units Via Sdl (Onboard) And Sdl (Ap Link)

    5PC810.SX05-00 ✓ ✓ ✓ 5PC800.BM45-00 Max. UXGA ✓ ✓ ✓ 5PC800.BM45-01 Max. UXGA Table 112: Possible combinations of system unit and CPU board 1) AP Link cannot be installed. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 195: Link Modules

    Detailed technical data about the cables can be found in the Automation Panel 900 User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 196: Bios Settings

    The COM C or COM D must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel or AP Link connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 197: Eight Automation Panel 900 Units Via Sdl (Onboard) And Sdl (Ap Link)

    Link: 5DLSDL.1000-01 Link: 5DLSDL.1000-01 not possible not possible Link: 5DLSDL.1000-00 Link: 5DLSDL.1000-00 Figure 99: Configuration - Eight Automation Panel 900 units via SDL (onboard) and SDL (AP Link) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 198: Basic System Requirements

    SDL cable for a fixed type of layout 15 m 5CASDL.0150-01 SDL cable with 45° plug for fixed type of layout 15 m Table 118: Cables for SDL configurations Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 199 Detailed technical data about the cables can be found in the Automation Panel 900 User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 200: Bios Settings

    The COM C or COM D must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel or AP Link connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 201: Six Ap900 And Two Ap800 Devices Via Sdl (Onboard) And Sdl (Ap Link)

    Link: 5DLSDL.1000-01 Link: 5DLSDL.1000-01 USB not possible Automation Panel 800 Automation Panel 800 Figure 100: Configuration - Six AP900 and two AP800 devices via SDL (onboard) and SDL (AP Link) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 202: Basic System Requirements

    Automation Panel 900 User's Manual. These can be downloaded as .pdf files from the B&R homepage www.br-automation.com. The following table shows the relationship between segment lengths and the maximum resolution according to the SDL cable used: Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 203 The COM C or COM D must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel or AP Link connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 204: Connection Of Usb Peripheral Devices

    USB drives e.g. CD ROM drive USB input devices USB display devices e.g. keyboard e.g. mouse Figure 101: Local connection of USB peripheral devices on the APC810 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 205: Remote Connection To Automation Panel 900 Via Dvi

    USB input devices USB drives USB display devices e.g. keyboard e.g. CD ROM drive e.g. mouse Figure 102: Remote connection of USB peripheral devices to the APC900 via DVI Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 206: Remote Connection To Automation Panel 800/900 Via Sdl

    USB input devices USB drives USB display devices e.g. keyboard e.g. CD ROM drive e.g. mouse Figure 103: Remote connection of USB peripheral devices to the APC800/900 via SDL Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 207: Configuration Of A Sata Raid Array

    Low Level Format * 0 PM ST96023AS 55GB 1 SM ST96023AS 55GB Select Menu Previous Menu Enter Select Ctrl-E Exit First HDD Figure 105: RAID Configuration Utility - Menu Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 208: Create Raid Set

    First HDD Figure 106: RAID Configuration Utility - Menu The RAID system can be recreated as "Striped" = RAID0 or "Mirrored" = RAID1 using the menu "Create RAID set". Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 209: Create Raid Set - Striped

    Auto configuration Auto configuration optimizes all settings. "Manual configuration" It is possible to specify the first and second HDD as well as the "Chunk Size" (= block size, application-dependent). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 210: Create Raid Set - Mirrored

    Auto configuration optimizes all settings. "Manual configuration" It is possible to specify the "Source" and "Target" HDD, and also to specify whether a rebuild (mirror) should be performed immediately (approx. 50 minutes). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 211: Delete Raid Set

    Previous Menu Enter Select Ctrl-E Exit First HDD Figure 109: RAID Configuration Utility - Delete RAID set An existing RAID set can be deleted using the menu "Delete RAID set". Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 212: Rebuild Mirrored Set

    SATARaid detected a new event and the rebuild is started. The entire rebuild lasts approximately 50 minutes. If "offlinerebuild" is selected, then a rebuild is performed immediately before starting the operating system (lasts approximately 30 minutes). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 213: Resolve Conflicts

    Figure 111: RAID Configuration Utility - Resolve conflicts Conflicts in a RAID set can be resolved using the "Resolve conflicts" menu. This function is only available if the status of the hard disk is "conflict". Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 214: Low Level Format

    Individual hard disks can be configured using the "Low Level Format" menu. This can only be done if a RAID set is not configured. A low level format of a hard disk takes approx. 40 minutes. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 215: Known Problems / Issues

    This means that the device boots even when the reset button is pressed. In MTCX PX32 firmware < V00.11, the system does not start after pressing (ca. 10 seconds) and releasing the reset button. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 216: Problems And Properties Of Subsequent Production Lots

    This can be avoided by setting a panel locking time of 50 ms. The panel locking time can be configured with the B&R Key Editor. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 217: Chapter 4: Software

    1.1 General Information BIOS stands for "Basic Input Output System". It is the most basic standardized communication between the user and the system (hardware). The BIOS system used in the Automation PC 810 systems is produced by American Megatrends Inc.

  • Page 218: Bios Setup Keys

    The key signals from the USB keyboard are only registered after the USB controller has been initialized. Function Enters the BIOS setup menu. Using the F12 key, you can boot from the network. Table 124: BM45 bios-relevant keys at POST Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 219 The colors of the BIOS Setup are switched. Changes are reset. These settings are loaded for all BIOS configurations. Save and close. Exits the submenu. Table 125: BM45 bios-relevant keys in the BIOS menu Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 220: Main

    Displays the CPU board controller None firmware revision. MAC Address Displays the MAC addresses assigned for None (ETH1) the ETH1 interface. Table 126: BM45 - Main menu - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 221: Advanced

    See "Graphics configuration", on page 231. CPU configuration Configures the CPU settings. Enter Opens the submenu See "CPU configuration", on page 235. Table 127: BM45 - Advanced menu - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 222: Acpi Configuration

    Critical Trip Point [105°C] Select Screen Select Item Change Option General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 116: BM45 - Advanced ACPI configuration Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 223 100°C, 105°C, 110°C be set in 5 degree increments. automatically shuts itself down. Table 128: BM45 - Advanced ACPI configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 224: Pci Configuration

    See "PCI IRQ Resource Exclusion", on page 225 PCI Interrupt Configures PCI interrupt routing Enter Opens the submenu Routing See "PCI Interrupt Routing", on page 227 Table 129: BM45 - Advanced PCI configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 225 Reserved - cannot be used. Information: No ISA bus present in the APC810 system. Therefore this setting is not relevant. Table 130: BM45 - Advanced PCI IRQ resource exclusion - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 226 IRQ interrupt routing for Legacy ISA Allocated Allocated by the system - cannot be used. devices. Table 130: BM45 - Advanced PCI IRQ resource exclusion - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 227 Option for setting the PIRQ E. Auto Automatic assignment by the BIOS and operating SMB,UHCI3,EHCI1) system. 5,6,7,9,10,11,12 Manual assignment. Table 131: BM45 - Advanced PCI interrupt routing - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 228 Assigns the PIRQ as 2nd exclusive PCI IRQ. exclusively (no IRQ sharing). Information: Only displayed when two PIRQs are set manually. Table 131: BM45 - Advanced PCI interrupt routing - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 229: Pci Express Configuration

    Disabled Disables this function. If you are not using any PCI Express devices, this option should be deactivated. Table 132: BM45 - Advanced PCI express configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 230 Interrupt Controller) on the PCIE port 1. The IRQ resources available to the system are expanded when the APIC mode is enabled. Table 132: BM45 - Advanced PCI express configuration - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 231: Graphics Configuration

    (monitor / panel connection). PCI / Int. VGA The graphics chip of a connected graphics card is used as video device. Table 133: BM45 - Advanced graphics configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 232 LFP. If no EDID data is found, then the data selected under "Local Flat Panel Type" is used. Table 133: BM45 - Advanced graphics configuration - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 233 Expand Text & Graphics Text and graphics are stretched across the entire surface of the display. Table 133: BM45 - Advanced graphics configuration - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 234 DVI monitors are reconnected, even if only one of them was connected and activated during a previous boot. Table 133: BM45 - Advanced graphics configuration - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 235: Cpu Configuration

    Option for enabling or disabling hardware Disabled Disables this function. Capability support for prevention of data execution. Enabled Enables this function. Table 134: BM45 - Advanced CPU configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 236: Chipset Configuration

    POST Code Output [PCI] Select Screen Select Item Change Option General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 123: BM45 - Advanced chipset configuration Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 237 BIOS POST code output should be routed Port 80h/84h is routed to the LPC bus. to the PCI bus or the LPC bus. Table 135: BM45 - Advanced chipset - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 238: I/O Interface Configuration

