- Page 1 INSTALLATION INSTRUCTIONS FOR LAVATORY FAUCETS WITH A TEE ASSEMBLY 1261 Logan Ave, Costa Mesa, CA 92626 Telephone: 714-361-4830 Fax: 714-617-3120 www.phylrich.com...
- Page 2 Step 1 Step 2 1 1/8" DIAMETER. HOLE for HOT & COLD VALVE MIN. 1 1/2" DIAMETER SPOUT HOLE Insert spout base nipple into center hole in lavatory or Should a counter top need to be drilled, please reference counter top. Install stainless washer (7) and spont (8) on the diagram above.
- Page 3 Step 7 Step 8 Connect stainless steel flex lines (6) from valve outlets to Insert drain rim (25) into the basin placing the Teflon spout tee (10). Flex lines should be looped as shown washer (26) under the rim. From below slip on washer (27) indiagram.
- Page 4 Page 3 P99030 (8/07)
- Page 5 ROUGH IN SPECIFICATIONS FOR LAVATORY SETS WITH TEE ASSEMBLIES Phylrich Prod# Rough In Phylrich Prod# Rough In K101.....2 1/2” K190.....2 1/2” K109.....2 1/2” K190A....2 1/2” K110.....2 1/2” K191.....2 1/2” K120.....2 1/2” K191A....2 1/2” K120A....2 1/2” K211.....2 7/8” K121.....2 1/2” K230....2 5/8”...
