6. Adjustment
wall
120°
Adjust to the desired position or tilt.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
7
Depending on the weight of the display,
it may be necessary to make adjustments
to the Ball Joint Mechanism.
E
+15°
360°
-15°
INSTALLATION MANUAL
TV Wall Mount
75x75
PM-STYLE-23A
100x100
CAUTION:
DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
27"
15kg
15kg
MAX
(33lbs)
(33lbs)
RATED
RATED
ISSUED: SEPT. 2013
Advertisement
Table of Contents
Related Manuals for PureMounts PM-STYLE-23A
Summary of Contents for PureMounts PM-STYLE-23A
- Page 1 Adjust to the desired position or tilt. 27" 75x75 Maintenance 15kg 15kg PM-STYLE-23A 100x100 • Check that the bracket is secure and safe to use at regular intervals(at least every three months). (33lbs) (33lbs) • Please contact your distributor if you have any questions.
- Page 2 Component Checklist NOTE: Read the entire instruction manual before you start installation and assembly. IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •...
- Page 3 2b. For Solid Brick and Concrete Mounting 1. Separating the VESA Plate from the Wall Mount 60mm 60mm (2.4") (2.4") ø 8mm (ø 5/16") Mark the exact location of mounting holes 2a. For Wood Stud Wall Mounting 50mm 50mm Drill pilot holes (2") (2") ø...
- Page 4 3. Installing the Decorative Covers wall Screw the VESA plate onto the TV. Install the decorative covers along the wall plate rail until they fit snuggly onto the wall plate. Tighten all screws but do not over tighten. 4. Installing the VESA Plate 5.
