3 Installation
3.1.1

Back mounting

min. 20
pin-and-socket connector
for control signals
Assembly for instance by gudgeon M6 with distance sleeve
Top
23 mm 270 mm
Lamp feeder cable
mains connection
319 mm
Fig. 1: Assembly of the ELC (all dimensions in mm).
ELC N6_N10-V3.1-09/11-GB subject to technical alterations
min. 20
23 mm
page 5
