Summary of Contents for Marport Trawl Speed

  • Page 1 Speed Sensors Service Manual...

  • Page 3: Table Of Contents

    Contents | ii Contents Legal....................4 History...................................4 Copyright..................................5 Disclaimer..................................5 Introduction and Presentation............6 Introduction................................6 Applications.................................7 Safety Guidelines..............................9 About Water Speed and Trawl Geometry......................10 Description.................................13 Firmware................................ 13 Technical Specifications...........................13 Main Parts..............................17 Installation Steps..............................19 Sensor Configuration..............20 Installing Mosa2..............................20 Connecting the Sensor to Mosa2........................21 Speed Explorer Specific Settings........................23 Sounding Modes............................
  • Page 4 Contents | iii System Configuration and Display..........47 Adding the Sensor to the Receiver......................... 47 Adding the Sensor with a Configuration File................. 47 Adding the Sensor Manually.........................49 Adding the Sensor to the Receiver..................49 Configuring the Sensor Settings....................51 Configuring Sensor Display on Scala/Scala2....................53 Outputting Scala/Scala2 Symmetry Data to Scantrol................

  • Page 5: Legal

    Speed Sensors | V5 | Legal Legal History 07/12/17 First release New topic: • About Time Variable Gain on page 27 03/09/18 Improved topic: • Replacing Parts on page 72: improved layout and pictures. New topic: • Troubleshooting: Sensor cannot connect in wireless connection on page 87 07/06/18...

  • Page 6: Copyright

    Marport. “Marport ”, the Marport logo and Software Defined Sonar are registered trademarks of Marport. All other brands, products and company names mentioned are the trademark and property of its respective owners only. Marport is a division of Airmar Technology Corporation.

  • Page 7: Introduction And Presentation

    The Trawl Speed sensor can be placed on the headline. It measures water flow in two axis: the flow along the direction of the trawl and across it. You can control if the trawl is moving at the right speed and with the right geometry.

  • Page 8: Applications

    These labels tag topics or actions that are specific to Scala and/or Scala2. Depending on the version you have, you may follow either one of these labels. Applications Here are some examples of data received from Grid, Trawl Speed and Speed Explorer sensors and displayed in Scala/Scala2. Grid sensor display...
  • Page 9 Speed Explorer display 1. Seabed / 2. Target strength (only for V3 version of sensors) / 3. Haddocks / 4. Trawl opening / 5. Trawl Speed dial: displays water across and along speeds. Trawl Speed 3D view 1. Control if the trawl opening has the correct angle. Across speed needs to be around 0.

  • Page 10: Safety Guidelines

    Install and use this product in accordance with this user manual. Incorrect use of the product may cause damage to the components or void the warranty. Only qualified Marport dealers can do maintenance and repairs on internal components of the sensors.

  • Page 11: About Water Speed And Trawl Geometry

    For example, you want the trawl speed to be at 5 knots relative to the water, and you have a GPS speed of 5 knots: •...
  • Page 12 Speed Sensors | V5 | Introduction and Presentation Across Water Speed Your trawl opening must be perpendicular to the current in order to catch more fish. The sensors measure the across water speed, that allows you to know if the trawl opening is perpendicular or not.
  • Page 13 Speed Sensors | V5 | Introduction and Presentation To see the water speeds and identify the trawl position, from Scala/Scala2, look at the Trawl Speed 3D view or Trawl Speed dial. | 12...

  • Page 14: Description

    30 to 60 kHz Range to vessel up to 2500 m* Data update rate Along/across speed: trawl speed and grid max. every 14 sec. - Symmetry: max. every 28 sec. - Pitch&Roll: 8 to 15 sec. (depends on settings) Depth range...
  • Page 15 Charging time Standard: 8-12 hours † Fast charge: 4 hours Battery type Lithium-Ion Weight of Trawl Speed and Symmetry 22.4 kg sensors (sensor + protection cage) in air Weight of Trawl Speed and Symmetry 13 kg sensors (sensor + protection cage) in water...
  • Page 16 13 kg Warranty 2 years (Sensor & Battery) ‡ *Reference only. Depends on functions enabled. / † Based on average charging time. / ‡ Marport Standard Marine Limited Warranty / **Depends on sensor uplink power. Speed Explorer Beamwidths Beamwidths for Uplink pings:...
  • Page 17 Speed Sensors | V5 | Introduction and Presentation Grid sensor | 16...