    Onboard Ethernet controller is disabled. Controller (ETH1) Ethernet controller on or off. Enabled Onboard Ethernet controller is enabled. Table 136: BM45 - Advanced I/O interface configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 239: Clock Configuration

    With this option, the cycle frequency can Enabled Enables this function. be modulated by reducing Disabled Disables this function. electromagnetic disturbances. Table 137: BM45 - Advanced clock configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 240: Ide Configuration

    Option for turning integrated SATA Disabled Disables this function. PATA Port) controllers 2 and 3 on or off. Enabled Enables this function. Table 138: BM45 - Advanced IDE configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 241 2) These settings are only possible if Configure SATA Port 0/1 as is set to RAID or AHCI. 3) These settings are only possible if SATA Port 2/3 (opt. PATA Port) is set to Enabled. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 242 Table 139: BM45 - Primary IDE master - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 243 32 Bit Data Transfer This function enables 32-bit IDE data Disabled Disables this function. transfer. Enabled Enables this function. Table 139: BM45 - Primary IDE master - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 244 Table 140: BM45 - Secondary IDE master - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 245 32Bit Data Transfer [Enabled] Select Screen Select Item Change Option General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 129: BM45 - Third IDE master Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 246 Enables this function. 32 Bit Data Transfer This function enables 32-bit data transfer. Disabled Disables this function. Enabled Enables this function. Table 141: BM45 - Third IDE master - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 247 Table 142: BM45 - Fourth IDE master - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 248: Usb Configuration

    Save and Exit USB Stick Default Emulation [Hard Disk] Exit USB Mass Storage Reset Delay [20 Sec] v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 131: BM45 - Advanced USB configuration Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 249 Hard disk An HDD-formatted drive can be used as an FDD (e.g. zip drive) for starting the system. Table 143: BM45 - Advanced USB configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 250: Keyboard/Mouse Configuration

    Numeric keypad is enabled. Typematic rate The key repeat function is set here. Slow Slow key repeat. Fast Fast key repeat. Table 144: BM45 - Advanced keyboard/mouse configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 251: Cpu Board Monitor

    None degrees Celsius and Fahrenheit). Top DIMM Displays the temperature of the first None Environment Temp. DRAM module. Table 145: BM45 - Advanced remote access configuration - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 252: Main Board/Panel Features

    Enter Go to Sub Screen Product Name: 5PC810.SX02-00 General Help User Serial ID: 00000000h Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 134: BM45 - Advanced main board/panel features Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 253 ID) and can only be changed with using the "B&R Control Center" via the ADI driver. Table 146: BM45 - Advanced main board/panel features - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 254 Displays fan speed for the selected panel. None Keys/LEDs None Displays the available keys and LEDs on the selected panel. Table 147: BM45 - Panel control - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 255 1 in degrees Celsius and Fahrenheit. Slide-in drive 2 Displays the temperature of the slide-in None drive 2 in degrees Celsius and Fahrenheit. Table 148: BM45 - Main board monitor - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 256 IRQ 11, IRQ 12 COM B Settings for the COM2 serial interface in Disabled Disables the interface. the system. Enabled Enables the interface. Table 149: BM45 - Legacy devices - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 257 (ETH2) on and off. Enabled Enables the controller. ETH2 MAC Address Displays the Ethernet 2 controller MAC None address. Table 149: BM45 - Legacy devices - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 258: Boot

    The boot sequence of a device type list can be changed. Device types that are not connected can also be entered to this list. Table 150: BM45 - Boot menu - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 259 Determines if the system is on/off Remain Off Remains off. following power loss. Turn On Powers on. Last State Enables the previous state. Table 150: BM45 - Boot menu - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 260: Security

    Enables this function. program or virus. Information: With this option, only the boot sector is protected, not the entire hard drive. Table 151: BM45 - Security menu - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 261 Enter Opens the submenu Master Passwords can be created here. See "Hard disk security master password", on page 263 Table 151: BM45 - Security menu - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 262: Hard Disk Security User Password

    A user password allows the user to edit only certain BIOS settings. Table 152: BM45 - Hard disk security user password Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 263: Hard Disk Security Master Password

    Enter Enter password. Master Password user password to change or configure each hard drive without having to reboot the device. Table 153: BM45 - Hard disk security master password Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 264: Power

    IGNORE Activities are ignored. Table 154: BM45 - Power menu - Setting options Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 265 Power Button Mode This function determines the function of On/Off Power button switches on/off. the power button. Suspend Suppresses the function. Table 154: BM45 - Power menu - Setting options (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 266: Exit

    The various positions of the CMOS profile hex switch (see figure "Interface overview - APC810, 2 card slot variant (front)", on page 47) can be used to load pre-defined BIOS profile settings. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 267 The following pages provide an overview of the BIOS default settings for the different CMOS profile switch positions. Settings highlighted in yellow are variations from the BIOS default profile (=profile 0). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 268: Main

    Active Cooling Trip Point Disabled Disabled Disabled Passive Cooling Trip Point Disabled Disabled Disabled Critical Trip Point 105°C 105°C 105°C Table 158: BM45 - Advanced ACPI configuration - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 269 PIRQ G (INTB) Auto Auto Auto PIRQ H (INTC,UHCI0, Auto Auto Auto EHCI0) 1st Exclusive PCI 2nd Exclusive PCI Table 159: BM45 - Advanced PCI configuration - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 270 Configuration SDVO Port C SDVO DVI SDVO DVI SDVO DVI Configuration SDVO/DVI Hotplug Enabled Enabled Enabled Support Table 161: BM45 - Advanced graphics configuration - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 271 Profile 2 My setting HDA Controller Disabled Disabled Disabled Onboard Gbe Controller Enabled Enabled Enabled (ETH1) Table 164: BM45 - Advanced I/O interface configuration - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 272 Auto Block (Multi-Sector Auto Auto Auto Transfer) PIO Mode Auto Auto Auto DMA Mode Auto Auto Auto Table 166: BM45 - Advanced IDE configuration - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 273 Hard disk Hard disk Hard disk Emulation USB Mass Storage Reset 20 Sec 20 Sec 20 Sec Delay Table 167: BM45 - Advanced USB configuration - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 274 Slide-in drive 1 Slide-in drive 2 ETH2 Controller Baseboard monitor Case 1 Case 2 Case 3 Case 4 Table 170: BM45 - Advanced main board/panel features - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 275: Boot

    Keep Current Keep Current Keep Current Mode Halt On Error Disabled Disabled Disabled Hit "DEL" Message Enabled Enabled Enabled Display Table 171: BM45 - Boot - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 276: Security

    Resume on PME# Disabled Disabled Disabled Resume On RTC Alarm Disabled Disabled Disabled Power Button Mode On/Off On/Off On/Off Table 173: BM45 - Power - Overview of profile settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 277: Bios Error Signals (Beep Codes)

    Software • BIOS options 1.10 BIOS Error signals (beep codes) While the Automation PC 810 is booting, the following messages and errors can occur with BIOS. These errors are signaled by different beeping codes. 1.10.1 BIOS BM45 Beeping code Meaning...

  • Page 278: Distribution Of Resources

    1) TOM - Top of memory: max. installed DRAM 2) Only if ACPI Aware OS is set to "YES" in the setup. 3) The VGA frame buffer can be reduced to 32 MB in the setup. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 279: I/O Address Assignment

    1) The BIOS assigns the PCI and PCI Express Bus I/O resources from FFF0h downward. Devices that are not compatible with PnP/PCI/PCI Express cannot use the I/O resources in this area. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 280: Interrupt Assignments In Pci Mode

    2) If the SATA configuration in BIOS is set to Enhanced mode for all SARA ports, IRQs 14 and 15 are enabled for the system and the SATA ports use other IRQs. ● ... Default setting ❍ ... Optional setting Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 281: Interrupt Assignments In Apic Mode

    3) PIRQ A: for PCIe; UHCI host controller 2, VGA controller, PCI express root port 0, PCI-EX to SATA bridge 4) PIRQ B: for PCIe; HDA audio, PCI express root port 1, onboard gigabit LAN controller Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 282 PCI 1 5PC810.BX05-00 PCIe 4 PCIe 3 PCIe 2 PCI 2 PCI 1 5PC810.BX05-01 Figure 145: PCI and PCIe routing with activated APIC CPU boards BM45 (bus units 5PC810.BX0x-0x) Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 283 Intel 82567 are shifted 1 digit back. (see block diagram of the 5PC810.BX05-02 bus) Figure 146: PCI and PCIe routing with activated APIC CPU boards BM45 (bus unit 5PC810.BX05-02) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 284: Upgrade Information

    2.1.1 What information do I need? Information: Individually saved BIOS settings are deleted when upgrading the BIOS. Before you begin the upgrade, it helps to determine the various software versions. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 285 A3C70168427 Enter Go to Sub Screen Product Name: 5PC810.SX02-00 General Help User Serial ID: 00000000h Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 147: Software version Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 286 Select Screen Select Item Change Option General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 148: Firmware version of the AP Link SDL transmitter Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 287: Bios Upgrade For Bm45 Com Express

