Summary of Contents for Logan All in One Series

  • Page 1 SURVEILLANCE KIT USER MANUAL English / Español “All in One” Seri e s...
  • Page 3: Table Of Contents

    Directory 1 Production Introduction ..........................5 1.1 Product overview ........................... 5 1.2 Main functions..........................5 2 Open-package check and cable connections ..................6 2.1 Open-package check ........................6 2.2 Hard disk installation ........................7 2.3 Shelf installation ..........................7 2.4 Front panel ............................. 8 2.5 Rear panel .............................
  • Page 4 4.4.4 NetService ......................... 37 4.4.5 Display ..........................46 4.4.6 PTZ config ......................... 47 4.4.7 RS232 ..........................48 4.4.8 Tour ............................... 48 4.5 Advanced ............................. 50 4.5.1 HDD Manage ........................50 4.5.2 Account ..........................50 4.5.3 Online user ........................53 4.5.4 TV adjust ........................... 53 4.5.5 Auto Maintain ........................
  • Page 5: Production Introduction

    1 Production Introduction 1.1 Product overview The series DVR is designed especially for security and defense field which is an outstanding digital surveillance product. It introduces embedded LINUX operating system which is more stable. It introduces standard H.264mp video compressed format and G.711A audio compressed format which insures the high quality image, low error coding ratio and single frame playing.
  • Page 6: Open-Package Check And Cable Connections

    Playback ·individual real-time video recording as well as searching, playback, network surveillance, recording check, downloading and so on ·multi-playback mode ·zoom at arbitrary region Net operating ·through net tele-surveillance in the real time ·tele-PTZ control ·tele-recording check and real-time playback Alarm linkage ·Alarm activated video record, tour, message,buzzer,e-mail,ftp Communication interface...
  • Page 7: Hard Disk Installation

    At last, please open the machine crust and check the data wire in the front panel, power wire, the connection between the fan power and the main board. 1. Front panel and rear panel  The key function specification in the front panel and the interface specification in the real panel are in the specification.
  • Page 8: Front Panel

    1、Make sure the temperature in the room lower than 35ª (95°f). 2、Keep the equipment have 15cm (6 inches) space around in order to air's circulation. 3、From bottom to shelf installation. 4、When multiple components install in the frame,please take preventive measures to avoid power socket overload.
  • Page 9: Audio And Video Input And Output Connections

    2.6 Audio and video input and output connections 2.6.1 Video input connections The video input port is BNC connector plug. The demand of input signal is PAL/NTSC BNC (1.0V 75Ω). The video signal must be accorded with the state standard which has the high signal to noise ratio, low aberration and low interference.
  • Page 10: Audio Signal Input

    2、Keep the computer display normal working by demagnetizing regularly. 3、Stay away from the electromagnetic Interference. 2.6.3 Audio signal input Audio port is BNC connection. The input impedance is high so the tone arm must be active. The audio signal line should be firm and away from the electromagnetic Interference and connected credible which avoid false and joint welding and oxidation.
  • Page 11: Basic Operation

    3 Basic operation Note: The button in gray display indicates nonsupport. 3.1 Turn on Plug the power supply .After the startup you will hear a beep. The default setting of video output is multiple-window output mode. If the startup time is within the video setting time, the timing video recording function will start up automatically.
  • Page 12: System Login

    3.3 System Login When the DVR boots up, the user must login and the system provides the corresponding functions with the user purview.There are three user settings. The names are admin, guest and default and these names have no password. Admin is the super user purview; guest and default’s permissions are preview and video playback.
  • Page 13: Main Menu

    Speed PTZ, Alarm Output, color Setting, Output adjust, Logout, view mode. Picture 3.2 Shortcut Menu 3.5.1 Main menu When you login, the system main menu is shown as below. Picture3.3 Main Menu 3.5.2 Playback There are two methods for you to play the video files in the hard disk. 1、...
  • Page 14 2、 Main menu>Record->Playback...
  • Page 15 Picture 3.4 video playback Playback control Operation hint Record mode Time interval choosing Switch by time, File searching Channel Date choosing file mode choosing Storage device File information Listed files Time choosing searching 【Listed files】Look up the listed files that accord with the searching criteria. 【File information】Look up the found file information.
  • Page 16: Record Control

    Previous frame Next frame Previous file Next file Round play Full screen Stop Picture 3.5 Playback control key Note: play under frame by frame, the playback status should be paused firstly. 【Operation tips】show function of the key that cursor placed. Special functions:...
  • Page 17: Alarm Output

    【Manual】Click the all button and the according channel is recording no matter the channel in any state. 【Stop】Click the stop button and the according channel stops recording no matter the channel in any state. 3.5.4 Alarm output Please check current channel status: “○” means it is not in alarming status, “●” means it is in alarming status.
  • Page 18 Picture 3.10 PTZ setup 【Speed】Set the PTZ rotation range. Default range: 1 ~ 8. 【Zoom】Click button to adjust the zoom multiple of the camera. 【Focus】Click button to adjust the focus of the camera . 【Iris】Click button to adjust the iris of the camera. 【Hide】Current interface will be temporarily hidden after click it.
  • Page 19 Step 3: click Settings button, return the Picture 3.10 Complete setup, that is the preset points and preset position corresponds. Clear Preset:Input preset points, click Remove button, remove the preset. Picture 3.11 Preset Settings 2) Preset Point Calls In Picture 3.10, click Page Shift button, enter PTZ control interface. In the input blank, write the preset points, then click Preset button, PTZ turn to the corresponding preset point.
  • Page 20 Remove Cruise Line:Input the number of cruise line, click Remove Cruise Lines button, then remove the cruise lines set。 Picture 3.13 Cruise between Points Settings 2)The Calls of Cruise between Points In Picture 3.10, click Page Shift button, enter PTZ control menu as shown in Picture 3.12. Please input the number of cruise in the value blank, then click Cruise between Points button, PTZ begins to work on the cruise line.
  • Page 21: Color Setting