  • Page 18: Main Parts

    Speed Sensors | V5 | Introduction and Presentation Main Parts External View 1. Temperature 6. Pressure-relief sensor spring 2. Negative charge 7. Pressure sensor 3. Water switch 8. EM log pins 4. Positive charge 9. Latch 5. Shoulder bolts CAUTION: •...
  • Page 19 Speed Sensors | V5 | Introduction and Presentation PCBA Connectors 1. Sarah Connor PCBA 2. A1 PCBA 3. EM log Sarah Connor PCBA A1 PCBA 1. Battery connector 2. Down connector 3. Up connector (B) 4. Water switch 5. Uplink (C) 6.

  • Page 20: Installation Steps

    Speed Sensors | V5 | Introduction and Presentation Installation Steps Click an installation step to jump directly to the corresponding section. Note: You can customize the display of data on Scala/Scala2 at any time. | 19...

  • Page 21: Sensor Configuration

    About this task Note: Mosa2 can only be installed on a macOS operating system. Procedure 1. Go to the DealerWeb page: https://dealerweb.marport.fr/Default.aspx. 2. Select Sensors > Tools. The list of available Mosa2 software versions is displayed. The list begins with the latest versions.

  • Page 22: Connecting The Sensor To Mosa2

    Speed Sensors | V5 | Sensor Configuration c) In the terminal, enter sh /Volumes/Marport-Mosa2/MosaPatchForMavericks.sh d) When prompted, enter the administrator password. e) Close the terminal. f) Open Mosa2 to check if the script has worked. If Mosa2 does not open, it means the script has not worked.
  • Page 23 Speed Sensors | V5 | Sensor Configuration 4. Open Mosa2, then wait a few seconds for the sensor to be recognized. When it appears on the discovery page, click Results The sensor configuration page is displayed. Troubleshooting: If the sensor is not detected by Mosa2, the issue might come from the short-range wireless connection of the computer.

  • Page 24: Speed Explorer Specific Settings

    Speed Sensors | V5 | Sensor Configuration Speed Explorer Specific Settings Speed Explorer sensor has specific settings that need to be configured. Sounding Modes The sensor can send pings according to three different sounding modes. Down 1 Sensor sends pings towards down direction (1) only. You can see fish going into the trawl.

  • Page 25: Uplink

    Speed Sensors | V5 | Sensor Configuration About this task Remember: Always click Apply after you change a setting and make sure there is a green check mark Procedure Click the tab Trawl Explorer. Uplink Procedure From TE Uplink Frequency, enter a frequency for the signal toward the vessel. Important: This parameter must be the same in the sensor settings in Scala/Scala2.
  • Page 26 If you change ping length on a sensor calibrated for target strength, it will have to be returned to a Marport sales' office for target strength calibration. Note: The maximum detection depth depends on ping frequency and type of bottom. The lower the ping frequency is, the longer the detection depth is.

  • Page 27: Target Strength

    Ping frequency is an important setting for the calibration of the sensor. If you change ping frequency on a sensor calibrated for target strength, it will have to be returned to a Marport sales' office for target strength calibration. Target Strength...

  • Page 28: About Time Variable Gain

    Speed Sensors | V5 | Sensor Configuration • In TVG Coefficient, enter between 0.500 and 0.520 to have approximately the equivalent of 20 log , 0.75 for 30 log or 1 for 40 log. • In Attenuator Coefficient, enter 25. •...
  • Page 29 Speed Sensors | V5 | Sensor Configuration 2. Click the tab Trawl Explorer. 3. From Option True Mode, select a sequence from True Mode Option. • Select Config1 (default): this is the more appropriate sequence for a Speed Explorer. • Or select Config3 if you use the True mode display on echograms in Scala/Scala2. 4.

  • Page 30: Configuring The Noise Floor

    Speed Sensors | V5 | Sensor Configuration Configuring the Noise Floor Even when the sensor is in a silent environment, a small level of noise is detected. You need to measure this level of noise so that the sensor ignores it when operating, otherwise it could have effects on the echogram.