    The system must be rebooted after a successful upgrade. • Reboot and press "Del" to enter the BIOS setup menu and load the setup defaults, then select "Save Changes and Exit". Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 288: Firmware Upgrade

    APC800 upgrade (MTCX, SDLR, SDLT, UPSI) disk. In some cases, these descriptions might not match the version you are currently using. Boot menu options: 1. Upgrade MTCX (APC810) PX32 and FPGA 2. Upgrade SDLT (APC810) only Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 289 The FPGA of the SDLT controller on the AP Link slot is automatically updated. Concerning item 3: Submenu 1 is opened for upgrading the SDLR controller on the Monitor/Panel plug. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 290 The firmware for the add-on UPSI is updated. 5.2 Upgrade Battery Settings (5AC600.UPSB-00) The battery settings for 5AC600.UPSB-00 are automatically updated. 5.3 Return to main menu Returns to the main menu. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 291: Possible Upgrade Problems And Software Dependencies (For V1.00)

    The function Legacy Mouse Support and Keyboard Controller Reset is only provided with the combination of MTCX PX32 V00.12 and MTCX FPGA V00.09 (included in APC810 MTCX upgrade disk V00.05). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 292: Creating An Ms-Dos Boot Diskette In Windows Xp

    "OK". Figure 150: Creating a bootable diskette in Windows XP - step 2 Figure 151: Creating a bootable diskette in Windows XP - step 3 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 293 Figure 152: Creating a bootable diskette in Windows XP - step 4 Figure 153: Creating a bootable diskette in Windows XP - step 5 Now all files (marked) except Command.com, IO.sys and MSDOS.sys can be deleted. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 294: Creating A Bootable Usb Flash Drive For B&R Upgrade Files

    In the B&R Upgrade text box, it's also possible to enter the path to the ZIP file for the B&R Upgrade Disk and select the file. • Click on the Start action button in the toolbar. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 295: Where Do I Get Ms-Dos

    Information concerning creating an MS-DOS boot diskette can be found in section 2.3 "Creating an MS-DOS boot diskette in Windows XP", on page 292. Then the files from the diskette are to be copied to your hard drive. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 296: Creating A Bootable Compactflash Card For B&R Upgrade Files

    In the B&R Upgrade text box, it's also possible to enter the path to the ZIP file for the B&R Upgrade Disk and select the file. • Click on the Start action button in the toolbar. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 297: Where Do I Get Ms-Dos

    MS-DOS boot diskette in Windows XP", on page 292. Then the files from the diskette are to be copied to your hard drive. 2.6 Upgrade problems Potential upgrade problems are listed in the Liesmich.txt or Readme.txt files on the upgrade disks. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 298: Automation Pc 810 With Ms-Dos

    USB 2.0 - only USB 1.1 rates can be reached. • A second graphics line (and therefore Extended Desktop mode) also cannot be used. • A few "ACPI control" BIOS functions cannot be used. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 299 ✓ ✓ ✓ 1280 x 1024 ✓ ✓ ✓ 1600 x 1200 ✓ ✓ 1920 x 1440 Table 180: Tested resolutions and color depths for DVI and RGB signals Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 300: Automation Pc 810 With Windows Xp Professional

    Upon request, B&R can pre-install the required Windows XP Professional version on the desired mass memory (add-on hard disk, slide-in hard disk). All of the drivers required for operation (graphics, network, etc.) are also installed when doing so. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 301: Installation On Pci Sata Raid Controller - 5Acpci.raic-03, 5Acpci.raic-05

    Press "Enter" and select the driver. 6) Follow the setup instructions. 7) The setup copies the files to the Windows XP Professional folder and restarts the Automation PC 810. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 302: Drivers

    - Material Related Downloads - BIOS / Drivers / Updates) on the B&R homepage (www.br- automation.com). Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 303: Automation Pc 810 With Windows 7

    Upon request, B&R can pre-install the required Windows 7 version on the desired mass memory (add-on hard disk, slide-in hard disk). All of the drivers required for operation (graphics, network, etc.) are also installed when doing so. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 304: Installation On Pci Sata Raid Controller - 5Acpci.raic-03, 5Acpci.raic-05

    6) Remove the USB flash drive. 7) The Windows 7 installation can now be performed as usual. Information: Depending on the system it could be neccesary to change the boot order in BIOS. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 305: Drivers

    Windows 7 system evaluation (system classification) is not currently supported. • Windows 7 does not contain a Beep.sys file, which means that audible signal is no longer played (i.e. when touching a key or button). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 306: Automation Pc 810 With Windows Embedded Standard 2009

    Windows XP Professional with SP3. It provides industry with leading reliability, improvements in security and performance, and the latest technology for Web browsing and extensive device support. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 307: Features With Wes2009 (Windows Embedded Standard 2009)

    Windows Installer Service ✓ Class Installer ✓ CoDevice Installer ✓ Media Player 6.4 ✓ DirectX 9.0c ✓ Accessories Number of fonts Table 184: Device functions in Windows Embedded Standard 2009 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 308: Installation

    B&R homepage (www.br-automation.com). A potentially activated "Enhanced Write Filter (EWF)" must be taken into consideration. Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 309: Automation Pc 810 With Windows Embedded Standard 7

    Standard 7. As with previous versions, this embedded operating system offers full system support of Automation PC 620, Automation PC 810, Panel PC 700, Panel PC 800 and Power Panel 500 devices. In addition to brand new features that are also included in Windows ® 7 Professional, Windows®...

  • Page 310: Features With Wes7 (Windows Embedded Standard 7)

    ✓ Bitlocker ✓ Applocker ✓ Tablet PC Support ✓ Windows Touch ✓ ✓ Boot from USB Stick ✓ ✓ Accessories Table 186: Device functions in Windows Embedded Standard 7 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 311: Installation

    (www.br-automation.com). A potentially activated "Enhanced Write Filter (EWF)" must be taken into consideration. Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 312: Automation Pc 810 With Automation Runtime

    8.2 Automation Runtime Windows (ARwin) The system is supported by ARwin with an AS 2.7 / AR 2.xx upgrade. The Automation Runtime Dongle must be connected to use ARwin on an Automation PC 810 (see section 10 "B&R Automation Runtime Dongle", on page 378).

  • Page 313: B&R Automation Device Interface (Adi) - Control Center

    These cannot be used to draw any conclusions about any hardware alarms or error conditions. The hardware components used have automatic diagnostics functions that can be applied in the event of error. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 314: Functions

    Mobile Panel 40/50 • Mobile Panel 100/200 • Automation Panel 800 (in connection with Automation PCs and Panel PCs) • Automation Panel 900 (in connection with Automation PCs and Panel PCs) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 315: Installation

    If a more current ADI driver version exists (see the B&R homepage download area), it can be installed later. A potentially activated "Enhanced Write Filter (EWF)" must be taken into consideration when installing. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 316: Sdl Equalizer Setting

    The value is optimally defined for the cable length when using the "Automatic setting". The equalizer value can only be changed if the function is supported by Automation Panel 900 (starting with Panel Firmware version 1.04 or higher). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 317: Ups Configuration

    The installed UPS must be selected and configured in the Control Panel using the energy options in order for battery operation to be supported. Information: The UPS service is supported starting with B&R Windows Embedded Version 2.10 or higher. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 318: Installing The Ups Service For The B&R Apc Add-On Ups

    In UPS firmware Version 1.07 or smaller, a change between battery operation and normal operation can lead to communication errors. 3) Select UPS monitor to display UPS status changes since the last time the system or UPS driver was started. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 319 "low" in the energy options, even if the battery is OK (Windows error). In an English version, three battery status levels are displayed: unknown, OK, replace A low battery status is never displayed. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 320: Changing Ups Battery Settings

    B&R under a new name and make adjust the settings in this file for the battery being used. Current files with settings for batteries from B&R can be updated using B&R's "Upgrade PPC800 MTCX" software. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 321: Updating Ups Battery Settings

    The progress indicator is not updated during this time. Information: The UPS is automatically restarted after a successful download. This can cause a brief failure in the UPS communication. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 322: Saving Ups Battery Settings

    3) Under UPS settings, click on Change. This opens the following dialog box: Figure 166: ADI Control Center - UPS settings Further information regarding the UPD system settings can be found in the Windows help. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 323 Low battery shutdown time. This will allow the operating system to shut down properly when UPS service is enabled. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 324: Changing Additional Ups Settings

    1) Open the Control Center in the Control Panel. 2) Select UPS tab. 3) Under UPS settings, click on Advanced. This opens the following dialog box: Figure 167: ADI Control Center - Advanced UPS settings Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 325 B&R UPS monitor. As long as the UPS monitor is active, no new messages are displayed. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 326: Procedure Following Power Failure

