Installation should only be performed by a Qualified Installation Professional
Safety warnings, contents of the box, tools needed
1
x4
12"
16"
* Mounting material not included .
Carefully check the condition of the wall , which
is provided for installation and select
appropriate fastening materials . Please note
that the free-standing installation requires a
correspondingly stable wall or possibly a gain .
Mount the wall bracket in a horizontal
position on the wall .
TP-1938-V05 ©2016 Promethean Ltd. All Rights Reserved. Products are subject to availability by country.
Product specifications are subject to change without notice.
4 x M3.5
1x
Optional
2
Remove the cover of the height adjustment .
ActivPanel Adjustable Stand 400
APTASBB400-90 - for use with ActivPanels
3
Make sure that the screws are turned
maximum to left safely.
5
Lock the stand with lock screws
with a mass* of 66kg to 95kg
™
Installation Guide
4
Lift the stand onto the bracket
6
Level vertically with feet at the bottom.
