MayPole MP7951 Manual

12v hand held

Download this manual

1. TECHNICAL SPECIFICATION

SECSPECIFICATIONS

Item No:

Voltage:

MP7951

12V - DC

2. PRODUCT SPECIFICATION

1. Trigger Switch

2. Analogue dsiplay

Hose with Quick coupler

www.maypole.ltd.uk

MP7951 12V Hand Held Air Compressor

Rated

Power

Flow Rate:

Current:

100 Watt

12 l/min.

4. Tyre connector

5. Ball needle connector

6. Inflatables connector

Max.

Sound Pressure

Pressure:

150 psi

<75.2 dB(A)

7. 12V DC vehicle connector

8. Accessory holder

Sound Power

<95.2dB (A)

Need help?

Do you have a question about the MP7951 and is the answer not in the manual?

Page 1 MP7951 12V Hand Held Air Compressor 1. TECHNICAL SPECIFICATION SECSPECIFICATIONS Item No: Voltage: Rated Power Flow Rate: Max. Sound Pressure Sound Power Current: Pressure: MP7951 12V - DC 100 Watt 12 l/min. 150 psi <75.2 dB(A) <95.2dB (A) 2. PRODUCT SPECIFICATION 1.
Page 2 MP7951 12V Hand Held Air Compressor 3. INTENDED USE Your analogue compressor is designed to be used from the standard 12V dc socket in most vehicles, to inflate car and bike tyres, balls, etc. This product is intended for household, consumer use only.
Page 3 MP7951 12V Hand Held Air Compressor 5. OPERATION OPERATION USE OF ACCESSORIES Remove the required accessories from the accessory Note: Make sure that the Quick Coupler is correctly fitted compartment. to the item to be inflated. To start the inflator use the trigger switch.
Page 4 MP7951 12V Hand Held Air Compressor 6. MAINTENANCE The only user serviceable part is a 10Amp fuse located I the 12V connector, this can be checked by unscrewing the spring loaded centre pin from the plug. Only replace with a fuse with identical ratings. Make sure that the machine is not live when carrying out maintenance work.