    If the supply voltage returns during the turn-off time, then the shutdown procedure will be stopped. If the supply voltage returns during the shutdown process, then the shutdown timer will run until the APC810 enters standby mode and will then reboot the system. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 327: Chapter 5: Standards And Certifications

    EN 60721-3-3 Classification of environmental conditions - part 3: Classification of groups of environmental parameters and their severities, section 3: Stationary use at weather-protected locations Table 187: Overview of standards Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 328 UL 508 Industrial control equipment (UL = Underwriters Laboratories) 47 CFR Federal Communications Commission (FCC), 47 CFR Part 15 Subpart B Class A Table 187: Overview of standards (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 329: Emission Requirements

    ≤ 75 connection, class A/D A per phase, and subject to conditional connection. Table 188: Overview of limits and testing guidelines for emissions Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 330: Network-Related Emissions

    73 dB (µV) 500 kHz - 30 MHz Quasi-peak value Quasi-peak value 60 dB (µV) 60 dB (µV) Average Average Table 189: Test requirements - Network-related emissions for industrial areas Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 331: Emissions, Electromagnetic Emissions

    Quasi-peak value > 960 MHz < 300 dB (µV/m) measured at a distance of 10 m Quasi-peak value Table 190: : Test requirements - Electromagnetic emissions for industrial areas Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 332: Requirements For Immunity To Disturbances

    A temporary function failure is permitted if the function restores itself, or the function can be restored by activating configuration and control elements. Criteria D: Deterioration or failure of the function, which can no longer be established (operating equipment destroyed). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 333: Electrostatic Discharge (Esd)

    Unshielded AC I/O >3 m ±1 kV, criteria B ±1 kV, criteria B Analog I/O Table 194: Test requirements - High-speed transient electrical disturbances (burst) 1) For EN 55024 without length limitation. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 334: Surges

    150 kHz - 80 MHz, 3 V, 80% amplitude modulation with 1 kHz, amplitude modulation with 1 kHz, length 3 seconds, criteria A length 3 seconds, criteria A Table 196: Test requirements - Conducted disturbances Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 335: Magnetic Fields With Electrical Frequencies

    2 m, criteria B ±2.5 kV, 1 MHz, repeat rate Power I/O, L to PE 400/seconds, length 2 seconds, connection lengths 2 m, criteria B Table 199: Test requirements - Damped vibration Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 336: Mechanical Conditions

    5 - 9 Hz Amplitude 2 - 9 Hz Amplitude 3.5 mm 3 mm 9 - 150 Hz Acceleration 9 - 200 Hz Acceleration Table 201: Test requirements - Vibration during operation Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 337: Vibration During Transport (Packaged)

    < 20 kg 20 - 100 kg 20 - 100 kg 20 - 100 kg > 100 kg > 100 kg > 100 kg Table 205: Test requirements - Toppling Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 338: Free Fall (Packaged)

    5 fall tests Weight Height < 10 kg 0.3 m 10 - 40 kg 0.3 m > 40 kg 0.25 m Table 206: Test requirements - Free fall Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 339: Climate Conditions

    EN 61131-2 Dry cold 16 hours at -40°C for 1 cycle, then 1 hour acclimatization and function testing, duration approximately 17 hours Table 210: Test requirements - Dry cold Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 340: Large Temperature Fluctuations

    Humid heat, constant (storage) 48 hours at +40°C and 92.5% RH, then insulation test within 3 hours, duration approximately 49 hours Table 214: Test requirements - Humid heat, constant (storage) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 341: Safety

    2.6 V 2.5 mm² 1.9 V 4.0 mm² 1.4 V > 6.0 mm² 1.0 V Table 216: Test requirements - Ground resistance 1) See EN 60204-1:1997 page 62, table 9. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 342: Insulation Resistance

    < 60 V after 5 sec (active parts) < 60 V after 1 sec (plug pins) < 60 V after 1 sec (plug pins) Table 219: Test requirements - Residual voltage Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 343: Leakage Current

    125 VDC 24 VAC 48 VAC 100 VAC 110 VAC - 15% 120 VAC +10% 200 VAC 230 VAC 240 VAC 400 VAC Table 223: Test requirements - Voltage range Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 344: Other Tests

    12.5 mm diameter Protection of personnel IP2. Protection against touching dangerous parts with fingers Protection against water IP.0 permeation with damaging Not protected consequences Table 225: Test requirements - Protection Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 345: International Certifications

    This mark is valid for the USA and Canada and simplifies certification of your machines and systems in these areas. Europe All harmonized EN standards for the applicable directives are met. Table 226: International certifications Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 346 Standards and certifications • International certifications Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 347: Chapter 6: Accessories

    CompactFlash card with 2048 MB SLC NAND flash and IDE/ATA interface 5CFCRD.4096-03 CompactFlash 4096 MB WD CompactFlash card with 4096 MB SLC NAND flash and IDE/ATA interface Table 227: Model numbers - Accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 348 SDL cable for fixed type of layout with one-sided 45° plug; length: 15 m 5CASDL.0150-03 SDL flex cable 15 m SDL cable for fixed and flexible type of layout; length: 15 m Table 227: Model numbers - Accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 349 Power supply, 1-phase, 10 A, redundant 24 VDC power supply, 1 phase, 10 A, redundant through parallel operation, input 115/230 VAC, manual select, DIN rail mounting Table 227: Model numbers - Accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 350 APC810 SATA hard disk replacement tray 5AC801.RDYR-01 APC810 Ready relay /2 Ready relay for APC810 for installation on an add-on UPS slot 5SWHMI.0000-00 HMI Drivers & Utilities DVD Table 227: Model numbers - Accessories Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 351: Tb103 3-Pin Supply Voltage Connector

    Name 0TB103.9 0TB103.91 Number of pins Type of terminal Screw clamps Cage clamps Distance between contacts 5.08 mm Table 229: Technical data - TB103 supply plug Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 352 14.5 A / 10 A per contact Terminal size 0.08 mm² - 3.31 mm² Cable type Copper wires only (no aluminum wires!) Table 229: Technical data - TB103 supply plug (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 353: Replacement Cmos Batteries

    < 1% per year Storage time Max. 3 years at 30° C Environmental characteristics Storage temperature -20 to +60°C Relative humidity 0 to 95% (non-condensing) Table 231: Technical data - Lithium batteries Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 354: Replacement Fan

    APC810 replacement fan filter 2CS 5 pcs. 5AC801.FA03-00 APC810 replacement fan filter 3CS 5 pcs. 5AC801.FA05-00 APC810 replacement fan filter 5CS 5 pcs. Table 232: Order data - Replacement fan filters Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 355: Dvi - Monitor Adapter 5Ac900.1000-00

    Adapter DVI-A/m to CRT DB15HD/f Adapter DVI (plug) to CRT (socket), for connecting a standard monitor to a DVI-I interface. Table 233: Order data - DVI - CRT adapter Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 356: Compactflash Cards 5Cfcrd.xxxx-04

    2048 MB B&R CompactFlash card 5CFCRD.4096-04 4096 MB B&R CompactFlash card 5CFCRD.8192-04 8192 MB B&R CompactFlash card 5CFCRD.016G-04 16 GB B&R CompactFlash card CompactFlash card Table 234: Order data - CompactFlash cards Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 357: Technical Data

    219.18 GB/day 438.36 GB/day 876.72 GB/day Clear/write cycles Guaranteed 100,000 Typical 2,000,000 SLC flash Wear leveling Static Error Correction Coding (ECC) Table 235: Technical data - CompactFlash cards 5CFCRD.xxxx-04 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 358 2) The file is written/read sequentially in True IDE mode with the DOS program Thruput.exe. 3) Endurance of B&R CF cards (linear written block size with 128 kB) 4) Depending on the average file size. 5) Not supported by B&R Embedded OS installer. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 359: Temperature Humidity Diagram

    1.01 ±0.07 1.01 ±0.07 3.30 ±0.1 CompactFlash type I 2.44 ±0.07 1.65 0.63 ±0.07 41.66 ±0.13 4 x R0.5 ±0.1 42.8 ±0.1 Figure 170: Dimensions - CompactFlash card Type I Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 360: Benchmark

    5CFCRD.0512-03 5CFCRD.4096-03 Figure 171: ATTO disk benchmark v2.34 comparison (reading) 1024 2048 4096 8192 Transfer size [kb] 5CFCRD.0512-04 5CFCRD.4096-04 5CFCRD.0512-03 5CFCRD.4096-03 Figure 172: ATTO disk benchmark v2.34 comparison (writing) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 361: Compactflash Cards - 5Cfcrd.xxxx-03

