Summary of Contents for EINHELL HEC 410
- Page 1 Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 1 ® Operating Instructions Hedge trimmer Art.-Nr.: 34.034.01...
-
Page 2: Technical Data
Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 2 Technical data Power supply 230 V ~ 50 Hz Power consumption 450 W Cutting length 40 cm Tooth spacing 12 mm Cuts/min n 3000 Noise power level LWA 95 dB(A) Noise pressure level LPA 87 dB(A) Vibration a 2,3 m/s... - Page 3 Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 3...
-
Page 4: Safety Instructions
Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 4 1. Safety instructions 1.18 When a blockage of the cutting device occurs, e.g. thick branches etc., the hedge trimmer Please read and follow the safety instructions must be made immediately inoperative carefully. -removal of mains plug- and only than may the 1.1 Before certain operations are undertaken with cause of the blockage be removed. -
Page 5: Mains Connection
Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 5 2. Fitting the hand guard and the 5. Operating instructions guide handle 5.1 In addition to hedges, a hedge trimmer can be employed for cutting scrubs and bushes. 1 Blade with storage bag 5.2 Cutting is best carried out if the hedge trimmer is 2 Hand guard guided so that the blade is kept at an angle of 5°... - Page 6 Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 6 Explosion Diagram HEC 410 Art.-Nr.: 34.034.00; I.-Nr.: 91017...
- Page 7 Anti-kink sleeve 34.035.00.13 Set of screws for the housing 34.035.00.14 Set of screws for the cutter rai 34.035.00.15 Cutter rail, complete for the HEC 410 34.034.00.01 Housing, 2 parts 34.035.00.17 Switch button 34.035.00.18 Cutter rail guard for the HEC 410 34.035.00.19...
- Page 8 Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 8...
- Page 9 Anleitung HEC GB 24.10.2001 15:27 Uhr Seite 9 Notizen:...
- Page 10 Any necessary replacement parts an necessary repair work are free of charge. We do not assume responsibility for consequential damage. Your customer service partner Einhell UK Ltd. Technical changes subject to change Brook House, Brookway North Cheshire Trading Estate, Prenton Wirral, Cheshire, CH43 3 DS Tel.
