Summary of Contents for Western Airconditioning PICCOLO Series
- Page 1 USE AND INSTALLATION MANUAL PICCOLO On/Off water cooled conditioning system SET CODE PICCOLO 12 PICCOLO 18 Versione 1.0...
- Page 2 DECLARATION OF CONFORMITY Description MONOSPLIT WATER TO AIR Model PICCOLO 12 PICCOLO 18 Is in compliance with the follow ECC direcrives, latest modification included, and the relevant nationale granting regulations in force: 2004/108/CE 2006/95/CE 2003/108/CE 2011/65/CE 2012/2016/CE...
-
Page 3: Table Of Contents
INDEX chapter page 1. GENERAL INFORMATION 2. DESCRIPRION UNIT PICCOLO 3. USER GUIDE INDOOR UNIT 4. CLEANING AND MAINTENANCE INDOOR UNIT 5. MALFUNCTION ANALYSIS INDOOR UNIT 6. PLACE OF INSTALLATION INDOOR UNIT 7. PRELIMINARY CHECKS 8. INSTALLATION INDOOR UNIT 9. CHECKS AFTER INSTALLATION 10. -
Page 4: General Information
1. GENERAL INFORMATION 1.1 SYMBOLOGY Within this publication and / or inside the equipment we used the following symbols: USER: Information, paragraph, chapter WARNING: Calls attention to actions that, Manual affecting the user or the user. if not correctly performed, may cause serious injury. - Page 5 GENERAL INFORMATION 1.3 OBSERVATIONS Keep the manual in a dry location to avoid deterioration. The device must be installed in such a way as to make possible the maintenance and / or repair. carefully read and understood all the information contained in this manual.
-
Page 6: Descriprion Unit Piccolo
GENERAL INFORMATION The Owner’s Manual is an integral part of the To disperse the parts of the package, or leave them within reach of children as they are potential sources equipment; it is recommended to read and kept with care. of danger. -
Page 7: User Guide Indoor Unit
USER GUIDE INDOOR UNIT 3. USER GUIDE INDOOR UNIT INDOOR UNIT REMOTE CONTROL inlet air panel display filter horizontal outlet emergency flap switch 3.1 BATTERY INSTALLATION 1. Press the back of the remote at the point indicated by the 3. After powering up the device, press the “ON / OFF” button symbol slide the cover in the direction of the arrow. - Page 8 USER GUIDE INDOOR UNIT 3.3 BUTTONS REMOTE CONTROL Sept. fan speed Ifeel signal reception turbo mode quiet function clean function auto mode temperatur cooling health function eco function function sleep function (not active) heating keyboard lock Func. not active clock temperature display display lighting horizontal flap...
- Page 9 USER GUIDE INDOOR UNIT auto cool dehumidification only heating ventilation (not active) To prevent the release of cold air once set the indoor the temperature range can be set from 16 to 31 ° C; air unit will delay of 1-5 min of air leakage. speed: Auto, fan1, fan2 Fan3, fan4, fan5 and turbo.
- Page 10 USER GUIDE INDOOR UNIT 3.11 BUTTON SLEEP Press this button to activate or deactivate the SLEEP mode - To change the “MODE” the SLEEP mode will be canceled. operation COOL / HEAT / DRY. - The feature is not available in FAN and AUTO modes. 3.12 BUTTON I FEEL to the indoor unit.
- Page 11 USER GUIDE INDOOR UNIT 3.17 BUTTON TIMER OFF will flash. Press “+” or “-” within 5 seconds. to adjust the This button selects the desired sleep time. After pressing the icon disappears, “OFF” and flashing 00:00. Press minutes. Each press of “+” or “-”, the clock will increase or “+”...
