Summary of Contents for Phylrich K8108
- Page 1 INSTALLATION INSTRUCTIONS FOR Single Hole Bar Faucets Product #’s: K8108, K8158, K8160, K8161 & K8190 FORM:LIT-INS-810-704 2937 North Ontario Street • Burbank • California 91504-2017 Telephone: 800-PHYLRICH • Fax: 818-955-7790 www.phylrich.com...
- Page 2 Step #1 Step #2 Position the Bar Body over the mounting hole as shown. (Note: The Handles pull for- ward to turn on.) The Mounting Bracket must be in the back.) Feed the Bar Supply Hoses (C) through the mounting hole on the counter.
- Page 3 Parts Breakout for K8108, K8158, K8160, K8161, K8190 Final View...