    Picture 3.14 Scan Setup 2)Scan Calls In Picture 3.10, click Page Shift button, then enter PTZ control menu as shown in Picture 3.12. Please input the number of scan in the value blank, then click Scan button,PTZ begins to work on the scan line.
  • Page 22: Output Adjust

    3.5.7 Output Adjust Adjust TV output area parameters. You can use the desktop shortcut menu or enter [main menu]> [management tools]> [Output adjust]. Picture 3.19 Output Adjust 3.5.8 Logout Logout, shut down the system or reboot up. You can use the desktop shortcut menu or enter [main menu].
  • Page 23: Main Menu

    system is shut down. Cancel midway is of no effect. 【reboot】Quit the system. Reboot up the system. 3.5.9 Window switch Preview in single window/four windows/eight windows/nine windows/sixteen windows according to your choice. 4 Main menu 4.1 Main menu navigation Main menu Sub menu Function Config...
  • Page 24 No disk, storage device error, disk no space, net disconnection, IP Abnormality conflicted General Set system time, data format, language, hard disk full time operation, configuration machine number, video format, output mode, summertime, stay time Set main (extra) coding parameter: code mode, resolving ability, frame Encode rate, code stream control, image quality type, code stream value, frame configuration...
  • Page 25: Record

    Resume setup state: common setup, code setup, recording setup, Restore alarm setup, network setup, network service, preview playback, serial port setup, user management Upgrade upgrade with external device(like USB) Device Info device hardware configuration and message Export the device's log or configuration to external device(like USB Import/Export flash disk);Input the configuration with external device(like USB flash disk).
  • Page 26 Picture 4.1 Record Configuration 【Channel】Choose the corresponding channel number to set the channel. Choose the all option to set the entire channels. 【Redundancy】 Choose the redundancy function option to implement the file double backup function. Double backup is writing the video files in two hard disks. When you do the double backup, make sure that there are two hard disks installed.
  • Page 27: Playback

    as opening recording, the “detection recording” state is on. The video file type is “A”. Note: Refer to chapter 4.3 to set corresponding alarm function. 4.2.2 Playback Refer to chapter 3.5.2. 4.2.3 Backup You can back up the video files to external storage through setup. Note:The storage must be installed before the file backup.
  • Page 28: Alarm Function

    Picture 4.3 Backup Remove:Clear the file information. Add:Show the file information satisfying the set file attributes. Backup format:configure the backup file format, according to require, can choose Start/pause:Click the play button to start the backup and click the pause button to stop the backup.
  • Page 29 Pic 4.4 【Channel】Choose the set motion detect channel. 【Sensitivity】Choose in the six options according to the 【Region】Click [set] to enter the set area. The area is divided into PAL22X18. Red block means the motion detect defensive area. White block means the unfenced area. You can set the area as followed, Drag the mouse and draw the area.
  • Page 30 Picture 4.6 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval. 【Alarm output】Start the external equipment of corresponding linkage alarm when the motion detect alarm is turned on. 【Delay】Delay a few moments and stop when the alarm state is turned off.
  • Page 31: Video Blind

    Picture 4.7 PTZ Activation under hybrid mode 【Delay】When alarm is over, recording will last some seconds(10~300sec),then stop. 【Show message】Pop the alarm information dialog box in the local host computer screen. 【Send EMAIL】■ means sending an email to user when the alarm is turned on. Note: Set in the [NetService] and send email.
  • Page 32: Alarm Input

    Pic 4.9 Video loss Set method: refer to chapter 4.3.1. Motion detect 4.3.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on. Note: "Advanced" button is the same as right click. Pic 4.10 Alarm input Set method: refer to chapter 4.3.1.
  • Page 33: Alarm Output

    4.3.5 Alarm output Refer to chapter 3.5.4. 4.3.6 Abnormality Analyzing and inspecting current software and hardware of the device: When some abnormal events happen,the device will make a relative answer such as show message and buzzer. Picture 4.11 Abnormal 【Event Type】 selecting abnormity you want to inspect 【Enable】...
  • Page 34: General

    4.4.1 General Picture 4.17 General setup 【System time】Set the system data and time. 【Date format】Choose the data format: YMD, MDY, DMY. 【Date Separator】Choose list separator of the data format. 【Time Format】Choose time format: 24-hour or 12-hour. 【Language】Support multiple language 【HDD full】Choose stop record: Stop recording when the hard disk is full. Choose overwrite: Cover the earliest recording files and continue recording when the hard disk is full.
  • Page 35: Encode Setup

