- Page 2 Thank you for purchasing a Pro‐LIFT G5Z. The Pro‐LIFT product line is designed to enhance your interactive whiteboards and projectors or LCD. Please follow all assembly instructions correctly to provide optimal use. Only a qualified contractor should install the Pro‐LIFT G5Z. If you do not understand any of the assembly instructions, please contact your local re‐seller or visit www.proliftstand.com. IMPROPER INSTALLATION CAN CAUSE DAMAGE TO YOUR Pro‐LIFT AND LEAD TO SERIOUS PHYSICAL INJURY. JORO Manufacturing cannot take any responsibility for damage or injury resulting from improper installation. Do not operate Pro‐LIFT G5Z if there are any obstructions below or above the board. Doing so may cause unit malfunction or lead to serious physical injury. The supplied mounting hardware is for use on the Pro‐LIFT stands only. If you encounter any problems or insufficient hardware during installation, please contact your local re‐seller. ...
- Page 3 G5ZL Main Frame Kit 3/16" Allen (Hex) Key Tube End Cap Cable Tie Mount Handle LCD Mount Fastener Kit 5/32" Allen (Hex) Key 3/16" Allen (Hex) Key ZLT Kit (ONLY available with Accessories) 5/32" Allen (Hex) Key Wing Nut - 10-24 www.joromfg.com www.proliftstand.com COPYRIGHT 2014...
- Page 4 M6 x 14mm Socket Cap Screw Mount the Pro-LIFT G5Z Feet For ease of installation, do this step while Pro-LIFT G5Z is lying down Be sure to use the M6 x 14mm Socket Cap Screws provided Be sure to NOT over tighten www.joromfg.com...
- Page 5 2 Pro-LIFT G5Z-ACC-LUPR LEFT Pro-LIFT G5Z-ACC-LUPR RIGHT Pro-LIFT PRO-LIFT LCD ARM Pro-LIFT PRO-LIFT LCD ARM 5/16x3/4" SILVER Button Head 5/16x3/4" SILVER Button Head Remove the 5/16x3/4" SILVER Button Heads and unhook the Pro-LIFT LCD Arm Be sure to NOT misplace the 5/16x3/4" SILVER Button Heads www.joromfg.com...
- Page 6 G5Z-ACC-LUPR LEFT G5Z-ACC-LUPR RIGHT 3 M6 x 14mm Socket Cap Screw G5Z-ACC-LUPR LEFT Mount the Pro-LIFT G5Z-ACC-LUPR Be sure to use the M6 x 14mm Socket Cap Screws supplied Be sure to NOT overtighten www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5ZL ASSY Instructions : 0.007...
- Page 7 Tube1020 End Cap 5/16 Hex Nut Tube1020 End Cap 5/16 Hex Nut 5/16x1" Button Head 5/16x1" Button Head 4 5/16 Hex Nut Tube1020 End Cap G5-ACC-PT5 5/16 Hex Nut 5/16x1" Button Head 5/16x1" Button Head Tube1020 End Cap Fasten the 5/16x1" Button Head Screws to the G5-ACC-PT5 Be sure to NOT over tighten Use rubber mallet to knock Tube1020 End Caps into place 5/16 Hex Nut...
- Page 8 5 Please use the appropriate mounting holes for your LCD (not included) as shown above G5-ACC-PT5 G5-ACC-PT5 LCD Fastener from LCD TV Kit provided Fasten the G5-ACC-PT5 to your LCD (not included) using the fasteners from the LCD TV Kit Be sure to use the appropriate fasteners as specified in the LCD owners manual Be sure to NOT over tighten www.joromfg.com...
- Page 9 PRO-LIFT LCD ARM Mount the Pro-LIFT LCD Arms to the G5-ACC-PT5 tubes Mount the Pro-LIFT LCD Arms prior to hanging on the Pro-LIFT G5Z main frame Be sure to use the fasteners supplied DO NOT COMPLETELY TIGHTEN! Allow for PRO-LIFT LCD ARM alignment www.joromfg.com...
- Page 10 7 G5Z-ACC-LUPR LEFT G5Z-ACC-LUPR RIGHT G5Z-ACC-LUPR LEFT G5Z-ACC-LUPR RIGHT Hang the LCD assembly Be sure to hang on all four (4) pins on uprights www.joromfg.com www.proliftstand.com COPYRIGHT 2014 ProLift G5ZL ASSY Instructions : 0.007...
- Page 11 5/16 Hex Nut 8 5/16x3/4" SILVER Button Head Secure Pro-LIFT LCD Arms to G5ZL Uprights Be sure to use the 5/16x3/4" SILVER Button Head Screws that were removed earlier Tighten all 5/16 Hex Nuts Be sure to NOT over tighten www.joromfg.com...
- Page 12 Thread-Cutting Screw (8-32 x 1/4" Lg.) Cable Tie Mount Cable Tie Mount Fasten the Cable Tie Mounts (Wire Management) Mounting holes provided on both G5Z Uprights and G5Z Main Support G5Z Main Support Be sure to use the Thread-Cutting Screw (8-32 x 1/4" Lg.) Be sure to NOT over tighten www.joromfg.com...
- Page 13 ...
- Page 14 Page Left Blank On Purpose ...
- Page 15 5Z-A C-TL Ordered d separ rately) Laptop not incl luded) ...
- Page 16 1/4" Washer G5Z-ACC-LTA Mount the Laptop Tray (if ordered with your product) For ease of installation, mount the G5Z-ACC-LTA first Be sure to use the M6 x 20mm Socket Cap Screw and 1/4" Washers from the ZLT Kit Mount the G5Z-ACC-TLT...
- Page 17 Page Left Blank On Purpose ...
- Page 18 5Z-A C-DC Ordered d separ rately) ...
- Page 19 1/4" Washer G5Z-ACC-LTA Mount the Documetn Camera Tray (if ordered with your product) For ease of installation, mount the G5Z-ACC-LTA first Be sure to use the M6 x 20mm Socket Cap Screw and 1/4" Washers from the ZLT Kit Mount the Stamped Top Arm...
-
