IR N OTES
Note:
IR a pplications i n t his s ection a re f or M odels: H E2BIR a nd H E1BIR. A ll d iagrams
reference M odel: H E2BIR. P lease n ote H E1BIR h as s ame I R s et u p i t j ust u ses 1 C at5/6
verses t he H E2BIR h as 2 C at5/6 c ables.
Basic I R S et U p D iagram
-­‐ I n t his d iagram t he I R b laster i s p lugged i nto t he B laster p ort o f t he
HE2BIR/HE1BIR t ransmitter. W hen u sing b laster t he o utput i s h igher t han n ormal
compared t o a e mitter. D o n ot p lace I R b laster d irectly o nto s ource e quipment s uch
as a B lu-­‐Ray p layer I R r eceiving w indow. T he s tronger s ignal c an o ver s aturate t he I R
receiver w indow o n t he d evice a nd c ause u nstable o r n on-­‐working p erformance.
Place t he b laster a f ew i nches a way f rom s ource e quipment o r b ounce I R o ff a
cabinet e tc. T est I R b laster l ocation f or b est p erformance b efore m ounting. P lug t he
IR R eceiver ( It i s l arger t han t he b laster) i nto t he I R R eceiver p ort o f t he
HE2BIR/HE1BIR r eceiver. M ount I R r eceiver i n a l ocation t hat w ill r eceive I R f rom
the r emote l ine o f s ight o r i nstall r eceiver s lightly b ehind b ottom o f T V f or a b ounced
IR e ffect. P lease n ote s ome T V's c an i nterfere w ith t he I R R eceiver. I t m ay b e b est t o
test I R R eceiver a way f rom t he T V i f i ntermittent p roblems a re b eing e xperienced t o
determine f inal l ocation o r u se C FL f riendly t ype I R R eceiver.
HE2BIR-TX
Transmission Range up to 130 Feet at 1080p
IR Blaster
IR Reciever
HE2BIR-RX
Two CAT5/6 cables
