ViewSonic P75F+ Specifications page 2

ViewSonic
P75f+/P75f+B
• ARAG ® screen treatment
This anti-reflection, anti-glare screen treatment
maintains the highest image quality.
• TCO and E S
NERGY TAR
• ViewSonic Wizard
This software provides user-friendly installation.
•
®
• PC and Mac compatible
• Three-year limited warranty
• Turn your LCD into a high-resolution TV
Hook up favorite extras like a DVD, gaming
console, VCR or digital camera
with ViewSonic's video
processing box.
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583 or (909) 444-8888 • Fax (909) 839-7922 • E-mail: SalesInfo@ViewSonic.com • ViewSonic.com
*
Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details.
Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2002 ViewSonic Corporation. All rights reserved. [10578-00B-04/02_0M] P75f+/P75f+B-1
P75f+ beige case version
®
certified
to ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
®
CRT Display
17.0" (16.0" VIEWABLE) PERFECTFLAT
CRT Type
Pitch
Phosphor
Glass Surface
INPUT SIGNAL Video
Sync
Frequency
COMPATIBILITY PC
Mac ® *
CONNECTOR Signal
Power
POWER Voltage
Consumption
CONTROLS Basic
®
OnView
VIDEO INPUT Bandwidth
MISCONVERGENCE
DISPLAY AREA Factory Setting 300mm x 225mm
(H x V) Maximum Scan 326mm x 250mm
OPERATING Temperature
CONDITIONS Humidity
DIMENSIONS Physical
(W x H x D)
WEIGHT Net
Gross
REGULATIONS
POWER MANAGEMENT
WARRANTY
ViewSonic Corporation's QMS & EMS have been registered
® CRT COLOR MONITOR
17" (16.0" viewable), 90º deflection, PerfectFlat
0.25mm aperture grille
RGB B22 medium/short persistence
Tint: TM~39.8%, anti-reflection, anti-static coating
RGB analog (75 ohms, 0.7 Vp-p)
H/V separated (TTL), composite
f h : 30~97kHz; f v : 50~160Hz
IBM compatible from VGA up to 1792x1344
™
Power Mac G3/G4 from 640x480 to 1600x1200
15-pin mini D-sub (high density)
3-pin plug (IEC320)
AC 90–240VAC, 50–60Hz (+/-2)Hz
95W (typ), 130W (max)
™
Power, 1, down, up, 2, UltraBrite toggle
Contrast, brightness, H. size, H. position, V. size,
V. position, pincushion, pin balance, trapezoid,
parallelogram, rotation, degauss, moiré reduction,
H. convergence, V. convergence, ViewMeter
®
ViewMatch color, data recall and zoom
205MHz
0.25mm (max) at center
0.35mm (max) at corners
32–104º F (0–40º C)
5–95% (non-condensing)
16.1" x 15.8" x 16.6"
39.6 lbs. (18.0 kgs.)
45.1 lbs. (20.5 kgs.)
UL/cUL, EPA E S ® , FCC-B, ICES003, DHHS,
NERGY TAR
NOM, TUV-S, CE, CB, TUV/GS, TUV/Ergo, MPR ll, TCO'95
(P75f+B), TCO'99, PSB, BSMI, C-TICK, GOST, Nordic,
PCBC, VCCI, CCEE
Meets TCO'95/'99 and E S standards
NERGY TAR
Three-year limited warranty on CRT, parts and labor.
®
, language,