  • Page 31: Calibrating The Sensor For Target Strength Value

    Speed Sensors | V5 | Sensor Configuration 5. Click Apply and make sure there is a green check mark Calibrating the Sensor for Target Strength Value For V3 version of the sensor, you need to calibrate the sensor to offset the variability of the sensor transducer and of sound transmission.
  • Page 32 Speed Sensors | V5 | Sensor Configuration 2. Before putting the sensor in water: a) Activate and deactivate the water-switch to connect the sensor to Mosa2 via a wireless signal. b) Cover the water switch and charging pins with adhesive tape to prevent water from touching them.
  • Page 33 Speed Sensors | V5 | Sensor Configuration Note: If the sensor is not correctly placed, you may have an error message asking you to correct the pitch and/or roll angle. The sensor sends a series of 5 pings to calculate if the echo is consistent and constant. A new target strength offset is calculated.

  • Page 34: Canceling The Ringing

    Speed Sensors | V5 | Sensor Configuration 10. Click Apply to save the offset. 11. Click Send Ping to check the target strength of the ball. 12. Click Reset to come back to the last saved configuration and check that the offset has been saved.
  • Page 35 Speed Sensors | V5 | Sensor Configuration The sensor emits 10 pings and you can see a curve on the graph. 4. Select Adjust profile points on top of the graph. 5. From the graph, click and drag red line points above the gray and yellow curves: a) The red line should follow the same curve.
  • Page 36 Speed Sensors | V5 | Sensor Configuration Note: Data below the red line will not appear on the echogram and data above will appear as a red line on the echogram. 6. Click Apply and make sure there is a green check mark 7.

  • Page 37: Configuring Flow Sensor Telegrams

    Configuring Flow Sensor Telegrams You need to define channels and telegrams that the sensor uses to transmit data to the receiver. These settings are for Trawl Speed, Grid and Symmetry sensors. About this task Important: Make sure there is a minimum distance of 200 Hz between the uplink frequency and other NBTE sensors' frequencies.

  • Page 38: Calibrating The Speed

    Speed Sensors | V5 | Sensor Configuration • Telegram D3: sends data every 3 to 8 sec. • Telegram AL: sends data every 11 to 15 sec. Note: D3 sends data more often, but it reduces the battery life. c) From Pitch Boat Code/Channel Code, select a channel for pitch data. d) From Pitch Telegram, choose between: •...
  • Page 39 9. Click OK to the pop-up message. You do not need to click Apply at the bottom of the page. 10. Marport offices only: Save the configuration file and add it to the sensor page on the DealerWeb, in the part Validation Screen Shots.

  • Page 40: Checking Speed Measures With Em Log Tester

    • The sensor is connected to Mosa2. About this task If you do not have the EM Log tester, please refer to your local Marport sales office. The EM Log tester is also useful to check that the sensor is still operational over time. You can check speed before every fishing campaign to make sure the sensor works properly.
  • Page 41 Speed Sensors | V5 | Sensor Configuration Troubleshooting: If the along speed is negative and the across speed positive, it means that you placed the EM Log tester upside down or that the cabling inside the sensor is inverted. Troubleshooting: If an error message says the offset and gain are incorrect or the EM log tester is broken, it may be because the EM log tester was not totally immobile during the test.

  • Page 42: Configuring The Uplink Power

    Speed Sensors | V5 | Sensor Configuration Configuring the Uplink Power You can increase the uplink power of the sensor to increase the power of the signal transmitted. It is useful if you have interferences or if the sensor is far from the vessel. Before you begin The sensor is connected to Mosa2.
  • Page 43 • Or, click Copy to clipboard then press Cmd + V on a word processor like Pages to paste the contents. 6. Marport offices only: To add the test on the DealerWeb: a) Click Copy to clipboard. b) From the DealerWeb, click Sensors > A1.

  • Page 44: Updating The Sensor

    You can update the firmware of the sensor to the latest available version. Downloading the Firmware About this task Note: Marport offices only. Only Marport offices can download new versions of firmware. Dealerships need to ask their local Marport office to get the firmware. Procedure 1.

  • Page 45: Exporting Sensor Configuration Settings For Record Keeping

    Speed Sensors | V5 | Sensor Configuration Procedure 1. Connect the sensor to Mosa2. 2. From Mosa2, click Menu > Expert Mode and enter the password copernic. 3. Click the tab Firmware. 4. Click Browse to import your file. Note: On tablet computers, Browse only search for *.a1f files in the Downloads folder. Information on the sensor firmware is displayed.