    5CFCRD.1024-03 CompactFlash 1024 MB WD 5CFCRD.2048-03 CompactFlash 2048 MB WD 5CFCRD.4096-03 CompactFlash 4096 MB WD 5CFCRD.8192-03 CompactFlash 8192 MB WD CompactFlash card Table 236: Order data - CompactFlash cards Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 362: Technical Data

    Provit 2000, Provit 5000, APC620, APC680, APC810, APC820 Windows 7 32-bit Windows 7 64-bit Windows Embedded Standard 7, 32-bit Windows Embedded Standard 7, 64-bit Table 237: Technical data - CompactFlash cards 5CFCRD.xxxx-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 363 Max. 3000 g (29430 m/s 0-peak) Altitude Maximum 80,000 feet (24,383 meters) Table 237: Technical data - CompactFlash cards 5CFCRD.xxxx-03 (Forts.) 1) Not supported by B&R Embedded OS installer. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 364: Temperature Humidity Diagram

    1.01 ±0.07 1.01 ±0.07 3.30 ±0.1 CompactFlash type I 2.44 ±0.07 1.65 0.63 ±0.07 41.66 ±0.13 4 x R0.5 ±0.1 42.8 ±0.1 Figure 174: Dimensions - CompactFlash card Type I Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 365: Usb Media Drive - 5Md900.Usb2-01

    +24 VDC supply (back side) • USB/B 2.0 connection (back side) • Optional front cover (see also section 8.9 "Front cover 5A5003.03 for the USB Media Drive", on page 371) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 366: Technical Data

    Starting time (0 rpm to read access) 14 seconds (maximum) 15 seconds (maximum) Host interface IDE (ATAPI) Table 239: Technical data - USB Media Drive 5MD900.USB2-01 Rev D0 and higher Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 367 Environmental characteristics Ambient temperature Operation +5 to +45°C Storage -20 to +60°C Transport -40 to +60°C Table 239: Technical data - USB Media Drive 5MD900.USB2-01 Rev D0 and higher (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 368: Dimensions

    ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm over 400 to 1000 mm ± 0.8 mm Figure 176: Dimensions - 5MD900.USB2-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 369: Dimensions With

    Outer contour (front cover) Outer contour (media device) 67.5 Cutout Cutout dimensions 183 ±0.5 mm x 55 ±0.5 mm 12.5 189.5 Figure 178: Installation cutout - USB Media Drive with front cover Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 370: Contents Of Delivery

    USB media drive is only permitted to be mounted and operated as shown in the following figure. less than 20° less than 20° less than 20° less than 20° Figure 180: Mounting orientation - 5MD900.USB2-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 371: Front Cover 5A5003.03 For The Usb Media Drive

    ± 0.3 mm over 30 to 120 mm over 120 to 400 mm ± 0.5 mm ± 0.8 mm over 400 to 1000 mm Figure 182: Dimensions - 5A5003.03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 372: Installation

    Installation depth Figure 183: Front cover mounting and installation depth 8.9.4 Cutout installation See the figure 178 "Installation cutout - USB Media Drive with front cover", on page 369. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 373: Usb Flash Drive

    USB flash drive 2 GB SanDisk Cruzer Micro 5MMUSB.2048-01 USB flash drive 2 GB B&R USB 2.0 flash drive 2 GB Table 242: Order data - USB flash drives Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 374: Technical Data - 5Mmusb.2048-00

    Max. 80 g (784 m/s 0-peak) and 11 ms duration Transport Max. 80 g (784 m/s 0-peak) and 11 ms duration Table 243: Technical data - USB flash drive 5MMUSB.2048-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 375: Temperature Humidity Diagram

    Figure 184: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-00 Temperature data is for operation at 500 meters. Derating the max. ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 376: Technical Data - 5Mmusb.2048-01

    At 20 - 2000 Hz: 20 g (peak) Shock Operation max. 1500 g (peak) Storage max. 1500 g (peak) Transport max. 1500 g (peak) Table 244: Technical data - USB flash drive 5MMUSB.2048-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 377: Temperature Humidity Diagram

    Figure 185: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-01 Temperature data is for operation at 500 meters. Derating the max. ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 378: B&R Automation Runtime Dongle

    B&R Automation Runtime ARwin, ARNC0 1A4600.10-3 B&R Automation Runtime ARwin+PVIControls incl. Li- cense Label and Security Key 1A4600.10-4 B&R Automation Runtime ARwin+ARNC0+PVIControls Table 245: Order data - B&R Automation Runtime Dongle Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 379: Uninterruptible Power Supply Ups

    Accessories • Uninterruptible power supply UPS 11. Uninterruptible power supply UPS With the optionally integrated UPS, the Automation PC 810 makes sure that the PC system completes write operations even after a power failure occurs. When the UPS detects a power failure, it switches to battery operation immediately without interruption.

  • Page 380: Order Data

    4) To configure: Automation Device Interface driver version 1.60 or higher (for the ADI Control Center) For info regarding configuration of the B&R UPS using the ADI Control Center, see chapter 9.4 "UPS configuration". Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 381: Individual Components

    Via the ADI Control Center (see section "Displaying UPS status values", on page 318) Configuration Via the ADI Control Center (see section "UPS configuration", on page 317) Table 247: Technical data - 5AC600.UPSI-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 382 7 "Maintenance / Servicing", section "Installing the UPS module", on page 440. Connection cable Mounting bracket Spacing bolt (14 mm) Spacing bolt (16 mm) Spacing ring (2 mm) Torx screws (T10) Figure 188: Add-on UPS module 5AC600.UPSI-00 - Installation materials Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 383: Battery Unit 5Ac600.Upsb-00

    10 years at 25°C (up to 80% battery capacity) Maintenance interval during storage 6 month interval between charges typ. recharge time at low battery 15 hours Table 248: Technical data - 5AC600.UPSB-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 384 6000 4000 2000 65 70 Temperature [°C] Figure 190: Temperature life span diagram Deep discharge cycles 1000000 100000 10000 1000 Amount of discharge [%] Figure 191: Deep discharge cycles Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 385 Accessories • Uninterruptible power supply UPS Dimensions ø5.4 ø11 87.5 All values in mm. Figure 192: Dimensions - 5AC600.UPSB-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 386 All values in mm. Figure 193: Drilling template for the battery unit Mounting instructions Due to the unique construction of these batteries, they can be stored and operated in any position. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 387: Ups Connection Cable

    12 V DC Testing AC voltage Wire / wire 1500 V Operating voltage Max. 300 V Current load 10 A at +20°C Table 249: Technical data - UPS connection cable Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 388: Power Supplies

    176-264 V 176-264 V 176-264 V 176-264 V 176-264 V DC input voltage 85-375 V 220-375 V 210-375 V 210-375 V 210-375 V 210-375 V Table 250: Single-phase power supplies Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 389: Three-Phase Power Supplies

    Output voltage 24-28 V 24-28 V 24 V 24 V Output current at 24 V 10 A 20 A 40 A Parallel operation Current balancing Table 251: Three-phase power supplies Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 390: Pci Cards

    13.1.1 Order data Model number Description Note 5ACPCI.ETH1-01 PCI Ethernet card 10/100 half size PCI Ethernet card, 1 Ethernet connection Table 252: Order data - PCI Ethernet Card 10/100 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 391: Technical Data

    Windows XP Professional, Windows XP Embedded, and DOS are available for download on the B&R Homepage in the download area (www.br-automation.com Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 392: Dimensions

    Accessories • PCI cards 13.1.4 Dimensions 42.6 106.3 121.7 All values in mm Figure 197: Dimensions - 5ACPCI.ETH1-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 393: Pci Ethernet Card 10/100 - 5Acpci.eth3-01

    13.2.1 Order data Model number Description Note 5ACPCI.ETH3-01 PCI Ethernet card 10/100 3port half size PCI Ethernet card, 3 Ethernet connections Table 254: Order data - PCI Ethernet Card 10/100 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 394: Technical Data

    Windows XP Professional, Windows XP Embedded, and DOS are available for download on the B&R Homepage in the download area (www.br-automation.com Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 395: Dimensions

    Accessories • PCI cards 13.2.4 Dimensions 42.6 106.3 121.7 All values in mm Figure 199: Dimensions - 5ACPCI.ETH3-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 396: Cables

    5CADVI.0050-00 DVI-D cable 5 m Single cable, DVI-D/m:DVI-D/m; length: 5 m 5CADVI.0100-00 DVI-D cable 10 m Single cable, DVI-D/m:DVI-D/m; length: 10 m Table 256: Order data - DVI cables Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 397: Technical Data

    Table 257: Technical data - DVI cable 5CADVI.0xxx-00 14.1.3 Flex radius specification Ferrite magnet Plug Flex radius Flex radius Plug - Ferrite magnet Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 201: Flex radius specification Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 398: Dimensions

