Page 1: Installation Manual
INSTALLATION MANUAL TV Wall Mount CAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 55" 200x200/400x200 PM-EASYFLEX-52 300x300/400x400 30kg 30kg 200x200/400x200 (66lbs) (66lbs) 70" PM-EASYFLEX-65 300x300/400x400 RATED RATED 600x400 ISSUED: OCT. 2013... - Page 2 NOTE: Read the entire instruction manual before you start installation and assembly. Component Checklist IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •...
- Page 3 1b. For Solid Brick and Concrete Mounting 1a. For Wood Stud Wall Mounting 55mm 55mm 55mm 60mm 60mm 60mm (2.2") (2.2") 2.2" (2.4") (2.4") 2.4" ø 4.5mm ø 10mm (ø 3/16") (ø 3/8") Find and mark Mark the exact the exact location location of of mounting holes mounting...
- Page 4 2. Mounting the Plastic Covers 4. Installing the Adapter Brackets wall wall thumbscrew BOTTOM Note: P ull the articulated arm and make it vertical to wall ,insert both top and bottom plastic covers Adjust the brackets to fit mounting holes on the back side of the TV.
- Page 5 5. Hooking the TV onto the Wall Mount 4-2 For Recessed Back Screens or to Access A/V Inputs wall M-C/M-D/M-E Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen. · Screw the assembled bracket onto the TV. ·...
- Page 6 6. Adjustment 180° -2° ~ +2° -15° Adjust to the desired position or tilt. Maintenance • Check that the bracket is secure and safe to use at regular intervals(at least every three months). • Please contact your distributor if you have any questions.