  • Page 46: Exporting Sensor Configuration Settings For The Receiver

    • Or, click Copy to clipboard, then press Cmd + V on a word processor like Pages to paste the contents. 5. Marport offices only: you need to add the contents of this file on the DealerWeb. a) Click Copy to clipboard.
  • Page 47 Speed Sensors | V5 | Sensor Configuration • Click Save to file to download the XML file on the computer. • Or, click Copy to clipboard, then press Cmd + V on a word processor like Pages to paste the contents.

  • Page 48: System Configuration And Display

    Speed Sensors | V5 | System Configuration and Display System Configuration and Display Learn how to configure the receiver to be able to receive and display Speed sensor data. Note: This guide refers to the following versions: Scala 01.06.06-01.06.34, Scala2 02.02. If you use another version, the visual interface and options may vary.
  • Page 49 Speed Sensors | V5 | System Configuration and Display 3. Click the tab Add from Marport Sensor Config Utility. 4. Click Browse and select the XML file. Information about the sensor is displayed. 5. Select a node from the list on the left. Nodes in green are already used.

  • Page 50: Adding The Sensor Manually

    Speed Sensors | V5 | System Configuration and Display Type of sensor Nodes Symmetry Grid Back of trawl: 8, 7, 6, 5 6. Click Add Sensor. The sensor is added to the system, with all its settings. Results You can see incoming data in the control panels, in Sensors Data/ What to do next •...
  • Page 51 TE/TS TE/TS V2 or V3* • Headrope: 10, 11, 12, 13 • Tunnel: 7, 8, 9 Trawl Speed Trawl Speed with or without Pitch and Roll † Headrope: 10, 11, 12, 13 Symmetry Symmetry with or without Pitch and Roll †...

  • Page 52: Configuring The Sensor Settings

    Flow Sensors Only for sensors with pitch and roll. Sensor name displayed in Scala/Scala2 and its features. Trawl Speed in this example, but the parameters are the same for Grid and Symmetry sensors. This setting helps detecting the signal of the sensor among other sensor or echosounder signals.
  • Page 53 Speed Sensors | V5 | System Configuration and Display Enter the same frequencies as the ones entered in Mosa2 in Pitch and Roll or Roll Boat Code/Channel Code and Pitch Boat Code/Channel Code (if sending pitch on a different channel). •...

  • Page 54: Configuring Sensor Display On Scala/Scala2

    Data title should be: • TE/TS for a Speed Explorer • Trawl Speed or 3N1 (from Scala/Scala2 version 01.06.06) for Symmetry, Grid and Trawl Speed sensors. The title is followed by the node where the sensor was placed when added to the system. Data displayed (e.g.
  • Page 55 Speed Sensors | V5 | System Configuration and Display 3. Click + drag to a page Range of Sonar Data to display the echogram of a Speed Explorer. To display the target strength, from the top left corner of the echogram, right- click the Speed Explorer name and select Display Target Strength.
  • Page 56 Speed Sensors | V5 | System Configuration and Display 5. You can display Water Speed Along and Water Speed Across data in a Trawl Speed Dial or in a Trawl Speed 3D View. Open to the control panels and go to Open the customization panels and Customize.
  • Page 57 Speed Sensors | V5 | System Configuration and Display Trawl Speed 3D View 6. You can also click and drag the data from the control panels, then choose a type of display from Choose new Gauge Type. 7. To display the angle of a Grid sensor, drag Grid Angle data to a page and select Dial: Note: The angle displayed should be 45°...

  • Page 58: Outputting Scala/Scala2 Symmetry Data To Scantrol

    You can output across speed data from Scala/Scala2 to Scantrol iSYM application. Before you begin • You need to have iSYM version 3.5.10 (beta version) and above • Make sure you have a license to use Marport software with Scantrol. Procedure 1. In Scala/Scala2, go to Settings > NMEA Outputs.
  • Page 59 Select Emit only selected data types, then select Water Speed Along and Water Speed Across. 6. Go to iSYM's System Settings. 7. Go to Trawl Sensors tab, then select Marport in Active sensor source. 8. Configure the communication settings in Trawl sensor communication. Enter the same port you set in Scala/Scala2.
  • Page 60 Speed Sensors | V5 | System Configuration and Display Note: Port closed mention at the bottom of the window does not impact the configuration and should be ignored. Tip: If you need to test the NMEA connection but the sensors are not in water: configure the same output settings in Scala Replay/ScalaReplay2, then replay SDS files containing speed data.