    Picture 4.18 DST (week) Picture 4.19 DST (date) 4.4.2 Encode setup Set the video/audio code parameter: video file, remote monitoring and so on. Set every main stream parameter in the left part, and set the extra stream parameter in the right part. Note: extra stream introduces video compression technique which was applying for multi-channel playback simultaneously, Dial-up multi-channel real-time monitor under poor bandwidth, or mobile monitor and so on.
  • Page 36 Picture 4.20 Encode setup Independent channel code setting 【Channel】Choose the channel number. 【Compression】Standard H.264 main profile. 【Resolution】Video resolution. 【Frame Rate】Set video frame rate 【Bit Rate Type】You can choose limited code stream or variable code stream. When you choose the variable code stream there are six image quality options.Under the limited code stream,you can choose the code stream manually;...
  • Page 37: Network Setup

    4.4.3 Network setup Picture4.21 Network 【DHCP Enable】Obtain IP address automatically(not suggested) 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code. Default: 255.255.255.0. 【Gateway】Set the default gateway. Default: 192.168.1.1. 【DNS setup】Domain Name Server. It translates the domain name into IP address. The IP address is offered by network provider.
  • Page 38 Picture 4.22 NetService 【PPPoE setup】 Picture4.23 PPPOE Enable:Reverse■ means choose,setting can become effective. Input the user name and password that ISP(Internet service provider)provides. After saving it reboot up your system. Then the DVR will build a network connection based on PPPoE. The IP address will change into dynamic IP address after above operation is well done.
  • Page 39 Picture 4.24 NTP The NTP server must be installed in the PC. Sever IP:Input the IP address installed NTP server. Port:Default: 123. You can set the port according to NTP server. Update Period:The same with the NTP server check interval. Default: 10minutes. 【EMAIL setup】...
  • Page 40 Sender:Set the email sender address. Receiver:Send the email to appointed receivers when the alarm is turned on. You can set three receivers at most. Title:Email title. 【IP Filter setup】 When choosing the white list, only the listed IP address can connect the DVR. The 64 IP addressed are supportive in the list.
  • Page 41 It is the abbreviation of dynamic domain name server. Local domain name:Provide the domain name registered by DDNS. User name:Provide the account registered by DDNS. Password: Provide the password registered by DDNS. When the DDNS is successfully configured and start, you can connect the domain name in the IE address column to visit.
  • Page 42 Picture 4.29 ARSP [Type] Choose "DNS" [Sever IP]: IP address of DDNS server [Port]: Port No. of device, related DDNS server listen port [User name] the user name that device can log in DDNS server [Password] the password related to the user name. [Update period]:Time interval between device and DDNS when update.
  • Page 43 ADSL through 3G net card, use CMS to visit and config the device Picture 4.31 Wireless Config 【Enable】Choose Enable to make all settings available 【Type】Dial type,default AUTO 【Wireless AP】3G access point 【Dial Number】3G Dial Number 【User Name】User name of 3G 【Password】Password of dial user 【IP Address】IP address,got from dial 【Mobile Monitor Setup】...
  • Page 44 UPNP protocol is to realize auto port forwarding on router, precondition of using this function is to make sure the UPNP function of router is enabled. Picture 4.33 UPNP 【Enable】Choose Enable to make sure all UPNP settings available 【HTTP】Route will automatically distribute HTTP port for the device,when IE viewing,it need this port 【TCP】Router will automatically distribute TCP port for the device,when monitoring via CMS,it need this port.
  • Page 45 【RTSP】 To do surveillance via cross-browser (Safari, Firefox, Google chrome) and VLC software. This function only for monitor but cannot control the device. Pic 4.35 RTSP setting 【Port】 :the default port is 554 【Cloud】 【Enable】The user can enter http://www.xmeye.net to login device by serial number. Pic 4.29 cloud...
  • Page 46: Display

    4.4.5 Display Configure the video output parameters including the front output mode and encode output mode. Front output:In the local preview mode include: channel title, time display, channel display, record status, alarm status, transparency and region cover. Encode output:In the network surveillance and video file mode include: channel title, time display, channel display, record status, alarm status, transparency and region cover.
  • Page 47: Ptz Config

    【 Region Cover 】 means the selective state. Click the cover area button and enter the correspondingchannel window. You can cover the arbitrary using mouse. (Black region is for output) 【Time display】and 【Channel display】 set the display position of channel title and time title. 4.4.6 PTZ config Pic 4.37 PTZ configure 【Channel】Choose the dome camera input channel.
  • Page 48: Rs232

    4.4.7 RS232 Pic 4.39 serial port setting 【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port. 【Baud rate】Choose the corresponding baud rate length. 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options. 【Parity】Include odd, even, mark, space, default is none.
  • Page 49 【interval】Set the patrol switch interval. The set range is 5-120 seconds. 【alarm tour】set the interval to shift alarm tour, range is 5-120 seconds, choose return when alarm ends, when alarm link to tour, system will auto shift to six-view after alarm finished. Remark:at preview mode, click upper right icon can turn on / off mean turn on,...
  • Page 50: Advanced

