User manual and installation
Ref:
GEN-OAN-GUI02
V1
Installation Manual SMK
Access Station Mini
September 2019
Note: Only the last version of this document available on the SIGFOX technical system documentation is official and
applicable. This document is confidential and is the property of SIGFOX. It shall not be copied and / or disclosed to third
parties, in any form without SIGFOX written permission."
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sigfox SMK Access Station Mini
Summary of Contents for Sigfox SMK Access Station Mini
-
Page 1: Installation Manual Smk Access Station Mini
Note: Only the last version of this document available on the SIGFOX technical system documentation is official and applicable. This document is confidential and is the property of SIGFOX. It shall not be copied and / or disclosed to third... - Page 2 13/09/2017 1.1 A. Trombetta Cable length 30/10/2017 1.2 A. Trombetta photos 09/09/2019 1.3 A. Trombetta Earth connectors Reference Documents Issued by Title Version SMK Access Station Mini Product Manual sigfox Assembly instruction Mast sigfox Assembly instruction Rail sigfox Commissioning Guidelines sigfox...
-
Page 3: Table Of Contents
Contents INSTALLATION MANUAL SMK ACCESS STATION MINI ..........1 1. INTRODUCTION ....................... 4 1.1 P ................... 4 RODUCT PRESENTATION 1.2 I ..................5 NSTALLATION VERVIEW 2 INSTALLATION SITE RECOMMENDATIONS ............6 2.1 A ........... 6 NTENNA PLACEMENT AND NEAR FIELD CLEARANCE 2.2 C... -
Page 4: Introduction
• SMK-868 operates in the 865-870 MHz band. • SMK-902 and SMK-902b operate in the 902-928 MHz band. SIGFOX Access Station Mini can fit in any terrain from rural, suburban to city locations and enable versatile installations at numerous sites ranging from indoors wall mount and desktop to outdoors on pole or rooftop. -
Page 5: Installation Overview
1.2 Installation Overview The Base Station should be used with the half-wave 2dBi antenna provided. Table of configurations Indoor Table DIN rail (wall) Outdoor Pole... -
Page 6: Installation Site Recommendations
2 INSTALLATION SITE RECOMMENDATIONS SMK Access Station mini has been developed for indoor and outdoor operation. It is certified including a 2dBi hinged half wave antenna that can be set straight or swivelled at right angle Note: For outdoor operation, the adjunction of sealing cover is mandatory. -
Page 7: Systems Proximity
200 m Wi-Fi 2.4 Admissible energy SMK access station mini shall not be exposed to signals greater than -20dBm from 0 to 821MHz and from 925MHz to 2.5GHz. SMK access station mini shall not be exposed to integrated power greater than 1mW within +/- 200 MHz from its operating frequency. -
Page 8: Bill Of Material
4 BILL OF MATERIAL Synopsis Power supply Ethernet connectivity Antenna USB dongle Sigfox Access Station Mini SBS-T3 MAS... -
Page 9: Antenna
4.1 Antenna Component Description Index Supplier Quantity Antenna Halfwave antenna sigfox 4.2 Base station Component Description Index Supplier Quantity SBS-T3 ( Access Station Mini TAP sigfox MAS) Fixation kit Different types of fixation sigfox Sealing cover Mandatory for outdoor sigfox... -
Page 10: Earthing
5 EARTHING Earthing (or grounding) all components is important especially if the BS is installed outside. The reasons are: - Protection against lightning strikes; - Evacuation of static electricity in the cables and equipment. Make sure the earth connectors are placed on surfaces free of paint or corrosion allowing the best electrical conduction. -
Page 11: Base Station Installation
6 BASE STATION INSTALLATION For assembly instruction please see the relevant reference documents. For desktop installation, make sure the surface is heat resistant. 6.1 Mast mount The Base station can be mast mounted (pole diameter from 20 to 50mm) and must be protected with sealing cover and optionally solar shade. -
Page 12: Base Station Waterproofness
In wall mounting configuration indoor, the antenna can be bent at 45 or 90° away from the wall to prevent losses. Instruction for fixing the DIN rail (length 200mm) onto the wall and the base station is provided with the Rail set. 7 BASE STATION WATERPROOFNESS Connectors’... - Page 13 Cover location...
-
Page 14: Electrical Connection
8 ELECTRICAL CONNECTION The base station must be connected to a power point with electrical protection according to standards. The base station operates with 12 V DC supply voltage. Figure: power supply input Power DIN 4 pin with lock type 8.1 Input power specification The electrical specifications are: Input voltage... -
Page 15: Cable Length
The base station only accepts the dynamic host configuration protocol (DHCP) on the ETH interface. For example: ADSL, 4G… Please refer to the provider’s manual. 9.2 Secondary The base station can be connected via the 3G or 4G network with the USB dongle provided by Sigfox. -
Page 16: Powering On & Commissioning
10 POWERING ON & COMMISSIONING Powering on the station will turn it on. It should be done only once the installation is finished. The Base Station will then automatically boot up. 10.1 LED status See Product Manual. 10.2 Commissioning See Training document BS commissioning. -
Page 17: Annexes
Annexes Base Station Label Following elements will appear in SMK label: Model, Input and Serial Number. The model is: SBS-T3-xxx (where xxx is the version number: 868, 902 or 902b) S/N is 0xxxxxxx-XX This is the base station ID This is the code to indicate it is an Access Station Mini The complete label will be defined on a country basis, taking into account the certification requirements.
