GX LTE 4G - Manual
NOTE: DRAFT MANUAL. FIRST STOCK EXPECTED IN 2020 Q4
1. Introduction
1.1 Product description
The GX LTE is an accessory for GX-devices. It is a cellular 2G, 3G and 4G modem; providing a mobile
internet for the system and connection to
LTE Product Page
on our website.
There are three models:
Part number
Name
GSM100100400 GX LTE 4G-E For EMEA/Korea/Thailand
GSM100200400 GX LTE 4G-A For North America
GSM100300400 GX LTE 4G-SA For Australia/New Zealand/South America
More information about supported frequencies and bands are in chapter 7.1
It requires a SIM card of the
USB cable.
The GX LTE includes a built-in GPS receiver. When the optional GPS antenna is installed, the system
can be tracked as well as Geo-fenced on the VRM Portal.
Victron Energy - https://www.victronenergy.com/live/
1/9
Victron Remote Management (VRM)
Region
Mini-SIM
format; and connects to the
portal. See also the
GX-device
with an included 1 meter
GX LTE 4G - Manual