    Figure 202: Dimensions - DVI cable 5CADVI.0xxx-00 14.1.5 Contents of delivery Amount Component DVI cable in desired length, plug covers are attached at the cable ends. Table 258: Contents of delivery - DVI cable 5CADVI.0xxx-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 399: Cable Specifications

    DVI cables provided by B&R are guaranteed to function properly. DVI-D (24+1), male DVI-D (24+1), male Pin assignments DVI-D (24+1), male DVI-D (24+1), male Shield Shield Figure 203: Pin assignments - DVI cable Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 400: Sdl Cable 5Casdl.0Xxx-00

    SDL cable for a fixed type of layout; length: 25 m 5CASDL.0300-00 SDL cable 30 m SDL cable for a fixed type of layout; length: 30 m Table 259: Order data - SDL cables Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 401: Technical Data

    Table 260: Technical data - SDL cables 5CASDL.0xxx-00 14.2.3 Flex radius specification Ferrite magnet Plug Flex radius Flex radius Plug - Ferrite magnet Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 205: Flex radius specification Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 402: Dimensions

    Figure 206: Dimensions - SDL cable 5CASDL.0xxx-00 14.2.5 Contents of delivery Amount Component SDL cable in desired length, plug covers are attached at the cable ends. Table 261: Contents of delivery - SDL cable 5CASDL.0xxx-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 403: Cable Specifications

    SDL cables provided by B&R are guaranteed to function properly. DVI (24+1), male DVI (24+1), male Pin assignments DVI (24+1), male DVI (24+1), male Shield Shield Figure 207: Pin assignments - SDL cable 5CASDL.0xxx-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 404: Sdl Cable With 45° Plug 5Casdl.0Xxx-01

    SDL cable 15 m 45° SDL cable for fixed type of layout with one-sided 45° plug; length: 15 m Table 262: Order data - SDL cables with 45° plug Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 405: Technical Data

    Table 263: Technical data - SDL cable with 45° plug 5CASDL.0xxx-01 14.3.3 Flex radius specification Ferrite magnet Plug Flex radius Flex radius Plug - Ferrite magnet Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 209: Flex radius specification Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 406: Dimensions

    Component SDL cable with 45° plug in desired length, plug covers are attached at the cable ends. Table 264: Contents of delivery - SDL cable with 45° plug 5CASDL.0xxx-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 407: Cable Specifications

    SDL cables provided by B&R are guaranteed to function properly. DVI (24+1), male DVI (24+1), male Pin assignments DVI (24+1), male DVI (24+1), male Shield Shield Figure 211: Pin assignments - SDL cable with 45° plug 5CASDL.0xxx-01 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 408: Sdl Flex Cable 5Casdl.0Xxx-03

    SDL cable for fixed and flexible type of layout; length: 25 m 5CASDL.0300-03 SDL flex cable 30 m SDL cable for fixed and flexible type of layout; length: 30 m Table 265: Order data - SDL cable 5CASDL.0xxx-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 409: Technical Data

    -20 to +80°C Moving -5 to +60°C Storage -20 to +80°C Fire resistance Fire resistant in accordance with UL758 (cable vertical flame test) Table 266: Technical data - SDL cable 5CASDL.0xxx-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 410: Flex Radius Specification

    Plug - Ferrite magnet Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 213: Flex radius specification 14.4.4 Dimensions 36.5 Length All values in mm Figure 214: Dimensions - SDL cable 5CASDL.0xxx-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 411: Contents Of Delivery

    - Hot Plug Detect DDC data 24 AWG XUSB0 + 5 V 24 AWG Schematic display mass 24 AWG Hot Plug detect 24 AWG Table 268: Structure - SDL cable 5CASDL.0xxx-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 412: Cable Specifications

    TMDS DATA 2/SDL Shield TMDS DATA 2/SDL Shield TMDS Data 2+ TMDS Data 2+ TMDS Data 2- TMDS Data 2- Cable shielding Cable shielding Figure 215: Pin assignments - SDL cable 5CASDL.0xxx-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 413: Sdl Flex Cable With Extender 5Casdl.0X00-13

    Metal cover with crimped stress relief Max. tension ≤ 400 N During installation ≤ 50 N During operation Table 270: Technical data - SDL flex cable with extender 5CASDL.0x00-13 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 414 Tested flex radius: 180 mm;15x cable diameter; hub: 460 mm; speed: 4800 cycles / hour Approbation UL AWM 20236 80°C 30 V Oil and hydrolysis resistance According to VDE 0282-10 Table 270: Technical data - SDL flex cable with extender 5CASDL.0x00-13 (Forts.) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 415: Flex Radius Specification

    Component SDL flex cable with extender in desired length, plug covers are attached at the cable ends. Table 271: Contents of delivery - SDL flex cable with extender 5CASDL.0xx0-13 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 416: Cable Specifications

    DVI (24+1), male DVI (24+1), male Extender Unit Black Box Pin assignments DVI (24+1), male DVI (24+1), male Shield Shield Figure 219: Pin assignments - SDL flex cable with extender 5CASDL.0x00-13 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 417: Rs232 Cable

    Min. 70 mm Table 273: Technical data - RS232 cables 14.6.3 Contents of delivery Amount Component RS232 cable in desired length Table 274: Contents of delivery - RS232 cables 9A0014.xx Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 418: Cable Specifications

    RS232 cables provided by B&R are guaranteed to function properly. DSUB (9-pin), male DSUB (9-pin), female Pin assignments DSUB (9-pin), male DSUB (9-pin), female Shield Shield Figure 221: Pin assignments - RS232 cable Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 419: Usb Cable

    Min. 100 mm Table 276: Technical data - USB cables 14.7.3 Contents of delivery Amount Component USB cable in desired length Table 277: Contents of delivery - USB cable Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 420: Cable Specifications

    USB cables provided by B&R are guaranteed to function properly. Pin assignments USB Type A, male USB Type B, male Shield Shield Figure 223: Pin assignments - USB cable Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 421: Apc810 Internal Supply Cable 5Camsc.0001-00

    1x 4-pin male disk drive power plug, 1x 4-pin female plug housing Wire cross section AWG 22 Flexibility Flexible Table 279: Technical data - APC810 internal supply cable 5CAMSC.0001-00 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 422: Hdd Replacement Tray 5Ac801.Fram-00

    The replacement hard disk is not included in delivery and must be ordered separately. (Order data can be found in Chapter 1 "General information" on page 27. Table 280: Order data - HDD replacement disk tray Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 423: Dimensions

    30 to 120 mm ± 0.3 mm ± 0.5 mm over 120 to 400 mm over 400 to 1000 mm ± 0.8 mm Figure 226: Dimensions - HDD replacement disk tray Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 424: Ready Relay 5Ac801.Rdyr-01

    Table 281: Order data - Ready relay 16.2 Pin assignments Assignment Description Image Not connected Not connected Normally open Change-over contact Normally closed Not connected Table 282: Pin assignments - Ready relay Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 425: Contents Of Delivery

    Internal supply voltage cable Spacing ring Label strip Mounting bracket 3x Torx screws (T6) 14 mm 16 mm spacing bolt spacing bolt Figure 228: Contents of delivery - Ready relay Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 426: Hmi Drivers & Utilities Dvd 5Swhmi.0000-00

    Automation PC 620 / Panel PC 700 CPU Board 945GME N270 BIOS • Automation PC 680 • Automation PC 810 / Automation PC 820 / Panel PC 800 B945GME BIOS • Automation PC 810 / Panel PC 800 945GME N270 CPU Board BIOS •...
  • Page 427 Panel PC 300 (MTCX) • Power Panel 100 (aPCI) • Power Panel 300/400 (aPCI) • Power Panel 300/400 (MTCX) • Panel PC 800 (MTCX, SDLR, SDLT) • UPS firmware Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 428 Thin Client • Windows NT Embedded • Windows XP Embedded • VNC Viewer MCAD templates for • Industrial PCs • Operator Interface devices • Legend Strips templates • Customized designs Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 429 Provit Mkey • Windows CE 5.0 help • Windows CE 6.0 help • Windows NT Embedded application guide • Windows XP Embedded application guide • UPS - uninterruptible power supply Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 430 Acrobat Reader 5.0.5 (freeware in German, English and French) • Power Archiver 6.0 (freeware in German, English and French) • Internet Explorer 5.0 (German and English) • Internet Explorer 6.0 (German and English) Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 431: Chapter 7: Maintenance / Servicing

    • The battery should only be changed by qualified personnel. The following replacement lithium batteries are available: 4A0006.00-000 (1 pc.) and 0AC201.91 (4 pcs.). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 432: Procedure

    • The battery should not be held by its edges. Insulated tweezers may also be used for inserting the battery. Like this Not like this Figure 231: Battery handling Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 433 To make the next battery change easier, be sure the removal strip is in place when inserting battery. • Reconnect power supply to the Automation PC 810 (plug in power cable and press power button). • Date and time might need to be reset in BIOS.