  • Page 61: Installation

    Headrope The Trawl Speed, Symmetry and Speed Explorer sensors can be installed on the headline to monitor the movements of the trawl. The sensor must be placed below the headrope, EM log pins facing down, in order to send signals to the correct direction.
  • Page 62 Speed Sensors | V5 | Installation 1. Attached to headrope 2. Safety wire with small shackles on both ends to secure the sensor 3. Rope passing between 2 housing attachment lugs and attached to the net 1. Floats at the back help stabilizing the pitch and roll of the sensor 2.
  • Page 63 / 4. Safety wire between the sensor and the cage to secure the sensor The sensor is attached to the grid with stainless steel plate and fastenings (not supplied by Marport), like on the image below: | 62...

  • Page 64: Servicing And Maintenance

    Speed Sensors | V5 | Servicing and Maintenance Servicing and Maintenance Read this section for troubleshooting and maintenance information. Interference Check You can check if there is noise interfering with the reception of signals. Spectrum Analyzer Display The following picture explains the main parts of the spectrum analyzer page on Scala/Scala2. Start/Stop spectrum 10 Marker: display frequency and levels of noise (dB) analyzer...

  • Page 65: Checking Noise Interference

    Speed Sensors | V5 | Servicing and Maintenance Checking Noise Interference You can use the spectrum analyzer to check the noise level of the hydrophones and check for interference. About this task Spectrum Analyzer Display on page 63 for details about the spectrum analyzer display. Procedure 1.

  • Page 66: Checking Noise Interference

    Speed Sensors | V5 | Servicing and Maintenance 6. To see the maximum, mean and real time measures of noise level at a specific frequency, select Marker on the left side of the screen and move the mouse over the graph. Frequency and levels of noise (dB) at the mouse pointer location are displayed under Marker.
  • Page 67 Speed Sensors | V5 | Servicing and Maintenance 5. The spectrum analyzer is displayed. You can display up to 6 spectrum analyzers at the same time. Below is an example of a page with two spectrum analyzers. The FFT plot shows three levels of noise in dBV: 1.
  • Page 68 Speed Sensors | V5 | Servicing and Maintenance • RealTime: the latest highest level of noise (dBV) recorded and its frequency. • Max: the highest level of noise recorded since the beginning of the spectrum and its frequency. 8. Check that there is more than 12 dBV between the maximum noise level (dark blue line) and the average noise level (cyan line) on the peak of sensor frequencies.

  • Page 69: Charging The Sensor

    14. Right-click the IP address of the receiver in the status bar and click Stop Spectrum. Charging the Sensor Charge the sensor at any battery level with either Marport Basic Sensor Charger or Marport Medusa II Multi-charger. About this task The sensor uses lithium-ion batteries.

  • Page 70: Maintenance

    Read this section to learn best practices for maintaining the sensor. Only an approved Marport dealer can access the internal unit. Warranty will become void if anyone other than an approved dealer tries to do internal maintenance duties on the sensor.

  • Page 71: Cleaning The Sensor

    Make sure to always use a protective cage when using the sensor. The protective cage must be approved by Marport. Any additional protective devices installed in front of the head may disrupt the flow and therefore alter the water speed measurements.

  • Page 72: Maintenance Checklist

    • If you put the sensor into storage for a long period of time, charge it once in a while. If you do not, batteries can become inoperable. Every 2 years Return the sensor to an approved Marport dealer for inspection and maintenance. | 71...

  • Page 73: Replacing Parts

    Speed Sensors | V5 | Servicing and Maintenance Replacing Parts Qualified Marport technicians can remove and replace the following parts if they are damaged. Removing and Putting Back the Housing Before you begin For this task you need the following tools:...

  • Page 74: Replacing The Batteries

    2. Make sure the housing is in the right direction. The side of the head with the EM log pins must not be on the same side as the Marport writing. 6. Press the latches again to put back the protective cage.
  • Page 75 (Molykote 55 o-ring grease) About this task Only qualified Marport technicians can do this task. Procedure 1. Install new batteries. 1. Remove the tape protecting the components. 2. Remove the batteries from the internal housing of both bottles and disconnect them from the battery connectors.