-
Page 12: Cleaning And Maintenance Indoor Unit
4. CLEANING AND MAINTENANCE INDOOR UNIT 4.1 CLEANING THE PANEL To clean the I.U. panel, it is recommended to use a soft damp cloth or dry. notes: Do not remove the panel to clean it. 4.2 CLEANING FILTERS 1. Open the panel. 2. -
Page 13: Malfunction Analysis Indoor Unit
5. MALFUNCTION ANALYSIS INDOOR UNIT 5.1 GENERAL IMPACTS OF NON-COMPLIANCE irregularity verification Remedy Cut off the power and feed it after a wait of at least There were power surges? 180sec. Move the remote closer all’U.I. Turn off fluorescent lamps There are fluorescent lamps? and try again. -
Page 14: Place Of Installation Indoor Unit
6. PLACE OF INSTALLATION INDOOR UNIT front 15 cm 15 cm 15 cm 250÷230 cm 6.1 PLACE OF CHOICE The installation in the following locations can result in non- 9. Select a location where the condensate can be dispersed compliance of operation: easily. -
Page 15: Preliminary Checks
7. PRELIMINARY CHECKS 7.1 EQUIPMENT 1. Level 8. cutter 9. Measuring tape 2. Drill 3. Hexagonal wrench 10. Pressure gauges 4. Wrench 11. Core drill 5. Vacuum pump 12. Vacuum cleaner 6. Screwdriver 13. Search Getaway 7. flaring 14. Metro 7.2 SAFETY PRECAUTIONS 1. -
Page 16: Installation Indoor Unit
8. INSTALLATION INDOOR UNIT 8.1 DRAINEG PIPE 1. The tube can be taken out in the direction right, rear left 2. Once you have decided to bring out the right pipe or the or right. left and cut the corresponding hole on the body. cut pipe Right rear 8.2 CONNECTION PIPES... - Page 17 INSTALLATION 8.4 ELECTRICAL CONNECTIONS 1. Open the panel, remove the screw on the cable cover. 5. Close the panel. - All connections between Indoor and Outdoor Unit should be 2. Thread the power cable on the hole at the back Inner Unity, carried out by qualified personnel.
- Page 18 INSTALLATION 8.6 WALL MOUNTING 1. Once covered, place the pipes and run them through the - The drain hose must not be over-coated in order to avoid the holes in the wall. obstruction. 2. Attach the indoor unit to the template. - The drain hose must follow the angle of the hole in the wall as shown in FIG.
-
Page 19: Checks After Installation
9. CHECKS AFTER INSTALLATION 9.1 EQUIPMENT Events to Monitor Problems associated with incorrect installation Installation is correct? The unit may drop, vibrate or make noise. Are the gas leakage been checked? Insufficient cooling. unit thermal insulation sufficient? It may cause condensation and consequent loss of water drops. Water drainage is optimal? It may cause condensation and consequent loss of water drops. -
Page 20: Installation Piccolo Unit Condensing
10. INSTALLATION PICCOLO UNIT CONDENSING 10.1 PLACE OF INSTALLATION The installation location should be agreed with the customer, - The front panel must be inspected, so the front space paying attention to the following points: should be adequate to permit the operator with all the steps required during installation, maintenance and assistance - The equipment should be placed in a technical room of (controls, adjustments, refrigerant charge). - Page 21 INSTALLATION 10.5 CONNECTIONS BETWEEN INDOOR UNIT AND OUTDOOR UNIT The indoor unit must be connected by means of the invalidate the warranty. In case of use of evaporating units with different refrigerant connections from those projected on condensing unit Flare connections of refrigeration quality copper tube fitted at the ends of Flare and dice isolated PICCOLO inverter drives use special fittings reduce (attention on the entire length.
- Page 22 INSTALLATION 10.11 WIRING It MUST MAKE AN EFFECTIVE EARTHING The manufacturer is not responsible for damage caused in the absence of the same The electrical connections must be made according to the electricity supplier. In the presence of three-phase supply, the following indications: unbalance between the three phases, must be at most 3%.
- Page 23 INSTALLATION pipe diameter [mm] tightening torque [Nm] 6,35 15 - 18 9,52 31 - 35 12,70 50 - 55 15,88 60 - 65 19,05 70 - 75 10.14 END OF INSTALLATION CHECKS A few simple checks ensure correct system operation: - Check the operating pressure (high pressure) by means of - Check the electrical connections.
-
Page 24: Self-Diagnosis
AUTODIAGNOSI 11. SELF-DIAGNOSIS Indoor unit PICCOLO 11.1 ERROR CODES ERROR TROUBLESHOOTING SOLUTION Turn off,restart after 5min,if the code occurs again after a few Overheat protection minutes, please contact the professional person. Turn off,restart after 5min,if the code occurs again after a few Over current protection minutes, please contact the professional person. -
Page 25: Maintenance Piccolo Unit
12. MAINTENANCE PICCOLO UNIT 12.1 ROUTINE MAINTENANCE Regular maintenance is essential to maintain the efficiency of - Efficiency safeties. the unit both in terms of operation and energy. - Power supply voltage. The maintenance plan that the Technical Assistance - Power consumption. Centre should be observed annually, provides the following - Tightness of electrical and PICCOLO connections.