  • Page 434: Installing / Exchanging A Slide-In Compact Drive

    Remove 2 ¼ turn screws Figure 233: Loosening the ¼ turn screws • Insert the compact SATA drive and tighten the ¼ turn screws. Figure 234: Inserting the compact SATA drive Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 435: Installing / Exchanging A Slide-In Slot Drive

    ¼ turn screws Figure 235: Loosening the ¼ turn screws • Insert the slide-in drive and tighten with the two ¼ turn screws. Figure 236: Installing the slide-in drive Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 436: Installing The Slide-In Compact Adapter

    ¼ turn screws Remove 2 ¼ turn screws Figure 237: Loosening the ¼ turn screws • Insert the slide-in compact adapter and tighten with the two ¼ turn screws. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 437 Maintenance / Servicing • Installing the slide-in compact adapter Figure 238: Installing the slide-in compact adapter • Once the adapter has been installed, the slide-in compact drive can be inserted. Figure 239: Inserting the slide-in compact drive Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 438: Installing / Exchanging The Fan Kit

    Insert the frame - Mount the contact board side to the sliding contacts on the system unit and fasten using the ¼ turn screws. Contact board Sliding contact Contact board Figure 241: Inserting and fastening the fan kit Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 439 Place the fan kit cover in the housing and fasten using the Torx screws removed earlier. Information: Regular control of the dust filter depending on area of use and degree of dirtiness. Installation is the same as for all APC810 devices. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 440: Installing The Ups Module

    Remove side cover (see section "Mounting the side cover", on page 453). • Remove UPS module cover by removing the 2 marked Torx screws (T10). Figure 244: Remove UPS module cover Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 441 (spacing bolt). Use the previously removed Torx screws from the mounting materials. Figure 246: Install UPS module • Plug in connection cable (see marked socket). Figure 247: Plug in connection cable Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 442: Apc810 2 And 3 Card Slot

    Remove UPS module cover by removing the 2 marked Torx screws (T10). Figure 249: Remove UPS module cover • Screw in spacing bolt and spacing ring on the main board (using M5 hex socket screwdriver). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 443 Install UPS module with 2 Torx screws (T10) on the housing and 1 Torx screw (T10) on the main board (spacing bolt). Use the previously removed Torx screws from the mounting materials. Figure 252: Install UPS module • Plug in connection cable (see marked socket). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 444 Figure 253: Plug in connection cable Information: When connecting the cable, make sure that the connector locking mechanism is engaged. Figure 254: Connector locking mechanism • Attach the side cover. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 445: Apc810 5 Card Slot

    Figure 256: Screw in spacing bolt and spacing ring • Install mounting bracket on UPS module using 2 Torx screws (T10). Mounting bracket + 2 Torx screws Figure 257: Install mounting bracket Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 446 Figure 259: Plug in connection cable Information: When connecting the cable, make sure that the connector locking mechanism is engaged. Figure 260: Connector locking mechanism • Attach the side cover Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 447: Installation With Installed Add-On Interface Module

    Figure 262: Screw in spacing bolt • Install the UPS module using 3 Torx screws (T10). Use the previously removed Torx screws and one Torx screw from the mounting materials. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 448 Figure 264: Plug in connection cable Information: When connecting the cable, make sure that the connector locking mechanism is engaged. Figure 265: Connector locking mechanism • Attach cover plate and side cover. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 449: Apc810 2 And 5 Card Slot

    Figure 268: Install mounting bracket • Install the UPS module using 3 Torx screws (T10). Use the previously removed Torx screws and one Torx screw from the mounting materials. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 450 Figure 270: Plug in connection cable Information: When connecting the cable, make sure that the connector locking mechanism is engaged. Figure 271: Connector locking mechanism • Attach cover plate and side cover. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 451: Apc810 5 Card Slot

    Figure 274: Install mounting bracket • Install the UPS module using 3 Torx screws (T10). Use the previously removed Torx screws and one Torx screw from the mounting materials. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 452 Figure 276: Plug in connection cable Information: When connecting the cable, make sure that the connector locking mechanism is engaged. Figure 277: Connector locking mechanism • Attach cover plate and side cover. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 453: Mounting The Side Cover

    Touch the housing or ground connection (not the power supply!) in order to discharge any electrostatic charge from your body. • Open the orange front cover. Behind the cover there are 4 Kombitorx screws (T10) that must be removed. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 454: Apc810 With 5 Card Slot

    Figure 280: Mounting the side cover - APC810 5 card slot • After the screws have been removed, the side cover can be removed by sliding it toward the front. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 455: Ap Link Installation

    Install the AP Link module using 3 Torx screws (T10). Use the previously removed Torx screws and an additional Torx screw from the mounting materials. Figure 282: Install AP Link module • Attach cover plate and side cover. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 456: Exchanging A Pci Sata Raid Hard Disk In A Raid 1 System

    Loosen the 4 appropriate mounting screws (M3x5). Primary Hard Disk (HDD0) Secondary Hard Disk (HDD1) Figure 283: Screw layout on the back side of the SATA RAID controller 5ACPCI.RAIC-03 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 457 Critical status - press any key to enter Configuration Utility". • A rebuild must be executed in the SATA RAID BIOS - for more information on this, see the section "Rebuild mirrored set", on page 212. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 458: Installing The Hdd Replacement Disk Tray

    • Attach the HDD replacement disk tray to the ventilation slots on the APC810 housing using the hooks provided. Figure 286: Installing the replacement disk tray in the APC810 Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 459: Installing The Ready Relay /2 In The Add-On Ups Slot

    Figure 288: Screw in spacing bolt and spacing ring • Ready relay with 2 Torx screws (T6) and the mounting bracket on the housing and 1 Torx screw (T6) on the main board (spacing bolt). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 460 Plug in connection cable Information: When connecting the internal supply voltage cable, make sure that the connector locking mechanism is engaged. Figure 290: Plug in connection cable • Attach the side cover Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 461: Temperature Sensor Locations

    1) The measured temperature is a guideline for the immediate ambient temperature, but can be influenced by neighboring components. 2) The B&R Control Center - ADI driver - can be downloaded for free from the download area on the B&R homepage (www.br- automation.com). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 462: Maintenance Controller Extended (Mtcx)

    XP/embedded, using B&R Control Center. For more information, see section 2.2 "Firmware upgrade", on page 288. 1) Can be downloaded from the download area on the B&R homepage (www.br-automation.com). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 463: Temperature Monitoring - Fan Control

    For example, slide-in 1/2: 44°C + 16°C = 60°C --> maximum fan speed The fans are first switched off again if the evaluated temperature remains 6°C lower than the start-up temperature for a time span of 4 hours (=lag-time). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 464: Connection Of An External Device To The Main Board

    4-pin connector, male +12 VDC Max. 10 watts Max. 5 watts +5 VDC Table 287: Pin assignments - Connector on main board Connections are protected with a 1A multi-fuse. Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 465: B&R Key Editor Information

    4 assignments per key possible (using layer function) • Configuration of panel locking time when multiple Automation Panel 900 devices are connected to Automation PCs and Panel PCs devices. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 466 The B&R Key Editor can be downloaded for free from the download area on the B&R homepage (www.br-automation.com ). Additionally, it can also be found on the B&R HMI Drivers & Utilities DVD (model number 5SWHMI.0000-00). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 467: B&R Automation Device Interface (Adi) Development Kit

    Help files for Visual Basic and Visual C++. • Sample projects for Visual Basic and Visual C++. • ADI DLL (for testing the applications, if no ADI driver is installed). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 468 A detailed description of using the ADI functions can be found in the integrated online help. The B&R Automation Device Interface (ADI) development kit can be downloaded for free from the download area on the B&R homepage (www.br-automation.com). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 469: B&R Automation Device Interface (Adi) .Net Sdk

    • Sample projects and code snippets for Visual Basic, Visual C++, Visual C# and Visual J#. • ADI DLL (for testing the applications, if no ADI driver is installed). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 470 A detailed description of using the ADI functions can be found in the integrated online help. The ADI .NET SDK can be downloaded for free from the download area on the B&R homepage (www.br-automation.com). Automation PC 810 with GM45 CPU board User's Manual V 1.14...