  • Page 76: Replacing The Shoulder Bolts

    About this task Only qualified Marport technicians can do this task. CAUTION: Never remove the shoulder bolts directly from the end cap. Shoulder bolts are attached to cables and removing them will damage the cables. Always open the bottle to remove the shoulder bolts from the inside.
  • Page 77 Speed Sensors | V5 | Servicing and Maintenance 1. Fully clean the surface and hole from debris (with a swab or Q-tip) and inspect the surface for burrs or pitting. 2. Put new lubricated o-ring crushes inside each hole of the shoulder bolts.

  • Page 78: Replacing The Pressure Sensor

    8 to 10 Crimping tool O-ring Loctite 425 lubricant (Molykote 55 o-ring grease) About this task Only qualified Marport technicians can do this task. Procedure 1. Remove the retainers around the PCBA to get access to the connectors. | 77...
  • Page 79 Speed Sensors | V5 | Servicing and Maintenance 1. Remove the tape protecting the components. 2. Using a 1.5 mm Allen key, remove the four screws holding the retainers that are on the side of PCBA where all the cables are connected. 3.
  • Page 80 Speed Sensors | V5 | Servicing and Maintenance 1. Screw / 2. Spring / 3. Metal ring / 4. Pressure sensor / 5. Small o-ring (1mm thick) / 6. Adapter ring (metal, must be installed with grove-side up) / 7. Large o-ring (1.5mm thick, may stay in the bottom of the hole when pressure sensor is removed) / 8.
  • Page 81 3. Check that all seals in the bottle are clean and lubricated. Apply lubricant if necessary. A. End cap / B. Transducer 1. Main o-ring / 2. Backup o-ring Updating the Depth Coefficients About this task Note: Marport offices only | 80...

  • Page 82: Replacing The Pressure-Relief Spring

    Speed Sensors | V5 | Servicing and Maintenance Procedure 1. Go to the DealerWeb page: https://dealerweb.marport.fr/Default.aspx and select Sensors > A1. 2. From the search box on the right, enter the product serial number of the sensor. 3. From the part Keller Depth Sensor, click Edit.
  • Page 83 8 to 10 (Molykote 55 o-ring grease) About this task Only qualified Marport technicians can do this task. Procedure 1. Remove the old pressure-relief spring. 1. Remove the screw above the pressure-relief spring with the screwdriver. 2. Remove the spring, plug and o-ring from the hole.
  • Page 84 Speed Sensors | V5 | Servicing and Maintenance 1. Put one of the o-ring around the plug groove. 2. Put the other o-ring down into the bottom of the pressure-relief hole. 3. Put the plug into the hole. 4. Tighten the install tool into the hole with the flat screwdriver to set the plug in place.

  • Page 85: Replacing The Temperature Sensor

    (Molykote 55 o-ring grease) About this task Only qualified Marport technicians can do this task. Procedure 1. Remove the retainers around the PCBA to get access to the connectors. 1. Remove the tape protecting the components. 2. Using a 1.5 mm Allen key, remove the four screws holding the retainers that are on the side of PCBA where all the cables are connected.
  • Page 86 Speed Sensors | V5 | Servicing and Maintenance 1. Disconnect and remove the batteries to get access to the back of the end cap. 2. Disconnect the pressure and temperature connector from the PCBA and remove the temperature sensor cables (2 black and 2 white).
  • Page 87 Speed Sensors | V5 | Servicing and Maintenance 1. Replace the o-ring seals with new lubricated seals. 2. On the new temperature sensor cables, strip the end of each cable and crimp pins to each stripped cable. Tip: If you do not have the necessary tools to do these operations on the cables, another solution is to keep the old cables connected to the connector, cut them at mid-length and solder the new cables...

  • Page 88: Troubleshooting

    The firmware has the wrong board ID. • Check that the last set of numbers in the name of the firmware file corresponds to the board ID of your sensor. If not, Marport offices need to download the correct firmware file from the DealerWeb.