    4.5 Advanced Manage tools menu including: HDD manage, account manage, online user, output adjust, auto maintain, upgrade. 4.5.1 HDD Manage Configure and manage the hard disk. The menu displays current hard disk information: hard disk number, input port, type, status and overall capability. The operation include: setup the write-read disk, read-only disk, redundant disk, hard disk format, resume default.
  • Page 51 can appoint the purview in the group. 3. The user management include: group/ user. The group and user name cannot be the same. Each user only belongs to one group. Pic 4.47 account management 【Modify User】Modify the existed user attribute. 【Modify Group】Modify the existed team attribute.
  • Page 52 Pic 4.49 Add User 【Add Group】Add a user group and set the purview. There are 33 different purviews: shut down the equipment, real time surveillance, playback, record setting, and video backup and so on. Pic 4.50 add group 【Delete User】Delete the current user. Choose the user and click delete user button. 【Delete Group】Delete the current group.
  • Page 53: Online User

    4.5.3 Online user To check the information of network user that connected with local device, also can tick the selected user to break up connection, then the user will be frozen after connection stopped, and will not log in until device reboot.
  • Page 54: Upgrade

    Pic 4.54 restore to default 4.5.7 Upgrade Upgrade Pic 4.55 【Upgrade】choose USB interface. 【Upgrade file】choose the upgrade file. 4.5.8 Device Info Provide device interface info like audio in, alarm in/out to be conveniently used for user.
  • Page 55: Import / Export

    Pic 4.56 device info 4.5.9 Import / Export Users can export the log info and the configure file from device to connected flash stick, and also can import related configure file from flash stick to settings, which greatly bring convenience to the customers.
  • Page 56: Hdd Info

    4.6.1 HDD info Display the hard disk state: hard disk type, overall capability, residual capability, the recording time and so on. Pic 4.58 HDD info 4.6.2 BPS Display the code stream(Kb/S)and hard disk capability (MB/H)in real time. It displays as the wave sketch map.
  • Page 57: Log

    4.6.3 LOG To search log information base on the set search mode. Log information include: system operation, configuration operation, data management, alarm affair, recording operation, user management, and file management and so on. Set the time section to look up and click the look up button.
  • Page 58: Shut Down System

    Pic 4.61 version information 4.7 Shut down system Refer to chapter 3.5.8.
  • Page 59: Faq

    5 FAQ 5.1 FAQ 1、 The DVR can not boot up normally. Possible reasons are as followed: The power supply is not correct. Switch power supply line is not in good connection. The program updating is wrong. The hard disk is damaged or the hard disk lines are broken. The front panel is damaged.
  • Page 60 The channel protection or the screen protection is set. The hardware of the DVR is damaged. 5、 Real-time image problems such as the image color or the brightness distortion. Possible reasons are as followed: When using the BNC output, the option between the N mode or PAL mode is wrong and the image becomes black and white.
  • Page 61 9、 There is audio signal in the surveillance window but no audio signal in the playback state. Possible reasons are as followed: Setting issues: the audio option is not chosen. The according channel is not connected with the video. 10、 The time is wrong.
  • Page 62 higher Version or installing the software for low edition. ActiveX is hold back. The version is not exceeded dx8.1. Update the display card driver. Network connection failure. Network setting issues. Invalid password or user name. The CMS is not matched the DVR program version. 14、...
  • Page 63 17、 The remote controller is not working, Possible reasons are as followed: The remote control address is not correct. The remote control distance is too far or the angle is too large. The battery is used up. The remote controller or the front panel of the recording machine is damaged. 18、...
  • Page 65 Directorio 1 Introducción del Producto ..........................67 1.1 Visión general del producto ......................... 67 1.2 Funciones principales .......................... 67 2 Verificando apertura de empaque y conexiones .................... 68 2.1 Verificando apertura de empaque ....................... 68 2.2 Instalacion de disco duro ........................69 2.3 Instalacion de la cubierta ........................
  • Page 66 4.4.4 NetService ..........................99 4.4.5 Pantalla ........................... 107 4.4.6 Ajuste PTZ ..........................109 4.4.7 RS232 ............................. 110 4.4.8 Tour ................................110 4.5 Avanzado ............................112 4.5.1 Administrar disco duro ......................112 4.5.2 Cuenta ............................ 112 4.5.3 usuario en línea ........................115 4.5.4 Ajustar TV..........................
  • Page 67: Introducción Del Producto

    1 Introducción del Producto 1.1 Visión general del producto La DVR serie está diseñada especialmente para el campo de la seguridad y defensa que es un producto de vigilancia digital excepcional. Se introduce el sistema operativo Linux embebido que es más estable. Se presenta en formato estándar H.264MP vídeo comprimido y el formato de audio comprimido G.711A que asegura la calidad de imagen de alta, baja proporción de errores de codificación y reproducción de un solo cuadro.
  • Page 68: Verificando Apertura De Empaque Y Conexiones

    · El control de la tele-PTZ · Verificación de tele-grabación y reproducción en tiempo real Acoplamiento de la alarma · Alarma activada grabación de vídeo, gira, mensaje, timbre, correo electrónico, FTP Interface de comunicación · Interfaz RS485 que cumple con la entrada de alarma y control PTZ ·...
  • Page 69: Instalacion De Disco Duro

    2.2 Instalación de disco duro Para el primer uso, por favor, instale el disco duro, este cuadro de máquina se puede instalar dos discos duros (sin capacidad limitada). Tome el cable de tornillo y abierta cubierta de la fuente de datos y conectar el disco duro Fijar el disco duro y la cubierta 2.3 Instalación de la cubierta Esta especificación de producto para el chasis 1U estándar, por lo que se puede instalar en el estante...
  • Page 70: Panel Frontal

