Packaged Hardware - ADC PowerWorx Power Distribution User Manual

ADCP-80-575 • Issue 2 • December 2006
1.4

Packaged Hardware

The fuse platform is shipped with hardware components (shown in
separately and enclosed in the same carton. The packaged hardware components include the
following items:
• Two sets of mounting brackets (for 19-inch or 23-inch rack mounting)—Used to mount
the panel on the equipment rack.
• 5/16-inch long, Phillips drive, 8-32 flat-head thread-forming screws (8)—Used to secure
the mounting brackets to the panel.
• 3/8-inch long, combination drive, 12-24 pan-head screws (4) and #12 flat washers (4)—
Used to secure the mounting brackets to the equipment rack.
• #10 ring terminals (2) for 12–10 AWG wire—Used to connect the grounding cables to the
grounding studs.
• Rear protective input terminal covers and output terminal covers—Used to prevent
accidental contact with the power input and output terminals. The number of covers
provided depends on the fuse configuration.
• Designation card and card holder—Used to record information about the protected
equipment. The card holder has a pressure-sensitive adhesive backing to permit
attachment to the panel, the rack, or a location close to the panel. The designation card
inserts into the card holder. It is also available as an accessory item.
Page 4
© 2006, ADC Telecommunications, Inc.
Figure 2) that are packaged
