TENTCO T21 Instructions

Family trailer tent

Advertisement

Instructions:

1.Ensure you are parked on level ground, your trailer brake is engaged and your stabiliser bars are down before you erect your tent
2. Remove the bag by loosening the straps, release the tension on the elastic chord and lift all the corners up of the board being
careful not to hook the bag on the frame.
3. Pull down the side tent canvas so that it hangs of the board and open the door flap to allow air to enter when erecting the tent.
4. With a person on either side of the tent ie. nosecone and tailgate, slowly lift the tent poles up allowing air to enter.
5. Once the tent frame is up insert the 2 aluminium poles at the front side of the tent. Attach the clinch fittings to the
ends of the horizontal pole next to the eye fitting. Now lay out the side tent and peg it down at all 4 corners.
6. Insert the springsteel rods into the holes in the hinges and attach to the flysheet. Use the 2 steel poles to support
the flysheet.
7. Additional guy ropes are installed on the side of the flysheet at the centre tent frame pole To provide extra stability
in windy conditions.
8. Additional straight pegs have been provided for the anchor points on the side tent groundsheet.
9. Inside the tent the ladder is to be fastened with the 2 velcro strips on the board edge. Failure to secure ladder properly
could result in serious injury.
10. We suggest an extra groundsheet be placed under the side tent to prevent damage by stones and thorns etc...
Children are to be supervised at all times when in the tent, close shade net zips on top of bed to prevent children falling out.
11. See overleaf for instructions for mounting tent to trailer
Go to
www.tentco.co.za
TRAILER TENT
TRAILER TENT
to view instructional videos on how to erect your tent
FAMILY
FAMILY
Zip to attach
add a room
Telescopic aluminium pole
with clinch fittings, under flysheet
Guy ropes
Aluminium poles
with clinch fittings
