Adaptive AlphaVision III PC Series Replacement Instructions

AlphaVision™ PC Series III Sign Controller Board Kit

Overview

AlphaVision PC Series signs contain an embedded controller board. The controller board translates messages via
ethernet and displays them on the sign. Depending on the installation of the sign, the controller board is interfaced
using one of two options. One option is a modular CAT5 Ethernet network connection, and the second option is a direct
connection to a monitor, keyboard, and mouse.
Attached to the controller board is a turbo board. The turbo board serves as an interface between the controller board
and the display face.
Several other sign components connect to the controller board including the sound card, hard disk drive (optional), loop
back boards, and power supplies.
These instructions are a guide for replacing the controller board kit into AlphaVision PC series signs.
LED display
panel
Disconnect
box
NOTE: Only one controller board is needed to operate single-sided or double-sided signs
Adaptive Micro Systems • 7840 North 86th Street • Milwaukee, WI 53224 USA • 414-357-2020 • 414-357-2029 (fax) • http://www.adaptivedisplays.com
Adaptive is a registered trademark of Adaptive Micro Systems. AlphaVision is a trademark of Adaptive Micro Systems.
May 15, 2007
Replacement Instructions
(pn 1234202726SP)
AVPC256112T3 Series (Shown with Controller side open)
Power
supplies
© Copyright 2007 Adaptive Micro Systems LLC. All rights reserved.
All other brand and product names are trademarks or registered trademarks of their respective companies.
Controller board and
turbo board
Top panel
Sound card
(optional)
Hard disk drive
(optional)
1234610511A