    2.4 Panel Frontal IMAGEN REFERENCIAL 1 2 3 1. ENCENDIDO 2. ALARMA 3. GRABACION 4. CONTROLES 3.1 Panel Trasero 1. Entrada de Video 2. Salida deAudio 3. HDMI 4. VGA 5. Entrada de Audio 6. USB 7. LAN 8. PTZ RS485 9.
  • Page 71: Las Conexiones De Entrada Y Salida De Audio Y Vídeo

    2.5 Las conexiones de entrada y salida de audio y vídeo 2.5.1 conexiones de entrada de vídeo El puerto de entrada de vídeo es plug conector BNC. La demanda de la señal de entrada es PAL / NTSC 75Ω). BNC (1.0V La señal de vídeo debe otorgar a la norma estatal que tiene la alta relación señal a ruido, baja aberración y baja interferencia.
  • Page 72: Salida De Señal De Audio

    La línea de señal de audio debe ser firme y lejos de la interferencia electromagnética y conectada creíble que evitan la oxidación de la soldadura y el falso y conjunta. La corriente de alta tensión se debe evitar especialmente 2.5.4 Salida de señal de audio Normalmente, el parámetro de salida de la señal de audio DVR es mayor que 200 mV 1 kW (BNC) que se puede conectar los auriculares de baja impedancia y la caja de sonido activo u otros equipos de salida de...
  • Page 73: Apague

    Nota: 1. Asegúrese de que la tensión de entrada se corresponde con el interruptor de la fuente de alimentación del DVR. 1. Demandas de suministro de energía: 220V ± 10% / 50Hz. Se sugiere usar el SAI para proteger la fuente de alimentación en condiciones aceptables 3.2 Apague Hay dos métodos para apagar el DVR.
  • Page 74: Vista Previa

    Imagen 3.1 Ingreso en el sistema La protección por contraseña: Si la contraseña es incorrecta tres veces continuas, la alarma se inicia. Si la contraseña es incorrecta cinco veces continuas, la cuenta será bloqueada. (A través de reinicio o después de media hora, la cuenta se desbloqueará...
  • Page 75: Menú Principal

    Imagen 3.2 Imagen del menú de acceso directo 3.5.1 Menú Principal Cuando vuelve a entrar, el menú principal del sistema se muestra a continuación. Imagen3.3 Menú Principal 3.5.2 reproduc ción n el disco duro. dos métodos para que usted juegu e los archivos de vídeo e escritorio.
  • Page 76 Imagen 3.4 Imagen de reproducción de vídeo...
  • Page 77 intervalo de Control de toque la Re modo de tiempo reproducción operación cordón para elegir Interruptor de fecha de tiempo, modo de la búsqueda elección archivo de archivos canal elección elección dispositivo de Información Los archivos tiempo de almacenamiento del archivo listados búsqueda 【...
  • Page 78: Registro De Control

    luego a la izquierda haga clic en el ratón para realizar zoom local. Doble clic izquierdo para salir. 3.5.3 Registro de Control Por favor, compruebe el estado del canal actual: "○" significa que no se encuentra en estado de grabación "●" significa que está en estado de grabación. Puede utilizar el menú...
  • Page 79: Control Ptz

    Imagen 3.9 Salida de alarma 【Configuración】 alarma está en función de la configuración. 【Manual】 Haga clic en todo el botón y el canal de acuerdo es alarmante, sin importar el canal en cualquier estado. 【Detener】 Haga clic en el botón de parada y el canal se detiene según alarmante sin importar el canal en cualquier estado 3.5.5 Control PTZ...
  • Page 80 【PTZ de alta velocidad】Demostración de la imagen del canal en pantalla completa . Izquierdo del ratón y pulse el control PTZ para rotar la orientación. Izquierdo del ratón presione y luego girar el ratón para ajustar el múltiplo de zoom de la cámara. 【Set】...
  • Page 81 EnImagen 3.10, haga clic en Página botón Shift, introduzca PTZ interfaz de control. En la entrada en blanco, escribir los puntos preestablecidos, haga clic en botón de memorización, PTZ a su vez hasta el punto de preselección correspondiente. 2、 Crucero entre los puntos Puntos preestablecidos múltiples líneas de cruceros, crucero de llamada entre puntos conectados, el PTZ correr en la línea 1)...
  • Page 82 Imagen 3.13 Configuración de crucero entre los puntos Las llamadas de crucero entre los puntos 2) En Imagen 3.10, haga clic en Página botón Shift, entrar en el menú de control PTZ, como se muestra en el Cuadro 3.12. Por favor introduce el número de cruceros en el valor en blanco, a continuación, haga clic en .
  • Page 83: Ajuste De Color

    3.5.6 Ajuste de Color Establecer los parámetros de la imagen selectivos (canal actual de visualización de la ventana única y lugar del cursor para la visualización de múltiples ventanas). Se puede utilizar el menú de acceso directo del escritorio y entrar en la interfaz. Los parámetros de la imagen incluyen: tonalidad, brillo, contraste, saturación.
  • Page 84: Logout

