Proton IMS-2290 Quick Manual

Беспроводной 2D сканер
Proton IMS-2290
1.Open packaging, inspect appearance and accessories
2.Press the button to make the equipment to start up
3.Connection and transmission scheme
Please note: the default connection mode of the scanner is
2.4G, which can be configured into bluetooth mode as required.
After starting up, the connection will be tried according to the
connection mode before shutting down. For example, the
scanner is connected with the mobile phone via bluetooth
before shutting down. After starting up again, the mobile phone
does not ignore the device and when the bluetooth is turned on,
the scanner will automatically connect with it.
The steps of scanner's function setting are:
Enter setting Read function barcode
3.1 Bluetooth mode
Turn on the bluetooth of terminal equipment, and the
scanner scans "Enter setting" - "Bluetooth HID mode" - "Enter
search" - "Exit setting" in turn. There is a new device
"Barcode Scanner HID" in the bluetooth list of the first
connection to terminal equipment. (Note: see 7 for the
meaning of indicator light)
①Enter setting
②Bluetooth HID mode
Краткое руководство пользователя
③Enter search
3.2 2.4G mode
Plug the Dongle into the computer, and after successfully
recognizing Dongle, scan the barcode of "Enter setting" --
"2.4G mode" -- "Connect Dongle" -- "Exit setting" in turn.
Barcode successfully connects with Dongle, then the blue
indicator light is always on.
①Enter setting
Exit setting
③Connect Dongle
4. Restore factory setting
Scan "Restore factory Setting" barcode will restore all
settings of the scanner to the factory state. This barcode does
not change the connection and transmission mode.
Restore factory setting
(новая версия)
5.Function configuration
5.1 Carriage return and line feed are configured
Scan "Enter setting" to start function setting, scan the
corresponding function bar code as required by the function,
and then scan "Exit setting" to finish the setting.
④Exit setting
Add line feed
②2.4Gmode
Remove carriage return/line feed
④Exit setting 6.Dormancy instruction
The scanner, which is in normal connection but does not
scan, will automatically shut down after about 10 minutes.
When you do not use the scanning device, you can scan the
following barcode to directly shut down the scanning device.
Enter setting
Add carriage return
Add carriage return/line feed
Exit setting
