Related Manuals for DenMat PeriOptix Flip-up
Summary of Contents for DenMat PeriOptix Flip-up
- Page 1 Legacy Greatest-value flip-up on the market. For any questions or problems, please contact your local distributor or call DenMat Customer Care at 1-800-433-6628 between the hours of 8am to 5pm (Pacific Time) Monday-Friday. Outside the U.S., please call 1-805-347-7990. Den-Mat Holdings, LLC 1017 W.
- Page 2 Flip-up Loupe and Frame Directions for Use Instructions, warranty and cleaning for PeriOptix Flip-up loupe system and frame...
- Page 3 Please note that your loupe system arrives complete and requires no assembly! Contents Inspect contents. If any item is missing, contact DenMat Customer Support. 1. Loupe Optics 2. Frame 3. Case 4. Lens Covers (Legacy Optics only) 5. Microfiber Cleaning Cloth 6.
- Page 4 Prompt inspection and reporting of missing or damaged product should be reported to shipping carrier and DenMat within 3 days of receipt of product. If DenMat products or any component thereof is found to be defective or at variance with the manufacturer’s specifications during the warranty period, DenMat will repair or replace the instrument or component(s) at no cost to the purchaser.
- Page 5 ANY OTHER STERILIZATION METHOD. • NO MODIFICATION OF THIS EQUIPMENT IS ALLOWED Storage When not using your loupes, store in the supplied carrying case with the lens covers in place (Legacy optics only). Avoid moisture and store in a dry environment. denmat.com...
- Page 6 Loupe Terminology A. Declination Angle B. Convergence Angle C. Interpupillary Distance (IPD) — distance between the pupils denmat.com...
- Page 7 2.2 Focus on an object with the optics far apart. 2.3 Bring the optics together until a single circle is observed. When a single circle is observed the IPD is set. Before IPD is adjusted After IPD is adjusted denmat.com...
- Page 8 If two dots are still seen, repeat steps 4.1 through 4.5 until one dot is seen and both barrels are pointing inward equally. Once set, tighten both convergence screws on each barrel. Barrels in Barrels out allignment of allignment denmat.com...