    3.5.8 Cierre de sesión Cierre de sesión, apagar el sistema o reiniciar arriba. Se puede utilizar el menú de acceso directo del escritorio o introduzca [menú principal]. Imagen 3.20 Salir / Apagar / reiniciar el sistema 【Salida】 Salir del menú. Oferta contraseña la próxima entrada 【...
  • Page 85 Detectar el dispositivo de copia de seguridad, formato de apoyo Devic electrónico, una copia de los archivos selectivos Conjunto de detección de movimiento canal de alarma, la sensibilidad, la zona, parámetros de vinculación: la Movimiento sección del tiempo, la salida de alarma, toque la detección pantalla, la grabación, captura de pantalla defensa, PTZ, patrulla, zumbido, correo electrónico y carga FTP...
  • Page 86 Definición de la codificación principal (adicional) de parámetros: modo de código, la capacidad de resolución, Codificar velocidad de fotogramas, el control de flujo de código, configuración imágenes de tipo calidad, el valor corriente del código, marco entre el valor, el vídeo / audio permiten, Establecer los parámetros básicos de la red, los parámetros de DHCP y DNS, red de alta velocidad de configuración...
  • Page 87: Grabación

    Ajuste positivo, negativo, cara visible, la distancia ajuste de salida estribor, el margen negro vertical y horizontal Ajuste el sistema de reinicio automático y eliminación Automático mantenimiento archivos automáticas. Restaurar configuración: configuración común, configuración del código, la configuración de la grabación, Restaurar configuración de alarmas, configuración de red, servicios de red, la reproducción de vista previa, configuración del...
  • Page 88 [Función de grabación]> [Configuración de grabación] para ajustar Nota: No existe por lo menos una lectura-escritura de disco duro (consulte el capítulo 4.5.1) Imagen 4.1 Ajuste de grabación 【Canal】 Selecciona el número de canal correspondiente para establecer el canal. Elija la opción de todo para sintonizar los canales enteros 【Redundancia】...
  • Page 89: Reproducción

    Regular: Realice la grabación normal en la sección de tiempo establecido. El tipo de archivo de vídeo es "R" Detectar: desencadenan la "detección de movimiento", "Máscara de la cámara" o señal de "pérdida de vídeo". Cuando por encima de alarma se establece como la apertura de la grabación, el estado "grabación por detección"...
  • Page 90: Función De Alarma

    【Detectar】 Detectar el almacenamiento conectado con el DVR como el disco duro o un disco universal 【Respaldo】 Haga clic en el botón de copia de seguridad y el cuadro de diálogo está elevado. Se puede elegir el archivo de copia de seguridad de acuerdo con el tipo, el canal y la hora Imagen 4.3 Respaldo Quitar: Borrar la información del archivo Añadir: muestra la información del archivo de la satisfacción de los atributos de archivo conjunto...
  • Page 91: Detección De Movimiento

    4.3.1 Detección de movimiento Cuando el sistema detecta la señal de movimiento que llega a la sensibilidad ajustada, el movimiento detecta la alarma está encendida y la función de enlace está encendida. Nota: el botón "Avanzado" es el mismo que el botón derecho del ratón. Imagen 4.4 【Canal】Seleccione el canal para ajustar detección de movimiento.
  • Page 92 tiempo. ■ significa que el conjunto válido. Imagen 4.6 E stablecer el intervalo de tiempo 【Intervalo】 Sólo una señal de alarma está activada, incluso hay varias señales de detección de movimiento en el intervalo establecido 【 】 Salida de alarma Arranque el equipo externo correspondiente de la alarma del acoplamiento cuando el movimiento detecta la alarma está...
  • Page 93: Bloqueo De Area De Video

    【Demora】 Cuando la alarma ha terminado, la grabación va a durar algunos segundos (10 ~ 300 seg), y luego se detiene 【Mostrar mensaje】Muestra el cuadro de diálogo de información de la alarma en la pantalla del ordenador host local 【Enviar EMAIL】 significa el envío de un correo electrónico al usuario cuando la alarma está...
  • Page 94: Alarma De Entrada

    encendida y la función de enlace está encendida Imagen 4.9 Perdida de video Ajuste de método: véase el capítulo 4.3.1. Detección de movimiento 4.3.4 Alarma de entrada Cuando el equipo obtiene la señal de alarma externa, la función de alarma está activada. Nota: el botón "Avanzado"...
  • Page 95: Alarma De Salida

    4.3.5 Alarma de salida 3.5.4. Consulte el capítulo 4.3.6 Anormalidad El análisis y la inspección actual del software y hardware del dispositivo: Cuando algunos eventos anormales ocurren, el dispositivo hará una respuesta relativa, como mensaje de espectáculo y zumbador Imagen 4.11 Anormalidad 【Tipo de evento】seleccionando la anomalía que desea inspeccionar 【Habilitar】Seleccionar para asegurarse de que la función este activada 【Mostrar mensaje】Automáticamente un cuadro de alarma será...
  • Page 96: General

    4.4.1 General Imagen 4.17 Configuración general 【Hora del sistema】Establece hora y fecha del sistema. 【Formato de fecha】 Seleccione el formato de datos: AMD, MDA, DMA. 【Separador de fecha】 Elija separador de lista del formato de datos 【Formato de hora】 Seleccione el formato de hora: 24 horas o 12 horas 【Idioma】...
  • Page 97: Configurar Codificación