  • Page 471: Glossary

    Although BIOS is used to configure a system's performance, the user does not usually come into contact with it. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 472 High reliability using error detection, error handling, troubleshooting. Hamming distance. CD-ROM Abbreviation for "Compact Disc Read-Only Memory". A removable data medium with a capacity of ~700 MB. CD-ROMs are optically scanned. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 473 CF cards were launched by SanDisk back in 1994. Currently, memory capacities reach up to 64 GB per unit. Since 1995, CompactFlash Association [CFA] has been looking after standardization and the worldwide distribution of CF technology Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 474 "Double In-line Memory Module" consisting of one or more RAM chips on a small circuit board that is connected with the motherboard of a computer. Direct Memory Access > Accelerated direct access to a computer’s RAM by bypassing the CPU. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 475 DVD drives. Abbreviation for "Digital Visual Interface" An interface for the digital transfer of video data. DVI-A Analog only DVI-D Digital only DVI-I Integrated, i.e. analog and digital Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 476 PC functionality on a very compact form factor of just 114 mm x 100 mm (´4.5" x 4"). The flexibility offered by ETX® in the development of system specific main boards allows easy requirement fulfillment in a number of different applications. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 477 Ethernet networks. FTP is one of the most used protocols on the Internet. It is defined in RFC 959 in the official regulations for Internet communication. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 478 130 countries. ISO is not an acronym for the name of the organization; it is derived from the Greek word "isos", meaning "equal" (www.iso.ch). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 479 LPT1, LPT2 and LPT3. The first parallel port (LPT1) is usually identical to the primary parallel output device PRN (in MS-DOS the logical device name for the printer). The abbreviation LPT stands for "Line Printer Terminal". Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 480 An abbreviation for "Mean time between failure". The average time which passes before a hardware component fails and repair is needed. This time is usually expressed in thousands or ten thousands of hours, sometimes known as power-on hours (POH). Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 481 200 companies from around the world, including Microsoft and other leading companies. Nowadays, OPC is also interpreted as a synonym for Openness, Productivity and Connectivity, symbolizing the new possibilities that this standard opens up. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 482 [IL, FBD, LAD, AS, ST]. Because of its serial functionality, reaction times are slower compared to connection-oriented control. Today, PLCs are available in device families with matched modular components for all levels of an automation hierarchy. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 483 I/O modules as well as intelligent signal and data processing units to be installed in the machine room, which among other things can significantly reduce cabling costs. Often used for time-critical factory automation applications. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 484 See also "real-time demands" and "real- time system". Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 485 DRAM switching circuits. This is made possible using block access. For each access, the DRAM determines the next memory addresses to be accessed. Sequential function chart > Graphic input language for PLCs used to represent sequential control. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 486 Abbreviation for Super Extended Graphics Array. Graphics standard with a screen resolution of 1280 × 1024 pixels (aspect ratio 5:4). SXGA+ Abbreviation for SXGA Plus; Generally 1400 × 1050 pixels. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 487 UART represents the most common type of circuit in modems for connecting to a personal computer. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 488 OEM market. It can be ported for various processor types and has a high degree of real-time capability. The development environment uses proven, well-established development tools. It is an open and scalable Windows operating system platform for many Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 489 ETX® Standard (Rev. 2.7). However, if ISA signals are needed, a PCI-ISA can be implemented on the base board. The use of an LPC bus already in XTX™ is considerably cheaper than a bridge solution. Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 490 Appendix A • Glossary Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 491 5 slot bus units ..................... 107 Figure 44: GM45 CPU board..................108 Figure 45: Heat sink ...................... 109 Figure 46: Main memory....................110 Figure 47: Slide-in compact HDD 40GB EE25 - 5AC801.HDDI-00....... 111 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 492 Figure 87: Optional mounting - horizontal ..............170 Figure 88: Standard mounting - Mounting distances............. 171 Figure 89: Flex radius - Cable connection..............172 Figure 90: Grounding concept ..................173 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 493 BM45 - Advanced USB configuration............248 Figure 132: BM45 - Advanced keyboard/mouse configuration........250 Figure 133: BM45 - Advanced CPU board monitor ............251 Figure 134: BM45 - Advanced main board/panel features ..........252 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 494 Dimensions - USB Media Drive with front cover .......... 369 Figure 178: Installation cutout - USB Media Drive with front cover ......... 369 Figure 179: Interfaces - 5MD900.USB2-01 ..............370 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 495 Pin assignments - USB cable............... 420 Figure 224: APC810 internal supply cable - 5CAMSC.0001-00........421 Figure 225: HDD replacement disk tray - 5AC801.FRAM-00.......... 422 Figure 226: Dimensions - HDD replacement disk tray ............ 423 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 496 Plug in connection cable ................450 Figure 271: Connector locking mechanism ..............450 Figure 272: Remove UPS module cover ................. 451 Figure 273: Screw in spacing bolt ................... 451 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 497 B&R Key Editor screenshots Version 3.10 (representation picture)..... 465 Figure 295: ADI development kit screenshots (Version 3.10) ......... 467 Figure 296: ADI .NET SDK Screenshots (Version 1.50) ..........469 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 498 Figure index Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 499 Technical data - System units ................104 Table 45: Technical data - Bus units ................. 107 Table 46: Technical data - GM45 CPU boards ..............108 Table 47: Technical data - Heat sink................. 109 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 500 Link module for the configuration - One Automation Panel 900 via SDL ..178 Table 93: Cables for SDL configurations ................179 Table 94: Segment lengths, resolutions and SDL cables ..........180 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 501 BM45 - Advanced CPU configuration - Setting options ........235 Table 135: BM45 - Advanced chipset - Setting options ............237 Table 136: BM45 - Advanced I/O interface configuration - Setting options ......238 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 502 Tested resolutions and color depths for DVI and RGB signals ......299 Table 181: Model numbers - Windows XP Professional ............. 300 Table 182: Model numbers - Windows 7................303 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 503 International certifications ................. 345 Table 227: Model numbers - Accessories ................347 Table 228: Order data - Supply plug ................... 351 Table 229: Technical data - TB103 supply plug ..............351 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 504 Table 274: Contents of delivery - RS232 cables 9A0014.xx ..........417 Table 275: Order data - USB cables ................... 419 Table 276: Technical data - USB cables ................419 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 505 Overview of required replacement SATA HDD for PCI SATA HDD RAID controller Table 285: Temperature sensor locations................461 Table 286: Temperature limits of the fan (MTCX PX32 V0.06)........... 463 Table 287: Pin assignments - Connector on main board ............ 464 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 506 Table index Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 507 5AC801.FA02-00 ....... 29 5CFCRD.0064-03....30 5AC801.FA03-00 ....... 29 5CFCRD.0128-03....30 5AC801.FA05-00 ....... 29 5CFCRD.016G-04 ....30 5AC801.FRAM-00 ..... 31 5CFCRD.0256-03....30 5AC801.HDDI-00....... 27 5CFCRD.0512-03....30 5AC801.HDDI-02....... 27 5CFCRD.0512-04....29 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 508 5PC810.BX05-01....... 26 5PC810.BX05-02....... 27 5PC810.FA01-00 ....... 28 5PC810.FA02-01 ....... 28 9A0014.02 ........349 5PC810.FA03-00 ....... 28 9A0014.05 ........349 5PC810.FA05-00 ....... 28 9A0014.10 ........349 5PC810.SX01-00......26 9S0000.01-010 ........31 5PC810.SX02-00..26 9S0000.01-020 ........31 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 509 APC810 5 card slot ........56 Cable type ....... 159, 162, 163, 164 Dimensions ..........60 Cables ............. 395 Interfaces ..........56 APC810 internal supply cable ....421 Technical data ........58 Cache ............472 API ............471 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 510 DS1425 ............98 upgrade files ..........296 DSR ............475 CRT ...........29, 474 DTR ............475 CTS ............474 Dual channel memory ......38, 110 DVD ............475 DVI ............. 85, 475 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 511 IDE ............478 Firmware ..........477 IF option ........... 156 Flex radius ........172, 387 Immunity ..........332 Floppy ............477 Individual components ......104 FPC ............477 AP Link card ......... 152 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 512 Low speed ...........88, 89 LPT ............479 Panel ............482 Panelware ..........482 Parity error ..........277 PC Card ........... 482 Magnetic fields with electrical frequencies ..PCI ............. 93, 482 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 513 SATA ....38, 101, 102, 103, 134, 141 RAID controller ........38, 301 Screw clamps ..........82 RAM ............484 SDL ............85 Ready relay ........155, 424 SDL cable with 45° plug ......404 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 514 USB flash drive for B&R update files ..294 SVGA ............486 USB Media Drive ........365 Switch ............486 Dimensions .......... 368 Switching power supply ......388 Dimensions with front cover ....369 SXGA ............486 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 515 Vibration during transport ......337 WXGA ............489 Vibration operation ........336 Video signals ..........85 Viruses ............24 Voltage dips ..........335 XGA ............489 Voltage fluctuations .........335 XTX ............489 Voltage range ..........343 Automation PC 810 with GM45 CPU board User's Manual V 1.14...
  • Page 516 Index Automation PC 810 with GM45 CPU board User's Manual V 1.14...

This manual is also suitable for:

5pc810.sx01-005pc810.sx02-005pc810.sx03-005pc810.sx05-005pc810.bx01-005pc810.bx01-01 ... Show all

Table of Contents