  • Page 89: Data In Scala/Scala2 Is Wrong

    Speed Sensors | V5 | Servicing and Maintenance If the sensor is not detected by Mosa2, the issue might come from the short-range wireless connection of the computer. 1. Close Mosa2. 2. Click the short-range wireless symbol in the top-right corner of the menu bar while holding the Shift (#) + ALT (#) keys on your Mac's keyboard.

  • Page 90: Echogram Is Fixed And Blue

    Speed Sensors | V5 | Servicing and Maintenance 4. You can increase the uplink power of the sensor to increase the power of the signal transmitted to the receiver: see Configuring the Uplink Power on page 41. 5. For sensors with echograms you can change the Echogram filter on Scala/Scala2 receiver page: 1.
  • Page 91 Speed Sensors | V5 | Servicing and Maintenance 2. From Mosa2, check speed measures with the EM log tester (see Checking Speed Measures with EM Log Tester). The sensor is not correctly installed on the trawl or the pitch and roll are not working correctly. 1.

  • Page 92: Support Contact

    Speed Sensors | V5 | Servicing and Maintenance Support Contact You can contact your local dealer if you need maintenance on your Marport products. You can also ask us at the following contact details: FRANCE ICELAND Marport France SAS Marport EHF 8, rue Maurice Le Léon...

  • Page 93: Appendix

    Speed Sensors | V5 | Appendix Appendix Frequency Plan It is important to carefully plan the setup of your sensors before adding them to the system. You can create a table with a list of frequencies and complete it when you add sensors. Boat &...
  • Page 94 Speed Sensors | V5 | Appendix C-4/CH5 42700 C-4/CH6 43300 C-5/CH1 42024 C-5/CH2 41690 C-5/CH3 41285 C-5/CH4 41060 C-5/CH5 42900 C-5/CH6 43400 C-6/CH1 39062 C-6/CH2 39375 C-6/CH3 39688 C-6/CH4 40000 C-6/CH5 40312 C-6/CH6 40625 C-7/CH1 38906 C-7/CH2 39219 C-7/CH3 39531 C-7/CH4 39844 C-7/CH5...
  • Page 95 Speed Sensors | V5 | Appendix Frequencies and intervals The diagrams below show the bandwidth of the different types of Marport sensors and intervals you must respect when adding other sensors. Figure 1: PRP sensors (e.g. Catch sensor, Trawl Speed, Spread sensor...) Example: If the frequency of the sensor is 40kHz, there should be no sensors between 39.9-40kHz...
  • Page 96 Speed Sensors | V5 | Appendix Examples of frequency allocations • We recommend to allocate frequencies between 34 and 56 kHz for wideband hydrophones and between 41 kHz and 44 kHz for narrowband hydrophones. • Echosounders are usually placed around 38 kHz, make sure to allow enough distance with them. | 95...
  • Page 97 Speed Sensors | V5 | Appendix | 96...

  • Page 98: Appendix B: Examples Of Installations For A Target Strength Calibration

    Speed Sensors | V5 | Appendix Appendix B: Examples of Installations for a Target Strength Calibration Support for sensor Figure 5: Example of support Figure 6: Example of support | 97...
  • Page 99 Speed Sensors | V5 | Appendix Ping pong ball Figure 7: Fishing line passes through the ball and is fixed with glue. Figure 8: Example of installation with counterweights. | 98...

  • Page 100: Appendix C: Technical Drawing Of Protective Cage

    Speed Sensors | V5 | Appendix 1. 50 cm 2. 1 m 3. Counterweight Appendix C: Technical Drawing of Protective Cage Technical drawing of the protective age for the Trawl Speed, Symmetry and Speed Explorer sensors. | 99...
  • Page 101 Speed Sensors | V5 | Appendix | 100...

  • Page 102: Index

    Index | 101 Index Numerics Wrong EM log 3D view Exporting configuration txt file XML file A1 board Across speed Along speed Export Firmware Battery life Error message Boat code Update Frequency Frequency plan Calibrating Across speed Along speed Geometry Installation examples Target Strength Channel code...
  • Page 103 Index | 102 Noise floor Technical specifications Noise Interference Telegram Temperature sensor Trawl opening TVG (Time Variable Gain) Option True Mode, See Measurement sending sequences Uplink power PCBA connectors Pings Pitch and roll Positive charge Water ingress Pulse length Water switch Range Receiver Adding sensor...