    Imagen 4.18 DST (semana) Imagen 4.19 DST (fecha) 4.4.2 Configurar codificación Ajuste el parámetro de código de video / audio: archivo de vídeo, control remoto y así sucesivamente. Establecer todos los parámetros de la corriente principal en la parte izquierda, y establecer el parámetro de flujo adicional en la parte derecha.
  • Page 98 Imagen 4.20 Configurar codificación Ajuste del código de canal independiente 【Canal】 Selecciona el número de canal 【Compresión】Standard H.264 perfil principal i 【 ónResoluc 】 Resolución de vídeo. 【 Frame Rate 】 velocidad de fotogramas de vídeo Ajuste 【 Bit Rate Tipo 】Puede elegir la corriente del código limitado o flujo de código variable. Cuando se elige la variable de flujo de código hay seis opciones de calidad de imagen.
  • Page 99: Configuración De La Red

    4.4.3 Configuración de la red Imagen 4.21Red 【 DHCP Habilitar 】 Obtener la dirección IP automáticamente (no se recomienda) 【 Dirección IP 】 establecer la dirección IP. Por defecto: 192.168.1.10. 【 Máscara de subred 】 Establecer el código de máscara de subred. Por defecto: 255.255.255.0. 【...
  • Page 100 Imagen 4.22 NetService 【 】 Configuración PPPoE Imagen4.23 PPPOE Habilitar. Introducir nombre usuario contraseña ISP (Internet ServiceProvider) proporciona. Después de guardar que se reinicie el sistema. A continuación, la DVR va a construir una conexión de red basada en el protocolo PPPoE. La dirección IP se convertirá en la dirección IP dinámica después de la operación anterior está...
  • Page 101 【Ajuste NTP】 Imagen 4.24 NTP El servidor NTP debe estar instalado en el PC. IP del Servidor: Introduzca la dirección IP del servidor NTP instalado. Puerto: Por defecto: 123. Usted puede establecer el puerto de acuerdo con servidor NTP. Actualización Periodo: Lo mismo con el intervalo de comprobación de servidor NTP. Por defecto: 10 minutos.
  • Page 102 Receptor: Enviar el correo electrónico a los receptores designados cuando la alarma está activada. Puede establecer tres receptores como máximo. Título: el título de correo electrónico 【 Configuración de filtros IP 】 Al elegir la lista blanca, sólo la dirección IP que aparece puede conectar el DVR. El 64 IP abordado se apoya en la lista.
  • Page 103 Cuando el DDNS está configurado correctamente y empezar, se puede conectar el nombre de dominio en la columna de la dirección de IE para visitar 【Ajuste FTP】 FTP está disponible sólo cuando la alarma ocurre, o la alarma se activa y el registro de instantáneas, subirá relacionadas grabaciones y las imágenes de captura a un servidor FTP Imagen 4.28 Ajuste FTP 【...
  • Page 104 Imagen 4.29 ARSP [Tipo] Seleccione "DNS" [IP del servidor]: dirección IP del servidor DDNS [Puerto]: Nº de puerto del dispositivo, servidor DDNS relacionada puerto de escucha [Nombre de usuario] el nombre de usuario que el dispositivo puede iniciar sesión en el servidor DDNS [Contraseña] la contraseña relacionada con el nombre de usuario.
  • Page 105 Imagen 4.31 Configuración inalámbrica 【 Habilitar 】 elige Habilitar para hacer todos los ajustes disponibles 【 Tipo 】 tipo de marcación, por defecto AUTO 【 Punto de acceso inalámbrico 】 3G punto de acceso 【 Marcar número 】 3G números de marcación 【...
  • Page 106 Imagen 4.33 UPNP 【 Habilitar 】 elige Habilitar para asegurarse de que todos los ajustes UPnP disponibles 【 HTTP 】 Ruta distribuirá de forma automática el puerto HTTP para el dispositivo, cuando el IE de visión, se necesita este puerto 【...
  • Page 107: Pantalla

    Imagen 4.35 Ajuste RTSP 【Port】 : el puerto por defecto es 554 【Cloud】 【Habilitar】 El usuario puede ingresar en http://www.xmeye.net para iniciar sesión dispositivo por número de serie. Imagen 4.29 cloud 4.4.5 Pantalla Configurar los parámetros de salida de vídeo, incluyendo el modo de salida frontal y el modo de salida de codificación.
  • Page 108 Imagen 4.36 Modo salida 【 Canal Título 】 Haga clic en el nombre del canal botón modificar y acceder al menú de nombre de canal. Modificar el nombre del canal. Los 16 caracteres chinos y 25 letras son de apoyo. 【...
  • Page 109: Ajuste Ptz

    4.4.6 Ajuste PTZ Imagen 4.37 Configurar PTZ 【 Canal 】 Elija el canal de entrada de la cámara domo. 【 Protocolo 】 Selecciona el protocolo correspondiente cúpula. (PELCOD como ejemplo) 【 Dirección 】 Establecer como la dirección de la cámara correspondiente. Por defecto: 1. (Nota: La dirección debe ser consistente con la dirección de la cámara.) 【...
  • Page 110: Rs232

    4.4.7 RS232 Imagen 4.39 Ajuste de Puerto serial 【 Función de puerto serial 】 puerto serial común se utiliza para depurar y programa de actualización o configurar el puerto serie específico. 【 Velocidad de transmisión 】 Elija la longitud de la velocidad de transmisión correspondiente. 【...
  • Page 111 Imagen 4.40 Configurar recorrido 【 Intervalo 】 Establecer el intervalo de interruptor de patrulla. El rango de ajuste es 5-120 segundos. 【 Recorrido de alarma 】 establecer el intervalo para cambiar gira de alarma, el rango es 5-120 segundos, elija volver cuando termina la alarma, cuando el enlace de alarma para recorrer, el sistema de cambio automático de seis vistas de alarma después de terminado.
  • Page 112: Avanzado

    4.5 Avanzado Administrar menú de herramientas, entre ellas: HDD gestionar, administrar la cuenta, el usuario en línea, ajuste de salida, auto mantener, actualizar 4.5.1 Administrar disco duro Configurar y gestionar el disco duro. El menú muestra la información actual de disco duro: número del disco duro, puerto de entrada, el tipo, el estado y la capacidad general.
  • Page 113 Imagen 4.47 Gestionar cuentas 【 Modificar usuario 】 Modificar el atributo de usuario existido. 【 Modificar Grupo 】 Modificar el atributo equipo existido. 【 Modificar contraseña 】 Modificar la contraseña de usuario. Se puede establecer una contraseña 1-6 bits. El espacio en blanco delante o por detrás de la línea char es válido. El blanco medio en la cadena char es válida Imagen 4.48 modificar la contraseña...
  • Page 114 Imagen 4.49 Agregar usuario 【 Agregar grupo 】Añadir un grupo de usuarios y establecer la competencia. Hay 33 pre visualizaciones diferentes: apagar el equipo, la vigilancia en tiempo real, reproducción, ajuste de grabación, copia de seguridad de vídeo y así sucesivamente Imagen 4.50 Añadir Grupo 【...
  • Page 115: Usuario En Línea

    4.5.3 Usuario en línea Para comprobar la información de usuario de la red que conecta con el dispositivo local, también puede marcar el usuario seleccionado para romper la conexión, el usuario será congelada después de la conexión se detuvo, y no podrá conectarse hasta que reinicio del dispositivo. Imagen 4.52 usuario online 4.5.4 Ajustar Consulte el capítulo 3.5.7.
  • Page 116: Actualización

    Imagen 4.54 Restaurar a los valores predeterminados 4.5.7 Actualización Imagen 4. 55 Actualización 【Upgrade】 elegir interfaz USB 【Upgrade file】 elegir el archivo de actualización 4.5.8 Información del dispositivo Proporcionar información interfaz de dispositivo como entrada de audio, alarma de entrada / salida para ser utilizado convenientemente para el usuario...
  • Page 117: Importar / Exportar

    Imagen 4.56 información del dispositivo 4.5.9 Importar / Exportar Los usuarios pueden exportar la información de registro y el archivo de configuración del dispositivo para flash stick conectado, y también puede importar el archivo de configuración relacionada del flash del palillo de los ajustes, los cuales aportan en gran medida la comodidad de los clientes 4.57 Importar / Exportar interfaz 4.6 Información...
  • Page 118: Información Del Hdd

    4.6.1 información del HDD Visualizar el estado del disco duro: tipo de disco duro, capacidad general, la capacidad residual, el tiempo de grabación y así sucesivamente Imagen 4.58 información del HDD 4.6.2 BPS Visualizar el flujo de código (Kb / S) y la capacidad del disco duro (MB / H) en tiempo real. Se muestra como el croquis de onda Imagen 4.59 BPS 4.6.3...
  • Page 119: Versión

    Información de registro incluye: el funcionamiento del sistema, el servicio de configuración, gestión de datos, asunto de alarma, la grabación, gestión de usuarios, gestión de archivos y así sucesivamente. Ajuste el intervalo de tiempo para mirar hacia arriba y haga clic en el botón de buscar. La información de registro se mostrará...
  • Page 120: Preguntas

    5 Preguntas 5.1 Preguntas 20、 El DVR no puede arrancar normalmente Las posibles razones son como sigue: La fuente de alimentación no es correcta. Modificador de la línea de alimentación no está en buena conexión. La actualización del programa es errónea. El disco duro está...
  • Page 121 24、 Problemas de imagen en tiempo real, tales como el color de la imagen o la distorsión de brillo Las posibles razones son como sigue: Cuando se utiliza la salida BNC, la opción entre el modo de modo o PAL N está mal y la imagen aparece en blanco y negro.
  • Page 122 29、 El tiempo está malo Las posibles razones son como sigue: Ajuste es incorrecto. La batería es de mala conexión o el voltaje es demasiado bajo. La oscilación está dañado 30、 El DVR no puede controlar el PTZ Las posibles razones son como sigue: Hay algo mal con el PTZ frontal.
  • Page 123 modo reproducción Las posibles razones son como sigue: La red no es estable. La máquina del usuario es limitado recurso. Elige el modo de juego-en-equipo en la configuración de red del DVR. La región se establece la protección de refugio o canal. El usuario no tiene competencia de vigilancia.
  • Page 124 Las posibles razones son como sigue: No hay medios de comunicación p capa. No hay software de versiones DirectX 8.1 o superior edición. No hay ningún archivo DivX503Bundle.exe para reproducir archivos de vídeo AVI. El 1012 archivos .exe ffdshow-2004 DivX503Bundle.exe y se deben instalar en el sistema Windows XP 39、...
  • Page 125 Any other questions you can contact our Technical Support Department at support@logan- cam.com Cualquier otra consulta se puede comunicar al Departamento de Soporte Técnico a través del correo electrónico support@logan-cam.com http://www.logan-cam.com...
